基于線下估計和線上補償?shù)臅r(shí)間交錯采樣ADC失配誤差補償方法

鄒應全; 吳太龍; 彭榆淞; 孫一航; 劉宜罡; 張翠芳

doi:10.11999/JEIT180098

基于線下估計和線上補償?shù)臅r(shí)間交錯采樣ADC失配誤差補償方法

doi: 10.11999/JEIT180098 cstr: 32379.14.JEIT180098

西南交通大學信息科學與技術學院 ??成都 ??611756

詳細信息

作者簡介:
鄒應全：男，1976年生，博士，副教授，研究方向?yàn)橹悄苄畔⒉杉c處理

吳太龍：男，1991年生，碩士生，研究方向?yàn)橹悄苄畔⑻幚砼c智能控制

彭榆淞：男，1990年生，碩士生，研究方向?yàn)橹悄苄畔⑻幚砼c智能控制

孫一航：男，1994年生，碩士生，研究方向?yàn)闊o線信息傳輸技術

劉宜罡：男，1992年生，碩士生，研究方向?yàn)橹悄苄畔⑻幚砼c智能控制

張翠芳：女，1961年生，博士，教授，研究方向?yàn)橹悄苄畔⑻幚砼c智能控制

通訊作者:
張翠芳　cfzhang_scce@home.swjtu.edu.cn

中圖分類號: TN79+2; TP391
計量
- 文章訪問數: 1765
- HTML全文瀏覽量: 554
- PDF下載量: 61
- 被引次數: 0
出版歷程
- 收稿日期: 2018-01-04
- 修回日期: 2018-10-22
- 網絡出版日期: 2018-10-25
- 刊出日期: 2019-01-01

Method for Compensating Distortion Created by Mismatch Errors in Time-interleaved ADCs Based on Offline Estimation and Online Correction

School of Information Science and Technology, Southwest Jiaotong University, Chengdu 611756, China

摘要

摘要:
該文提出一種改進的時間交錯采樣模數轉換器(TIADC)失配誤差補償方法。系統通過誤差參數和簡化的拉格朗日插值算法分別實現了對偏置、增益的失配誤差補償和采樣時間的失配誤差補償。該補償方法在FPGA中采用低復雜度的定點運算實現，在TIADC硬件平臺中實現了對多通道ADC采樣數據的線上校正。實驗結果表明：所提改進方法在仿真環境下使無雜散動態范圍提升了51 dB，并且在硬件實現過程中使SFDR優化達45 dB。在保持失配誤差估計精度和補償效果優良的前提下，該方法不僅降低了算法的計算復雜度，而且該補償結構不受TIADC通道數目的限制。
- 模數轉換器 /
- 時間交錯采樣 /
- 失配誤差 /
- 補償結構 /
- 定點運算
Abstract:
A improved method is proposed for compensating the distortion created by mismatches in Time-Interleaved Analog-to-Digital Converters (TI ADCs). The error compensation of offset and gain is realized by error parameters, and the error compensation of sampling time is realized by the simplified Lagrange interpolation algorithm. The compensation method is implemented in FPGA with the low complexity of fixed-point algorithm, and the online calibration of multi-channel ADC sampling data is implemented in the TIADC hardware platform. The experimental results show that the proposed method improves the Spurious-Free Dynamic Range (SFDR) of sampling data up to 51 dB in the simulation environment, and optimizes the SFDR up to 45 dB in the process of hardware implementation. Under the premise of maintaining the error estimation precision and compensation effect, this method not only reduces the computational complexity of the algorithm, but also the compensation structure is not limited by the number of TIADC channels.
- Analog-to-Digital Converter /
- Time-interleaved sampling /
- Mismatch errors /
- Compensation structure /
- Fixed-point algorithm

HTML全文

圖 1 TIADC采樣結構

下載: 全尺寸圖片幻燈片

圖 2 偏置失配和增益失配誤差補償結構圖

下載: 全尺寸圖片幻燈片

圖 3 采樣時間失配誤差補償結構圖

下載: 全尺寸圖片幻燈片

圖 4 采樣輸出序列頻譜對比圖

下載: 全尺寸圖片幻燈片

圖 5 Lagrange插值階數$N$與SFDR、輸入信號頻率與采樣頻率比值${f_{\rm{t}}}/{f_{\rm{s}}}$的關系圖

下載: 全尺寸圖片幻燈片

圖 6 硬件失配誤差補償結構運算時間仿真圖

下載: 全尺寸圖片幻燈片

圖 7 定點運算與浮點運算的失配誤差補償頻譜對比圖

下載: 全尺寸圖片幻燈片

圖 8 TIADC系統中失配補償前后輸出數據頻譜對比圖

下載: 全尺寸圖片幻燈片

表 1 失配誤差的真實值與估計值

ADC通道	ADC1	ADC2	ADC3	ADC4	ADC5	ADC6	ADC7	ADC8
G	1.04440	0.95730	0.96170	1.02140	1.00460	0.97110	1.04570	1.02500
$\widehat G$	1.04440	0.95723	0.96150	1.02137	1.00456	0.97081	1.04555	1.02493
O	0.02130	–0.01120	0.04290	0.02940	0.01250	0.02600	–0.03320	–0.03170
$\widehat O$	0.02130	–0.01119	0.04292	0.02940	0.01251	0.02599	–0.03320	–0.03169
T (ps)	0	502	–877	324	–415	1109	757	–496
$\widehat T\; {\rm{(ps)}}$	2	503	–879	324	–417	1112	758	–498

下載: 導出CSV

表 2 本文所改進的誤差估計算法與文獻[11]和文獻[13]中誤差估計算法的相對估計誤差對比(%)

估計方法	偏置誤差的相對估計誤差	增益誤差的相對估計誤差	采樣時間誤差的相對估計誤差
文獻[11]	1.416	0.02	1.29
文獻[13]	0.3	0.0096	1.28
本文改進方法	0.04	0.03	0.48

下載: 導出CSV

表 3 硬件補償電路的FPGA片上邏輯資源消耗情況

資源類型	總組合功能	專用邏輯寄存器	18 bit嵌入式乘法器	存儲容量
資源消耗情況	111/8256	98/8256	5/18	0/165888

下載: 導出CSV

表 4 偏置、增益和采樣時間失配誤差估計值

ADC通道	ADC1	ADC2
$\widehat G$	1.061100	1.061900
$\widehat O\;\left( {\rm{V}} \right)$	–0.057000	0.000053
$\widehat T\;\left( {\rm{ns}} \right)$	1.191200	1.424300

下載: 導出CSV

參考文獻(15)

BLACK W C and HODGES D A. Time interleaved converter arrays[J]. IEEE Journal of Solid-State Circuits, 1980, 15(6): 1022–1029. doi: 10.1109/JSSC.1980.1051512

PETRAGLIA A and MITRA S K. Analysis of mismatch effects among A/D converters in a time-interleaved waveform digitizer[J]. IEEE Transactions on Instrumentation and Measurement, 1991, 40(5): 831–835. doi: 10.1109/19.106306

KUIOSAWA N, KOBAYASHI H, MARUYAMA K, et al. Explicit analysis of channel mismatch effects in time-interleaved ADC systems[J]. IEEE Transactions on Circuits and Systems I, Fundamental Theory and Applications, 2001, 48(3): 261–271. doi: 10.1109/81.915383

VOGEL C. The impact of combined channel mismatch effects in time-interleaved ADCs[J]. IEEE Transactions on Instrumentation and Measurement, 2005, 54(1): 415–427. doi: 10.1109/TIM.2004.834046

LOONEY M. Advanced digital post-processing techniques enhance performance in time-interleaved ADC systems[OL]. http://www.analog.com/cn/analog-dialogue/articles/advanced-digital-post-processing-techniques.html, 2017.1.

BONNETAT A, HODE J M, FERRE G, et al. An adaptive all-digital blind compensation of dual-TIADC frequency response mismatch based on complex signal correlations[J]. IEEE Transactions on Circuits and Systems II, Express Briefs, 2015, 62(9): 821–825. doi: 10.1109/TCSII.2015.2435611

BONNETAT A, HODE J M, FERRE G, et al. Correlation-based frequency-response mismatch compensation of quad-TIADC using real samples[J]. IEEE Transactions on Circuits and Systems II, Express Briefs, 2015, 62(8): 746–750. doi: 10.1109/TCSII.2015.2433472

ELBORNSSON J, GUSTAFSSON F, and EKLUND J E. Blind equalization of time errors in a time-interleaved ADC system[J]. IEEE Transactions on Signal Processing, 2005, 53(4): 1413–1424. doi: 10.1109/TSP.2005.843706

LIU Sujiang, CUI Jiashuai, MA Haixiao, et al. Blind timing error estimation based on the phasic relationship between nonoverlapping frequency points in time-interleaved ADCs[C]. IEEE International Conference on Solid-State and Integrated Circuit Technology, Guilin, China, 2014: 1–3. doi: 10.1109/ICSICT.2014.7021586.

張尚良, 鄒月嫻. TIADC高速數據捕獲和時間失配補償?shù)腇PGA實現[J]. 數據采集與處理, 2011, 26(5): 601–608. doi: 10.3969/j.issn.1004-9037.2011.05.019

ZHANG Shangliang and ZOU Yuexian. FPGA implementation of data acquisition and timing mismatch compensation for TIADC system[J]. Journal of Data Acquisition &Processing, 2011, 26(5): 601–608. doi: 10.3969/j.issn.1004-9037.2011.05.019

劉洋, 刁節濤, 王義楠, 等. 交錯采樣技術中的失配誤差建模與估計[J]. 儀表技術與傳感器, 2015, 12: 132–135. doi: 10.3969/j.issn.1002-1841.2015.12.039

LIU Yang, DIAO Jietao, WANG Yinan, et al. Modeling and identification of channel mismatches in time-interleaved technique[J]. Instrument Technique and Sensor, 2015, 12: 132–135. doi: 10.3969/j.issn.1002-1841.2015.12.039

SEO M, RODWELL M, and MADHOW U. Generalized blind mismatch correction for two-channel time-interleaved ADCs[C]. IEEE International Conference on Acoustics, Speech and Signal Processing, Honolulu, Hawaii, USA, 2007, vol. 3: 1505–1508. doi: 10.1109/ISCAS.2007.378233.

SCHMIDT C A, COUSSEAU J E, FIGUEROA J L, et al. Efficient estimation and correction of mismatch errors in time-interleaved ADCs[J]. IEEE Transactions on Instrumentation and Measurement, 2016, 65(2): 243–254. doi: 10.1109/TIM.2015.2490378

ZOU Yuexian, ZHANG Shangliang, LIM Yongching, et al. Timing mismatch compensation in time-interleaved ADCs based on multichannel Lagrange Polynomial Interpolation[J]. IEEE Transactions on Instrumentation and Measurement, 2011, 60(4): 1123–1131. doi: 10.1109/TIM.2010.2085291

SINDHI S K and PRABHU K M M. Reconstruction of N-th order nonuniformly sampled bandlimited signals using digital filter banks[J]. Digital Signal Processing, 2013, 23(6): 1877–1886. doi: 10.1016/j.dsp.2013.06.004
