前視多通道合成孔徑雷達解模糊成像方法

盧景月; 張磊; 王冠勇

doi:10.11999/JEIT180177

前視多通道合成孔徑雷達解模糊成像方法

doi: 10.11999/JEIT180177 cstr: 32379.14.JEIT180177

西安電子科技大學雷達信號處理國家重點實驗室 ??西安 ??710071

基金項目: 國家自然科學基金(61771372, 61771367)

詳細信息

作者簡介:
盧景月：男，1994年生，博士生，研究方向?yàn)楹铣煽讖嚼走_(dá)成像

張磊：男，1984年生，副教授，主要研究方向?yàn)楹铣煽讖嚼走_(dá)成像、目標識別

王冠勇：男，1989年生，工程師，主要研究方向?yàn)楹铣煽讖嚼走_(dá)成像

通訊作者:
張磊　 775807665@qq.com

中圖分類號: TN957.52
計量
- 文章訪問數: 2538
- HTML全文瀏覽量: 876
- PDF下載量: 91
- 被引次數: 0
出版歷程
- 收稿日期: 2018-02-09
- 修回日期: 2018-07-10
- 網絡出版日期: 2018-07-24
- 刊出日期: 2018-12-01

Ambiguity Resolving and Imaging Algorithm for Multi-channel Forward-looking Synthetic Aperture Radar

National Key Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China

Funds: The National Natural Science Foundation of China (61771372, 61771367)

摘要

摘要: 傳統合成孔徑雷達方位向分辨率僅由合成孔徑提供，但在正前視區域多普勒分集有限，成像性能迅速下降且前視成像也存在固有的左右多普勒模糊問題。針對上述問題該文討論前視多通道合成孔徑雷達系統模型，提出一種理想直線航跡下空域零點約束自適應波束形成的成像方法，有效綜合陣列實孔徑和合成孔徑提高正前視區域的成像質量，利用有限陣列空域自由度實現左右多普勒解模糊。首先對回波數據大前斜成像處理，得到左右模糊的圖像，然后進行波束形成，將各通道圖像加權并且相干累加，實現左右多普勒解模糊以及方位分辨率增強。仿真實驗表明空域零點約束自適應波束形成的成像方法可對前視場景進行高分辨成像。
- 合成孔徑雷達 /
- 前視成像 /
- 方位向分辨率 /
- 多普勒模糊 /
- 波束形成
Abstract: The azimuth resolution of traditional synthetic aperture radar is only provided by synthetic aperture. However, in the forward looking area, the Doppler diversity is limited, so the imaging performance declines rapidly. And forward looking imaging also has the Doppler ambiguity problem. In this paper, an adaptive beam forming method with spatial confinement under ideal line track is proposed. The imaging quality of the positive forward region is improved effectively by combining the array of real aperture and synthetic aperture, and the Doppler solution is blurred by using the array space domain. First, the echo data is processed by High Squint SAR imaging to obtain the blurred image. Then the beam-forming is performed, weighted and coherent accumulated with each channel image, so as to resolve Doppler ambiguity and enhance the azimuth resolution. Simulation confirms the validity of the proposed approach.
- SAR /
- Forward-looking imaging /
- Azimuth resolution /
- Doppler ambiguity /
- Beam forming

HTML全文

圖 1 FLMC-SAR系統模型

下載: 全尺寸圖片幻燈片

圖 2 算法處理流程

下載: 全尺寸圖片幻燈片

圖 3 點目標成像結果

下載: 全尺寸圖片幻燈片

圖 4 面目標成像結果

下載: 全尺寸圖片幻燈片

表 1 仿真參數

參數	數值	參數	數值
載頻Fc	30 GHz	脈沖重復頻率PRF	8000 Hz
信號帶寬B	55 MHz	波束方位寬度	8°
采樣帶寬Fs	64 MHz	波束俯仰寬度	22°
下壓角	20°	場景中心斜距Rs	7000 m
合成孔徑長度	100 m	陣列實孔徑長度	0.4 m

下載: 導出CSV

表 2 各方位點目標仿真分辨率與理論分辨率對比

參數	數值	數值	數值	數值	數值
坐標	(R₀, 3.4°)	(R₀, –3.0°)	(R₀, 2.6°)	(R₀, 2.2°)	(R₀, 1.8°)
仿真分辨率IRW(rad)	6.76E–04	7.63E–04	8.72E–04	1.13E–03	1.53E–03
理論全孔徑分辨率	7.00E–04	7.91E–04	9.09E–04	1.07E–03	1.29E–03
理論合成孔徑分辨率	7.50E–04	8.55E–04	9.94E–04	1.19E–03	1.46E–03

下載: 導出CSV

參考文獻(15)

WU Xiaoli and WANG Weiwei. The burst mode of geosynchronous Synthetic Aperture Radar[C]. IEEE 5th Asia-Pacific Conference on Synthetic Aperture Radar, Piscataway, USA, 2015: 200–203.

LI Caipin and HE Mingyi. A novel attitude steering strategy for GEO SAR staring Imaging[C]. IEEE China Summit and International Conference on Signal and Information Processing, Piscataway, USA, 2015: 630–634.

RODRIGUEZ M, PRATS P, SCHULZE D, et al. First bistatic spaceborne SAR experiments with TanDEM-X[J]. IEEE Geoscience and Remote Sensing Letters, 2012, 9(1): 33–37.

INGO W, THOMAS E, and JENS K, et al. Potential and limitations of forward-looking bistatic SAR[C]. IEEE International Geoscience and Remote Sensing Symposium, Piscataway, USA, 2010: 216–219.

孟自強, 李亞超, 邢孟道, 等. 基于斜距等效的彈載雙基前視SAR相位空變校正方法[J]. 電子與信息學報, 2016, 38(3): 613–621 doi: 10.11999/JEIT150782

MENG Ziqiang, LI Yachao, XING Mengdao, et al. Phase space-variance correction method for missile-borne bistatic forward-looking sar based on equivalent range equation[J]. Journal of Electronics&Information Technology, 2016, 38(3): 613–621 doi: 10.11999/JEIT150782

REN Xiaozhen, SUN Jiantao, YANG Ruliang, et al. A new three-dimensional imaging algorithm for airborne forward-looking SAR[J]. IEEE Geoscience and Remote Sensing Letters, 2011, 8(1): 153–157 doi: 10.1109/LGRS.2010.2055035

SUTOR T, BUCKREUSS S, KRIEGER G, et al. Sector imaging radar for enhanced vision: theory and applications[C]. European Conference on Synthetic Aperture Radar, Munich, Germany, 2000: 357–359.

包敏, 周鵬, 史林, 等. 雙天線前視彈載SAR解模糊算法研究[J]. 電子與信息學報, 2013, 35(12): 2857–2862 doi: 10.3724/SP.J.1146.2013.00083

BAO Min, ZHOU Peng, SHI Lin, et al. Study on deambiguity algorithm for double antenna forward looking missile borne SAR[J]. Journal of Electronics&Information Technology, 2013, 35(12): 2857–2862 doi: 10.3724/SP.J.1146.2013.00083

李悅麗, 梁甸農, 黃曉濤, 等. 一種單脈沖雷達多通道解卷積前視成像方法[J]. 信號處理, 2007, 23(5): 699–703

LI Yueli, LIANG Diannong, HUANG Xiaotao et al. A multi-channel deconvolution based forward-looking imaging method in monopulse radar[J]. Signal Processing, 2007, 23(5): 699–703

曾操, 陳昊, 何學輝, 等. 相控陣子陣級和差多波束測角方法[J]. 西安電子科技大學學報, 2013, 40(1): 19–25 doi: 10.3969/j.issn.1001-2400.2013.01.004

ZENG Cao, CHEN Hao, HE Xuehui et al. Monpulse angle estimation using sun-difference multi-beamforming based on the phase array at the sub-array level[J]. Journal of Xidian University, 2013, 40(1): 19–25 doi: 10.3969/j.issn.1001-2400.2013.01.004

趙珊珊, 張林讓, 劉楠, 等. 利用幅度比特征進行有源假目標鑒別[J]. 西安電子科技大學學報, 2017, 44(5): 51–57 doi: 10.3969/j.issn.1001-2400.2017.05.009

ZHAO Shanshan, ZHANG Linrang, LIU Nan, et al. Active false-target discrimination method based on the amplitude ratio feature[J]. Journal of Xidian University, 2017, 44(5): 51–57 doi: 10.3969/j.issn.1001-2400.2017.05.009

韋北余, 朱岱寅, 吳迪, 等. 一種基于和差波束的機載SAR定位方法[J]. 電子與信息學報, 2013, 35(6): 1464–1470 doi: 10.3724/SP.J.1146.2012.01194

WEI Beiyu, ZHU Daiyin, WU Di, et al. An airborne SAR geolocation approach based on sum-difference beam SAR imagery[J]. Journal of Electrontics&Information Technology, 2013, 35(6): 1464–1470 doi: 10.3724/SP.J.1146.2012.01194

馬曉峰, 沈愛松, 盛衛星, 等. 可控測角精度和范圍的數字陣列單脈沖和差波束優化[J]. 電子與信息學報, 2016, 38(12): 3107–3113 doi: 10.11999/JEIT160873

MA Xiaofeng, SHEN Aisong, SHENG Weixing et al. Sum and difference patterns optimization for digital array with controllable accuracy and range of angle estimation[J]. Journal of Electronics&Information Technology, 2016, 38(12): 3107–3113 doi: 10.11999/JEIT160873

溫鑫, 黃培康, 年豐, 等. 主動式毫米波近距離圓柱掃描三維成像系統[J]. 系統工程與電子技術, 2004, 36(6): 1044–1049

WEN Xin, HUANG Peikang, NIAN Feng et al. Active millimeter-wave near-field cylindrical scanning three-dimensional imaging system[J]. Systems Engineering and Electronics, 2004, 36(6): 1044–1049

馬喜樂. 方位多相位中心SAR高分辨率寬測繪帶成像技術研究[D]. [博士論文], 國防科技大學, 2014.

MA Xile. Research on high-resolution wide-swath imaging technologies of azimuth multiple phase center SAR[D]. [Ph.D. dissertation], National University of Defense Technology, 2014.
