基于回波的多子帶SAR系統載頻誤差補償方法研究

方素娟; 李光祚; 張益霏; 郁文賢; 吳一戎

doi:10.11999/JEIT180079

基于回波的多子帶SAR系統載頻誤差補償方法研究

doi: 10.11999/JEIT180079 cstr: 32379.14.JEIT180079

方素娟¹,
李光祚^1, ,,
張益霏²,
郁文賢¹,
吳一戎^{1, 2}

1.
上海交通大學電子信息與電氣工程學院上海 200240
2.
中國科學院電子學研究所北京 100190

詳細信息

作者簡介:
方素娟：女，1970年生，研究員，研究方位為合成孔徑雷達系統、雷達信號處理

李光祚：男，1985年生，博士生，研究方向為合成孔徑雷達與合成孔徑激光雷達信號處理

張益霏：男，1983年生，副研究員，研究方向為雷達系統、高分對地觀測地面應用

郁文賢：男，1964年生，博士，教授，研究方向為雷達目標識別、遙感信息處理、融合導航定位技術

吳一戎：男，1963年生，博士，研究員，中國科學院院士，研究方向為合成孔徑雷達、遙感衛星地面處理與應用系統技術等

通訊作者:
李光祚　 hnyzlgz@163.com

中圖分類號: TN958
計量
- 文章訪問數: 1763
- HTML全文瀏覽量: 726
- PDF下載量: 73
- 被引次數: 0
出版歷程
- 收稿日期: 2018-01-19
- 修回日期: 2018-07-24
- 網絡出版日期: 2018-08-03
- 刊出日期: 2018-12-01

Method for Frequency Error Compensation Based on Raw Data for SAR System with Bandwidth Synthesis

1.
School of Electronic Information and Electrical Engineering, Shanghai Jiaotong University, Shanghai 200240, China
2.
Insititute of Electrics, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 為了提高SAR系統的分辨率，在距離向可以通過發射一系列不同載頻的窄帶信號，通過信號處理的方法實現帶寬合成，進而得到等效大帶寬信號對應的分辨率。為有效實現帶寬合成，要求不同子帶回波的載頻步進值嚴格已知，這在某些實際應用環境中，并不能總是滿足，因而需要從回波數據中直接估計步進值。該文提出一種基于子帶回波數據的載頻誤差估計與補償方法。該方法基于壓縮后子帶回波數據多普勒相位與載頻的關系，對子帶圖像進行干涉處理，提取差分相位，并利用差分相位沿方位向的冗余進行相干積累，獲得以實際載頻步進值為振蕩頻率的單頻信號，進而通過頻譜分析方法得到誤差頻率，并對子帶間相位誤差進行補償。通過該方法，能夠?qū)崿F(xiàn)子帶信號的相干合成，提升了SAR數據成像質量。實驗數據的處理結果驗證了該方法的有效性。
- 高分寬幅SAR /
- 帶寬合成 /
- 子帶頻率誤差 /
- 相位差分 /
- 相干積累
Abstract: To improve the resolution of the SAR system, radar bandwidth should be improved. By means of synthetic bandwidth, wide bandwidth can be achieved with less hardware complexity. For frequency band synthesis SAR system, frequency difference should be accurately known. However, in the real measurement situation, the frequency difference may drift and should be estimated based on the raw data. In this manuscript, an effective method is proposed to estimate the frequency difference error and compensate the phase error. Based on the relation between the interferometric phase of subband echoes and frequency difference, the frequency difference drift is estimated. The interferometry between subband images yields the interferometric image. It is observed that in the yielded image, phase varies with range and the slope is proportional to the frequency difference. Also, the phase is redundant along azimuth. Based on the redundancy along azimuth, a new vector is formed. The vector is a sinusoidal signal with the frequency value corresponding to the relative range shift. Frequency analysis yields the value of the frequency difference error. Based on the proposed method, the SAR image is improved. The effectiveness of the method is verified by processing the real SAR data.
- High Resolution and Wide Swath SAR (HRWS-SAR) /
- Bandwidth synthesis /
- Frequency difference drift /
- Interferometric phase /
- Coherent accumulation

HTML全文

圖 1 距離脈壓效果評估指標隨相位誤差變化情況

下載: 全尺寸圖片幻燈片

圖 2 載頻差估計實驗結果

下載: 全尺寸圖片幻燈片

圖 3 成像實驗結果對比

下載: 全尺寸圖片幻燈片

圖 4 距離剖面對比

下載: 全尺寸圖片幻燈片

圖 5 方法穩健性實驗驗證

下載: 全尺寸圖片幻燈片
