短階相干系數加權的平面波復合成像算法

鄭馳超,  張路南,  王浩,  彭虎

鄭馳超, 張路南, 王浩, 彭虎. 短階相干系數加權的平面波復合成像算法[J]. 電子與信息學報, 2018, 40(12): 2919-2927. doi: 10.11999/JEIT180120
引用本文: 鄭馳超, 張路南, 王浩, 彭虎. 短階相干系數加權的平面波復合成像算法[J]. 電子與信息學報, 2018, 40(12): 2919-2927. doi: 10.11999/JEIT180120
Chichao ZHENG, Lunan ZHANG, Hao WANG, Hu PENG. Plane-wave Compounding with Short-lag Coherence Factor Weighting[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2919-2927. doi: 10.11999/JEIT180120
Citation: Chichao ZHENG, Lunan ZHANG, Hao WANG, Hu PENG. Plane-wave Compounding with Short-lag Coherence Factor Weighting[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2919-2927. doi: 10.11999/JEIT180120

短階相干系數加權的平面波復合成像算法

doi: 10.11999/JEIT180120 cstr: 32379.14.JEIT180120

  • 合肥工業大學生物醫學工程系 ??合肥 ??230009

基金項目: 國家自然科學基金(61201060, 61172037)
詳細信息
    作者簡介:

    鄭馳超：男，1984年生，副研究員，碩士生導師，研究方向?yàn)獒t(yī)學超聲成像、信號處理

    張路南：女，1994年生，碩士生，研究方向?yàn)獒t(yī)學信號處理

    王浩：男，1994年生，碩士生，研究方向?yàn)殡娐放c系統

    彭虎：男，1962年生，教授，博士生導師，研究方向?yàn)獒t(yī)學超聲工程、電路與系統

    通訊作者:

    彭虎　 hpeng@hfut.edu.cn

  • 中圖分類號: TN911.7; R445.1

Plane-wave Compounding with Short-lag Coherence Factor Weighting

  • Department of Biomedical Engineering, Hefei University of Technology, Hefei 230009, China

Funds: The National Natural Science Foundation of China (61201060, 61172037)
  • 摘要: 相干平面波復合(CPWC)成像算法采用多個角度平面波成像結果直接疊加的方式進行成像，具有速度快，質量高等優點，CPWC成像直接疊加的成像方式，忽略了平面波成像結果之間的相干性。相干系數(CF)加權算法可以有效提高成像的分辨率和對比度，降低了背景成像質量。該文提出了短階相干系數(SLCF)加權算法，該算法采用角度差異參數來確定相干系數的階數，根據角度差異較小的平面波輸出計算相干系數，對CPWC成像結果進行加權成像。仿真和實驗結果表明SLCF加權算法相對于傳統的CPWC成像算法，可以改善成像的橫向分辨率和對比度。相對CF和廣義相干系數(GCF)算法，SLCF可以提高對比度和背景成像質量，而且運算量更低。
    Abstract: The Coherent Plane-Wave Compounding (CPWC) algorithm is based on the recombination of several plane-waves with different steering angles, which can achieve high-quality images with high frame rate. However, CPWC ignores the coherence between the plane-wave imaging results. Coherence Factor (CF) weighted algorithm can effectively improve the imaging contrast and resolution, while it degrades the background speckle quality. A Short-Lag Coherence Factor (SLCF) algorithm for CPWC is proposed. SLCF uses the angular difference parameter to ascertain the order of the coherence factor and calculates the coherence factor for the plane-waves with small angular difference. Then, SLCF is utilized to weight CPWC to obtain the final images. Simulated and experimental results show that SLCF-weighted algorithm can improve the imaging quality in terms of lateral resolution and Contrast Ratio (CR), compared with CPWC. In addition, in comparison with CF and Generalized Coherence Factor (GCF) weighted algorithm, SLCF can achieve better background speckle quality and it has lower computational complexity.
    • HTML全文

  • 圖  1  散射點的成像結果

    圖  2  (0 mm, 20 mm)處散射點橫向強度變化

    圖  3  斑的仿真成像結果

    圖  5  坐標為(–0.5 mm, 28 mm)處的散射點橫向強度變化

    圖  4  點的實驗成像結果

    圖  6  暗斑的實驗成像結果

    圖  7  人體組織成像結果

    圖  8  人體頸動脈切面成像結果

    表  1  不同算法仿真點的橫向與縱向FWHM及仿真斑的CR, CNR和背景SNR

    算法 橫向FWHM(mm) 縱向FWHM(mm) CR(dB) CNR SSNR
    CPWC 0.540 0.415 30.22\15.96 4.68\2.45 8.52\6.36
    CF 0.443 0.414 38.69\23.02 4.02\2.25 4.37\2.56
    GCF 0.495 0.413 40.64\24.28 5.15\2.60 5.57\2.96
    SLCF(8%) 0.537 0.415 38.00\21.62 5.22\2.31 6.86\3.40
    SLCF(18%) 0.530 0.415 39.86\23.45 5.31\2.46 6.25\3.15
    SLCF(30%) 0.524 0.415 40.48\24.14 5.17\2.48 5.83\3.01
    SLCF(40%) 0.516 0.415 40.29\24.46 4.89\2.50 5.45\2.93
    下載: 導出CSV

    表  2  不同算法實驗點的橫向與縱向FWHM及實驗斑的CR, CNR和背景SNR

    算法 橫向?qū)挾?mm) 縱向?qū)挾?mm) CR(dB) CNR SSNR
    CPWC 0.550 0.554 24.39\10.16 3.76\1.61 7.50\5.38
    CF 0.477 0.542 31.73\12.64 3.25\1.49 3.56\1.82
    GCF 0.513 0.553 33.38\13.66 4.10\1.64 4.49\1.97
    SLCF(8%) 0.546 0.550 30.20\15.82 3.84\1.89 5.57\2.96
    SLCF(18%) 0.536 0.554 32.71\17.85 4.08\2.10 5.05\2.71
    SLCF(30%) 0.522 0.555 33.63\18.54 4.06\2.17 4.71\2.61
    SLCF(40%) 0.501 0.557 33.72\18.64 3.90\2.14 4.42\2.51
    下載: 導出CSV

    表  3  人體成像數據的CR, CNR和背景SNR

    算法 CR(dB) CNR SSNR
    CPWC 26.33 2.45 3.68
    CF 26.96 1.85 1.99
    GCF 28.28 1.98 2.10
    SLCF(8%) 29.84 2.39 2.79
    SLCF(18%) 28.84 2.10 2.32
    SLCF(30%) 28.23 1.94 2.11
    SLCF(40%) 27.86 1.86 2.01
    下載: 導出CSV
  • MONTALDO G, TANTER M, BERCOFF J, et al. Coherent plane-wave compounding for very high frame rate ultrasonography and transient elastography[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2009, 56(3): 489–506 doi: 10.1109/TUFFC.2009.1067
    BERCOFF J, MONTALDO G, LOUPAS T, et al. Ultrafast compound Doppler imaging: Providing full blood flow characterization[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2011, 58(1): 134–147 doi: 10.1109/TUFFC.2011.1780
    VITI J, VOS H J, DE JONG N, et al. Contrast detection efficacy for plane vs. focused wave transmission[C]. 2014 IEEE International on Ultrasonics Symposium (IUS), Chicago, USA, 2014: 1750–1753.
    SEBASTIEN S, HERVé L, OLIVIER B, et al. Experimental evaluation of spectral-based quantitative ultrasound imaging using plane wave compounding[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2014, 61(11): 1824–1834 doi: 10.1109/TUFFC.2014.006543
    POREE J, GARCIA D, CHAYER B, et al. Non-invasive vascular elastography with plane strain incompressibility assumption using ultrafast coherent compound plane wave imaging[J]. IEEE Transactions on Medical Imaging, 2015, 34(12): 2618–2631 doi: 10.1109/TMI.2015.2450992
    DENARIE B, TANGEN T A, EKROLL I K, et al. Coherent plane wave compounding for very high frame rate ultrasonography of rapidly moving targets[J]. IEEE Transactions on Medical Imaging, 2013, 32(7): 1265–1276 doi: 10.1109/TMI.2013.2255310
    ZHAO Jinxin, WANG Yuanyuan, ZENG Xing, et al. Plane wave compounding based on a joint transmitting-receiving adaptive beamformer[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2015, 62(8): 1440–1452 doi: 10.1109/TUFFC.2014.006934
    TOULEMONDE M, BASSET O, TORTOLI P, et al. Thomson’s multitaper approach combined with coherent plane-wave compounding to reduce speckle in ultrasound imaging[J]. Ultrasonics, 2015, 56: 390–398 doi: 10.1016/j.ultras.2014.09.006
    GASSE M, MILLIOZ F, ROUX E, et al. High-quality plane wave compounding using convolutional neural networks[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2017, 64(10): 1637–1639 doi: 10.1109/TUFFC.2017.2736890
    HOLLMAN K W, RIGBY K W, and O'DONNELL M. Coherence factor of speckle from a multi-row probe[C]. IEEE, Ultrasonics Symposium, Caesars Tahoe, USA, 1999: 1257–1260.
    NILSEN C C and HOLM S. Wiener beamforming and the coherence factor in ultrasound imaging[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2010, 57(6): 1329–1346 doi: 10.1109/TUFFC.2010.1553
    YU Mingyue, LI Yang, MA Teng, et al. Intravascular ultrasound imaging with virtual source synthetic aperture (VSSA) focusing and coherence factor weighting[J]. IEEE Transactions on Medical Imaging, 2017, 36(10): 2171–2178 doi: 10.1109/TMI.2017.2723479
    ZHAO Jinxin, WANG Jin, and WANG Yuanyuan. Synthetic aperture ultrasound imaging with classified aperture coherence factors[J]. Journal of Medical Imaging&Health Informatics, 2017, 7(5): 1013–1020 doi: 10.1166/jmihi.2017.21301013
    LI Paichi and LI Menglin. Adaptive imaging using the generalized coherence factor[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2003, 50(2): 128–141.
    WEI G, WANG Y, and YU J. Ultrasound harmonic enhanced imaging using eigenspace-based coherence factor[J]. Ultrasonics, 2016, 72: 106–116 doi: 10.1016/j.ultras.2016.07.017
    WANG Y H and LI P C. SNR-dependent coherence-based adaptive imaging for high-frame-rate ultrasonic and photoacoustic imaging[J]. IEEE Transactions on Ultrasonics Ferroelectrics&Frequency Control, 2014, 61(8): 1419–1432 doi: 10.1109/TUFFC.2014.3051
    LI Y L and DAHL J J. Angular coherence in ultrasound imaging: Theory and applications[J]. Journal of the Acoustical Society of America, 2017, 141(3): 1582–1594 doi: 10.1121/1.4976960
    Plane-wave Imaging challenge in medical ultraSound[OL]. https://www.creatis.insa-lyon.fr/Challenge/IEEE_IUS_2016/, 2016.
    JENSEN J A. Field: A program for simulating ultrasound systems[J]. Medical&Biological Engineering&Computing, 1996, 34(1): 351–353.
    ZHAO Jinxin, WANG Yuanyuan, YU Jinhua, et al. Short-lag spatial coherence ultrasound imaging with adaptive synthetic transmit aperture focusing[J]. Ultrason Imaging, 2017, 39(4): 224–239 doi: 10.1177/0161734616688328
