基于迭代并行干擾消除的低復雜度大規模MIMO信號檢測算法

申濱; 趙書鋒; 金純

doi:10.11999/JEIT180111

基于迭代并行干擾消除的低復雜度大規模MIMO信號檢測算法

doi: 10.11999/JEIT180111 cstr: 32379.14.JEIT180111

重慶郵電大學移動通信重點實驗室 ??重慶 ??400065

基金項目: 重慶市科委重點產業共性關鍵技術創新專項(cstc2015zdcy-ztzx40008)

詳細信息

作者簡介:
申濱：男，1978年生，教授，研究方向?yàn)檎J(rèn)知無線電、大規模MIMO等

趙書鋒：男，1991年生，碩士生，研究方向?yàn)榇笠?guī)模MIMO信號檢測

金純：男，1966年生，教授，研究方向?yàn)闊o線通信信號處理、物聯網等

通訊作者:
申濱　 shenbin@cqupt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 3120
- HTML全文瀏覽量: 1181
- PDF下載量: 93
- 被引次數: 0
出版歷程
- 收稿日期: 2018-01-25
- 修回日期: 2018-05-29
- 網絡出版日期: 2018-08-14
- 刊出日期: 2018-12-01

Low Complexity Iterative Parallel Interference Cancellation Detection Algorithms for Massive MIMO Systems

Chongqing Key Laboratory of Mobile Communications, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The Innovation Project of the Common Key Technology of Chongqing Science and Technology Industry (cstc2015zdcy-ztzx40008)

摘要

摘要: 基于干擾消除思想該文提出一種適用于大規模MIMO系統上行鏈路的低復雜度迭代并行干擾消除算法，在算法實現中避免了線性檢測算法所需的高復雜度 $({\cal O}({K^3}))$ 矩陣求逆運算，將復雜度保持在 $({\cal O}({K^2}))$ 。在此基礎上，引入噪聲預測機制，提出一種基于噪聲預測的迭代并行干擾消除算法，進一步提高了硬判決檢測性能?？紤]天線間殘留干擾，將干擾消除思想運用到軟判決中，最后提出一種基于迭代并行干擾消除的低復雜度軟輸出信號檢測算法。仿真結果表明：提出的信號檢測方法的復雜度優于MMSE檢測算法，經過幾次簡單的迭代，算法即快速收斂并獲得接近甚至優于MMSE檢測算法的誤碼率性能。
- 大規模MIMO /
- 低復雜度 /
- 迭代并行干擾消除 /
- 噪聲預測 /
- 軟輸出
Abstract: Based on interference cancellation method, a low complexity Iterative Parallel Interference Cancellation (IPIC) algorithm is proposed for the uplink of massive MIMO systems. The proposed algorithm avoids the high complexity matrix inversion required by the linear detection algorithm, and hence the complexity is maintained only at $({\cal O}({K^2}))$ . Meanwhile, the noise prediction mechanism is introduced and the noise-prediction aided iterative parallel interference cancellation algorithm is proposed to improve further the detection performance. Considering the residual inter-antenna interference, a low-complexity soft output signal detection algorithm is proposed as well. The simulation results show that the complexity of all the proposed signal detection methods are better than that of the MMSE detection algorithm. With only a small number of iterations, the proposed algorithm achieves its performance quite close to or even surpassing that of the MMSE algorithm.
- Massive MIMO /
- Low-complexity /
- Iterative Parallel Interference Cancellation (IPIC) /
- Noise-prediction /
- Soft output

HTML全文

圖 1 算法復雜度對比

下載: 全尺寸圖片幻燈片

圖 3 $128 \times 32$ MIMO系統下BER性能(硬判決)

下載: 全尺寸圖片幻燈片

圖 2 $128 \times 16$ MIMO系統下BER性能(硬判決)

下載: 全尺寸圖片幻燈片

圖 4 信道估計誤差下算法BER性能(硬判決)

下載: 全尺寸圖片幻燈片

圖 6 $128 \times 16$ MIMO系統中各算法軟輸出BER性能

下載: 全尺寸圖片幻燈片

圖 5 $128 \times 32$ MIMO系統中各算法軟輸出BER性能

下載: 全尺寸圖片幻燈片

表 1 基于迭代并行干擾消除算法(IPIC)

　算法1　基于迭代并行干擾消除算法(IPIC)

　輸入: ${{H}},{{y}},{\sigma ^2},K,{T_{{\rm{iter}}}};$

　初始化：

　(1) ${{G}} = {{{H}}^{\rm{H}}}{{H}},{} = {{{H}}^{\rm{H}}}{{y}},{{\hat{ s}}^{(0)}} = {{{D}}^{ - 1}}{{{H}}^{\rm{H}}}$ ${{y}} = \{ \hat s_1^{(0)},\hat s_2^{(0)}, ·\!·\!· ,\hat s_K^{(0)}\} $

　 For $t = 1:{T_{{\rm{iter}}}};$

　　 For $i = 1:K$;
　(2) 更新 $\hat s_i^{(t)} = \hat s_i^{(t - 1)} + \frac{{{b_i} - \displaystyle\sum\nolimits_{j = 1}^{i - 1} {{G_{ij}}} \hat s_j^{(t)} - \displaystyle\sum\nolimits_{j = i}^K {{G_{ij}}} \hat s_j^{(t - 1)}}}{{{G_{ii}}}}$

　(3) 更新 ${{\hat{ s}}^{(t)}} = {\left[ {\hat s_1^{(t)},\hat s_2^{(t)}, ·\!·\!· ,\hat s_{i - 1}^{(t)}}, {Q(\hat s_i^{(t)})}, {\hat s_{i + 1}^{(t - 1)},\hat s_{i + 2}^{(t - 1)}, ·\!·\!· ,\hat s_K^{(t - 1)}}\right]^{\rm{T}}}$

　(4)　　 $i = i + 1$

end for

　(5)　　 $t = t + 1$

　　　end for

　輸出 ${\hat{ s}} = {{\hat{ s}}^{({T_{{\rm{iter}}}})}}$

下載: 導出CSV

表 2 基于噪聲預測的迭代并行干擾消除算法(NP-IPIC)

　算法2　基于噪聲預測的迭代并行干擾消除算法(NP-IPIC)

　輸入: ${{H}},{{y}},{\sigma ^2},K,{T_{{\rm{iter}}}};$

　初始化：

　(1) ${{G}} = {{{H}}^{\rm{H}}}{{H}},{} = {{{H}}^{\rm{H}}}{{y}}$, ${{D}} = {\rm{diag}}({{G}} + {\sigma ^2}{{{I}}_K})$

　　　 ${{\hat{ s}}^{(0)}} = Q({{{D}}^{ - 1}}{{{H}}^{\rm{H}}}{{y}}) = \{ \hat s_1^{(0)},\hat s_2^{(0)}, ·\!·\!· ,\hat s_K^{(0)}\}$

　(2) 對 ${{H}}$列范數進行降序排序，
$o = \arg {\rm{sort}}({\tau _1},{\tau _2}, ·\!·\!· ,{\tau _K}),\ {\tau _k} = \left\| {{{{h}}_k}} \right\|_2^2,\ \forall k = 1,2, ·\!·\!· ,K$

　　　For $t = 1:{T_{{\rm{iter}}}}$;

　　　　For $i = 1:K$;

　(3) 更新
$\hat s_{o(i)}^{(t)} = \hat s_{o(i)}^{(t - 1)} + \frac{{{b_{o(i)}} - \displaystyle\sum\limits_{j = 1}^{i - 1} {{G_{o(i)o(j)}}} \hat s_{o(j)}^{(t)} - \displaystyle\sum\limits_{j = i}^K {{G_{o(i)o(j)}}} \hat s_{o(j)}^{(t - 1)}}}{{{G_{o(i)o(i)}}}}$

　(4) 判斷 $i$是否等于1，如果為1，則計算 $\bar s_{o(1)}^{(t)} = Q\left(\hat s_{o(1)}^{(t)}\right)$, 噪聲
采樣 $\hat n_{o(1)}^{(t)} = \hat s_{o(1)}^{(t)} - \bar s_{o(1)}^{(t)} = \hat s_{o(1)}^{(t)} - \mathbb{Q}\left(\bar s_{o(1)}^{(t)}\right)$, 如果 $i > 1$，跳過
本步驟，執行下一步；
　(5) 更新 ${\hat{ n}} = \frac{{{{a}}_{o(i - 1)}^{\rm{H}}}}{{{{\left\| {{{{a}}_{o(i - 1)}}} \right\|}^2}}}\hat n_{o(i - 1)}^{(t)}$

　(6) $\hat n_{o(i)}^{(t)} = {{{a}}_{o(i)}}{\hat{ n}}$, $\bar s_{o(i)}^{(t)} = Q\left(\hat s_{o(i)}^{(t)} - \hat n_{o(i)}^{(t)}\right)$

　(7) 更新
${{\hat{ s}}^{(t)}} = {[ {\hat s_{o(1)}^{(t)},\hat s_{o(2)}^{(t)}, ·\!·\!· ,\hat s_{o(i - 1)}^{(t)}}, {\bar s_{o(i)}^{(t)}}, {\hat s_{o(i + 1)}^{(t - 1)},\hat s_{o(i + 2)}^{(t - 1)}, ·\!·\!· ,\hat s_{o(K)}^{(t - 1)}}]^{\rm{T}}}$

　(8)　　　 $i = i + 1$

　　　　end for

　(9)　　 $t = t + 1$

　　　end for

　(10) 根據 ${{\hat{ s}}^{({T_{{\rm{iter}}}})}}$中下標進行重新排序得到 ${{\hat{ s}}^{{\rm{final}}}}$

　輸出 ${\hat{ s}} = {{\hat{ s}}^{{\rm{final}}}}$

下載: 導出CSV

表 3 基于迭代并行干擾消除的軟輸出算法(S-IPIC)

　算法3　基于迭代并行干擾消除的軟輸出算法(S-IPIC)

　輸入: ${{H}},{{y}},{\sigma ^2},K,{T_{{\rm{iter}}}};$

　初始化：

　(1) ${G}={H}^{\rm H}{H}, ={H}^{\rm H}{y}$,

${{D}} = {\rm{diag}}({{G}} + {\sigma ^2}{{{I}}_K}) {{\hat{ s}}^{(0)}} = {{{D}}^{ - 1}}{{{H}}^{\rm{H}}}{{y}} = \{ \hat s_1^{(0)},\hat s_2^{(0)}, ·\!·\!· ,\hat s_K^{(0)}\} $

　(2) 估計方差

　　　For $i = 1:K;$
　(3) $V_i^{(0)} = \sum\limits_{{\alpha _n} \in {\cal{Q}}} \Bigr| {\alpha _n} - \hat s_i^{(0)}{\Bigr|^2}P({s_i} = {\alpha _n})$

　　　end for

　　　估計發送信號并計算NPI方差

　　　For $t = 1:{T_{{\rm{iter}}}};$

　　　　For $i = 1:K;$
　(4) 更新
　　　　 $\hat s_i^{(t)} = {\rm{ }}\hat s_i^{(t - 1)} + \frac{{{b_i} - \displaystyle\sum\limits_{j = 1}^{i - 1} {{G_{ij}}} \hat s_j^{(t)} - \displaystyle\sum\limits_{j = i}^K {{G_{ij}}} \hat s_j^{(t - 1)}}}{{{G_{ii}}}}$

　(5) 更新 ${{\hat{ s}}^{(t)}} = {\left[ {\hat s_1^{(t)},\hat s_2^{(t)}, ·\!·\!· ,\hat s_{i - 1}^{(t)}}, {\hat s_i^{(t)}}, {\hat s_{i + 1}^{(t - 1)},\hat s_{i + 2}^{(t - 1)}, ·\!·\!· ,\hat s_K^{(t - 1)}}\right]^{\rm T}}$

　(6) 更新
　　　　 $V_i^{(t)} = \sum\limits_{{\alpha _n} \in {\cal{O}}} | {\alpha _n} - \hat s_i^{(t)}{|^2}P({s_i} = {\alpha _n})$

　(7) 計算等效信道增益和NPI方差

　　 ${\mu _i} = 1$,
　　 ${(\nu _i^{(t)})^2}{\rm{ }} = \frac{1}{{G_{ii}^2}}\left( {\sum\limits_{j = 1}^{i - 1} | {G_{ij}}{|^2}V_j^{(t)} + \sum\limits_{j = i + 1}^K | {G_{ij}}{|^2}V_j^{(t - 1)}} \right) + \frac{{{\sigma ^2}}}{{{G_{ii}}}}$

　(8) 計算SINR ${{\rm Y}_i} = {{\mu _i^2} / {{{(\nu _i^{(t)})}^2}}}$

　(9)　　　 $i = i + 1$

　　　　end for

　(10)　　 $t = t + 1$

　　　end for

　輸出
　　　　 ${L_{i,b}} = {{\rm Y} _i}\left( {\mathop {\min }\limits_{a \in {\cal{O}}_b^0} {{\left| {\frac{{\hat s_i^{(t)}}}{{{\mu _i}}} - a} \right|}^2} - \mathop {\min }\limits_{a' \in {\cal{O}}_b^1} {{\left| {\frac{{\hat s_i^{(t)}}}{{{\mu _i}}} - a'} \right|}^2}} \right)$

下載: 導出CSV

參考文獻(24)

MARZETTA T L. Noncooperative cellular wireless with unlimited numbers of base station antennas[J]. IEEE Transactions on Wireless Communications, 2010, 9(11): 3590–3600 doi: 10.1109/TWC.2010.092810.091092

LU Lu, LI G Y, SWINDLEHURST A L, et al. An overview of massive MIMO: benefits and challenges[J]. IEEE Journal of Selected Topics in Signal Processing, 2014, 8(5): 742–758 doi: 10.1109/JSTSP.2014.2317671

MUMTAZ S, MORGADO A, HUQ K M S, et al. A survey of 5G technologies: regulatory, standardization and industrial perspectives[J]. Digital Communications&Networks, 2017, 4(2): 87–97 doi: 10.1016/j.dcan.2017.09.010

ARAúJO D C, MAKSYMYUK T, ALMEIDA A L F D, et al. Massive MIMO: Survey and future research topics[J]. IET Communications, 2016, 10(15): 1938–1946 doi: 10.1049/iet-com.2015.1091

NGO H Q, LARSSON E G, and MARZETTA T L. Energy and spectral efficiency of very large multiuser MIMO systems[J]. IEEE Transactions on Communications, 2013, 61(4): 1436–1449 doi: 10.1109/TCOMM.2013.020413.110848

曹海燕, 楊敬畏, 方昕, 等. 大規模MIMO系統中基于二對角矩陣分解的低復雜度檢測算法[J]. 電子與信息學報, 2018, 40(2): 416–420 doi: 10.11999/JEIT170399

CAO Haiyan, YANG Jingwei, FANG Xin, et al. Low complexity detection algorithm based on two-diagonal matrix decomposition in massive MIMO systems[J]. Journal of Electronics&Information Technology, 2018, 40(2): 416–420 doi: 10.11999/JEIT170399

WU M, YIN B, VOSOUGHI A, et al. Approximate matrix inversion for high-throughput data detection in the large-scale MIMO uplink[C]. IEEE International Symposium on Circuits and Systems, Beijing, China 2013: 2155–2158.

DATTA T, SRINIDHI N, CHOCKALINGAM A, et al. Random-restart reactive tabu search algorithm for detection in large-MIMO systems[J]. IEEE Communications Letters, 2010, 14(12): 1107–1109 doi: 10.1109/LCOMM.2010.101210.101587

PEREIRA AA J and SAMPAIO-NETO R. A random-list based LAS algorithm for near-optimal detection in large-scale uplink multiuser MIMO systems[C]. WSA 2015; 19th International ITG Workshop on Smart Antennas, Ilmenau, Germany, 2015: 1–5.

WU M, YIN B, WANG G, et al. Large-scale MIMO detection for 3GPP LTE: algorithms and FPGA implementations[J]. IEEE Journal of Selected Topics in Signal Processing, 2014, 8(5): 916–929 doi: 10.1109/JSTSP.2014.2313021

TANG C, LIU C, YUAN L, et al. High precision low complexity matrix inversion based on Newton iteration for data detection in the massive MIMO[J]. IEEE Communications Letters, 2016, 20(3): 490–493 doi: 10.1109/LCOMM.2015.2514281

GAO Xinyu, DAI Linglong, YUEN C, et al. Low-complexity MMSE signal detection based on Richardson method for large-scale MIMO systems[C]. Vehicular Technology Conference, Vancouver, Canada, 2014: 1–5.

DAI Linglong, GAO Xinyu, SU Xin, et al. Low-complexity soft-output signal detection based on gauss–seidel method for uplink multiuser large-scale MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2015, 64(10): 4839–4845 doi: 10.1109/TVT.2014.2370106

QIN Xianbo, YAN Zhiting, and HE Guanghui. A near-optimal detection scheme based on joint steepest descent and jacobi method for uplink massive MIMO systems[J]. IEEE Communications Letters, 2016, 20(2): 276–279 doi: 10.1109/LCOMM.2015.2504506

GAO Xinyu, DAI Linglong, HU Yuting, et al. Matrix inversion-less signal detection using SOR method for uplink large-scale MIMO systems[C]. Global Communications Conference, Austin, USA, 2014: 3291–3295.

YIN B, WU M, CAVALLARO J R, et al. Conjugate gradient-based soft-output detection and precoding in massive MIMO systems[C]. Global Communications Conference, Austin, USA, 2014: 3696–3701.

XUE Ye, ZHANG Chuan, ZHANG Shunqing, et al. Steepest descent method based soft-output detection for massive MIMO uplink[C]. IEEE International Workshop on Signal Processing Systems, Dallas, USA, 2016: 273–278.

FOSCHINI G J. Layered space-time architecture for wireless communication in a fading environment when using multi-element antennas[J]. Bell Labs Technical Journal, 1996, 1(2): 41–59 doi: 10.1002/bltj.2015

FA R and LAMARE R C D. Multi-branch successive interference cancellation for MIMO spatial multiplexing systems: Design, analysis and adaptive implementation[J]. IET Communications, 2011, 5(4): 484–494 doi: 10.1049/iet-com.2009.0843

LI P, LAMARE R C D, and FA R. Multiple feedback successive interference cancellation detection for multiuser MIMO systems[J]. IEEE Transactions on Wireless Communications, 2011, 10(8): 2432–2439 doi: 10.1109/TWC.2011.060811.101962

MANDLOI M, HUSSAIN M A, and BHATIA V. Improved multiple feedback successive interference cancellation algorithms for near-optimal MIMO detection[J]. IET Communications, 2017, 11(1): 150–159 doi: 10.1049/iet-com.2016.0333

MANDLOI M and BHATIA V. Low-complexity near-optimal iterative sequential detection for uplink massive MIMO systems[J]. IEEE Communications Letters, 2017, 21(3): 568–571 doi: 10.1109/LCOMM.2016.2637366

倪興, 王曉湘, 杜娟. 一種新的基于噪聲預測的部分判決反饋MIMO接收算法[J]. 電子與信息學報, 2008, 30(1): 52–54

NI Xing, WANG Xiaoxiang, and DU Juan. A noise-predictive partial decision-feedback detection for MIMO systems[J]. Journal of Electronics&Information Technology, 2008, 30(1): 52–54

WATERS D W and BARRY J R. Noise-predictive decision-feedback detection for multiple-input multiple-output channels[J]. IEEE Transactions on Signal Processing, 2005, 53(5): 1852–1859 doi: 10.1109/TSP.2005.845474
