雷達目標三維散射中心位置正向推導和分析

張磊,  何思遠,  朱國強,  張?jiān)迫A,  殷紅成,  閆華

張磊, 何思遠, 朱國強, 張?jiān)迫A, 殷紅成, 閆華. 雷達目標三維散射中心位置正向推導和分析[J]. 電子與信息學報, 2018, 40(12): 2854-2860. doi: 10.11999/JEIT180115
引用本文: 張磊, 何思遠, 朱國強, 張?jiān)迫A, 殷紅成, 閆華. 雷達目標三維散射中心位置正向推導和分析[J]. 電子與信息學報, 2018, 40(12): 2854-2860. doi: 10.11999/JEIT180115
Lei ZHANG, Siyuan HE, Guoqiang ZHU, Yunhua ZHANG, Hongcheng YIN, Hua YAN. Forward Derivation and Analysis for 3-D Scattering Center Position of Radar Target[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2854-2860. doi: 10.11999/JEIT180115
Citation: Lei ZHANG, Siyuan HE, Guoqiang ZHU, Yunhua ZHANG, Hongcheng YIN, Hua YAN. Forward Derivation and Analysis for 3-D Scattering Center Position of Radar Target[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2854-2860. doi: 10.11999/JEIT180115

雷達目標三維散射中心位置正向推導和分析

doi: 10.11999/JEIT180115 cstr: 32379.14.JEIT180115
  • 1.

    武漢大學電子信息學院 ??武漢 ??430072

  • 2.

    電磁散射重點實驗室 ??北京 ??100854

基金項目: 國家自然科學基金(61571333)
詳細信息
    作者簡介:

    張磊：男，1991年生，博士生，研究方向?yàn)槔走_(dá)目標特性及電磁仿真等

    何思遠：女，1982年生，教授，主要研究方向?yàn)橛?jì)算電磁學、雷達目標特性與目標識別等

    朱國強：男，1959年生，教授，長期從事目標電磁散射特性、天線理論與技術等方面的研究

    張?jiān)迫A：男，1981年生，副教授，主要研究方向?yàn)槿斯る姶挪牧显O(shè)計與應用、新型天線理論與應用、電磁散射與目標特性等

    殷紅成：男，1967年生，研究員，長期從事電磁散射、雷達目標特性、目標識別等方面的研究

    閆華：男，1981年生，高級工程師，主要研究方向?yàn)槟繕?biāo)電磁散射建模與特性分析等

    通訊作者:

    何思遠　 siyuanhe@whu.edu.cn

  • 中圖分類號: TN955

Forward Derivation and Analysis for 3-D Scattering Center Position of Radar Target

  • 1.

    School of Electronic Information, Wuhan University, Wuhan 430072, China

  • 2.

    National Electromagnetic Scattering Laboratory, Beijing 100854, China

Funds: The National Natural Science of China (61571333)
  • 摘要: 為了更好地將散射中心與目標結構聯系起來，該文基于目標幾何模型給出一種在單次和2次耦合散射機理下雷達目標部件級3維散射中心位置正向推算方法。重點探究了2次耦合散射機理下強散射情況的射線等效位置確定原理及方法。對其他弱散射情況，應用等價變換等效為強散射情況。最后，使用此位置推算方法推導并分析了直角二面角，鈍角二面角，SLICY, T72坦克模型的部件級3維散射中心位置，并與相應的仿真或?qū)崪ySAR圖像進行比對以驗證此位置推算方法的正確性。
    Abstract: To link better scattering centers with target structures, a forward method is presented to deduce the component-level 3-D scattering center position of radar target under the mechanisms of single and double scattering based on target geometric model. Under the mechanism of double scattering, the principle and method for determining the ray equivalent position is introduced especially under the situation of strong scattering. As for other weak scattering situations, the equivalent transformation is used to transform the weak scattering situations to the strong one. Finally, this position derivation method is applied to the models of right dihedral angle, obtuse dihedral angle, SLICY and T72 tank to deduce and analyze their component-level scattering center positions. The corresponding simulated or actual SAR images are used for contrast to validate the accuracy of the position derivation method.
    • HTML全文

  • 圖  1  不同入射角下垂直入射直角二面角棱邊俯視示意圖

    圖  2  垂直入射鈍角二面角棱邊示意圖及射線等效位置分布圖

    圖  4  直角二面角仿真SAR圖像

    圖  6  面分離的直角二面角仿真SAR圖像

    圖  3  直角二面角幾何模型圖

    圖  8  面分離的鈍角二面角仿真SAR圖像

    圖  7  面分離的鈍角二面角幾何模型圖

    圖  5  面分離的直角二面角幾何模型圖

    圖  9  SLICY幾何模型及實測SAR圖像與散射中心模型重構SAR圖像對比圖

    圖  10  T72坦克幾何模型及仿真SAR圖像與散射中心模型重構SAR圖像對比圖

    表  1  SLICY實測SAR圖像峰值位置與本文方法推算位置對比表

    散射源編號 1 2 3
    部件 三面角(前右) 頂帽(矮) 頂帽(高)
    機理 3次耦合散射 2次耦合散射 2次耦合散射
    實測圖像八鄰域峰值提取位置 (–0.0173, –1.3806) (–0.2407, –0.0262) (0.6531, –0.6933)
    本文方法推斷投影位置 (–0.0043, –1.2648) (–0.1798, –0.0683) (0.5791, –0.7669)
    位置誤差 (0.0130, 0.1158) (0.0609, 0.0421) (0.0740, 0.0736)
    下載: 導出CSV

    表  2  T72坦克仿真SAR圖像主要峰值位置與本文方法推算位置對比表

    散射源編號 1 2 3 4
    部件 燃料桶(右) 燃料桶(左) 后方擋板(左) 后方擋板(右)
    機理 單次散射 單次散射 單次散射 單次散射
    仿真圖像八鄰域峰值提取位置 (1.0077, –2.0791) (–1.0594, –2.0791) (–0.4393, –3.1312) (0.3876, –3.1312)
    本文方法推斷投影位置 (1.0075, –2.1394) (–1.0022, –2.1394) (–0.4411, –3.1568) (0.4328, –3.1568)
    位置誤差 (0.0002, 0.0603) (0.0572, 0.0603) (0.0018, 0.0256) (0.0452, 0.0256)
    下載: 導出CSV
  • POTTER L C, CHIANG D M, CARRIERE R, et al. A GTD-based parametric model for radar scattering[J]. IEEE Transactions on Antennas and Propagation, 1995, 43(10): 1058–1067 doi: 10.1109/8.467641
    POTTER L C and MOSES R L. Attributed scattering centers for SAR ATR[J]. IEEE Transactions on Image Processing, 1997, 6(1): 79–91 doi: 10.1109/83.552098
    GERRY M J, POTTER L C, GUPTA I J, et al. A parametric model for synthetic aperture radar measurements[J]. IEEE Transactions on Antennas and Propagation, 1999, 47(7): 1179–1188 doi: 10.1109/8.785750
    JACKSON J A, RIGLING B D, and MOSES R L. Canonical scattering feature models for 3D and bistatic SAR[J]. IEEE Transactions on Aerospace and Electronic Systems, 2010, 46(2): 525–541 doi: 10.1109/TAES.2010.5461639
    BHALLA R, LING H, MOORE J, et al. 3D scattering center representation of complex targets using the shooting and bouncing ray technique: A review[J]. IEEE Antennas and Propagation Magazine, 1998, 40(5): 30–39 doi: 10.1109/74.735963
    CHIANG H C, MOSES R L, and POTTER L C. Model-based classification of radar images[J]. IEEE Transactions on Information Theory, 2000, 46(5): 1842–1854 doi: 10.1109/18.857795
    張靜克, 計科峰, 邢相薇. SAR目標屬性散射中心特征提取與分析[J]. 雷達科學與技術, 2011, 9(3): 207–212 doi: 10.3969/j.issn.1672-2337.2011.03.003

    ZHANG Jingke, JI Kefeng, and XING Xiangwei. Feature extraction and analysis of attributed scattering centers on SAR targets[J]. Radar Science and Technology, 2011, 9(3): 207–212 doi: 10.3969/j.issn.1672-2337.2011.03.003
    段佳, 張磊, 邢孟道, 等. 合成孔徑雷達目標特征提取新方法[J]. 西安電子科技大學學報(自然科學版), 2014, 41(4): 13–19 doi: 10.3969/j.issn.1001-2400.2014.04.003

    DUAN Jia, ZHANG Lei, XING Mengdao, et al. Novel feature extraction method for synthetic aperture radar targets[J]. Journal of Xidian University, 2014, 41(4): 13–19 doi: 10.3969/j.issn.1001-2400.2014.04.003
    ZHOU Jianxiong, SHI Zhiguang, and FU Qiang. Three-dimensional scattering center extraction based on wide aperture data at a single elevation[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 53(3): 1638–1655 doi: 10.1109/TGRS.2014.2346509
    KOETS M A and MOSES R L. Feature extraction using attributed scattering center models on SAR imagery[J]. SPIE, 1999, 3721: 104–115 doi: 10.1117/12.357628
    MA Conghui, WEN Gongjian, DING Baiyuan, et al. Three-dimensional electromagnetic model-based scattering center matching method for synthetic aperture radar automatic target recognition by combining spatial and attributed information[J]. Journal of Applied Remote Sensing, 2016, 10(1): 016025 doi: 10.1117/1.JRS.10.016025
    MA Conghui, WEN Gongjian, HUANG Xiaohong, et al. Scatterer-based approach to evaluate similarity between 3D em-model and 2D SAR data for ATR[J]. IET Radar,Sonar&Navigation, 2017, 11(2): 254–259 doi: 10.1049/iet-rsn.2016.0123
    DING Baiyuan, WEN Gongjian, ZHONG Jinrong, et al. A robust similarity measure for attributed scattering center sets with application to SAR ATR[J]. Neurocomputing, 2017, 219(C): 130–143 doi: 10.1016/j.neucom.2016.09.007
    文貢堅, 朱國強, 殷紅成, 等. 基于三維電磁散射參數化模型的SAR目標識別方法[J]. 雷達學報, 2017, 6(2): 115–135 doi: 10.12000/JR17034

    WEN Gongjian, ZHU Guoqiang, YIN Hongcheng, et al. SAR ATR based on 3D parametric electromagnetic scattering model[J]. Journal of Radars, 2017, 6(2): 115–135 doi: 10.12000/JR17034
    HE Yang, HE Siyuan, ZHANG Yunhua, et al. A forward approach to establish parametric scattering center models for known complex radar targets applied to SAR ATR[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(12): 6192–6205 doi: 10.1109/TAP.2014.2360700
    HE Siyuan, DENG Fangshun, CHEN Haitao, et al. Range profile analysis of the 2-D target above a rough surface based on the electromagnetic numerical simulation[J]. IEEE Transactions on Antennas and Propagation, 2009, 57(10): 3258–3263 doi: 10.1109/TAP.2009.2028632
