基于小波的穩健光流計算方法

王洪雁,  鄭佳,  裴炳南

王洪雁, 鄭佳, 裴炳南. 基于小波的穩健光流計算方法[J]. 電子與信息學報, 2018, 40(12): 2945-2953. doi: 10.11999/JEIT180077
引用本文: 王洪雁, 鄭佳, 裴炳南. 基于小波的穩健光流計算方法[J]. 電子與信息學報, 2018, 40(12): 2945-2953. doi: 10.11999/JEIT180077
Hongyan WANG, Jia ZHENG, Bingnan PEI. A Robust Optical Flow Calculation Method Based on Wavelet[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2945-2953. doi: 10.11999/JEIT180077
Citation: Hongyan WANG, Jia ZHENG, Bingnan PEI. A Robust Optical Flow Calculation Method Based on Wavelet[J]. Journal of Electronics & Information Technology, 2018, 40(12): 2945-2953. doi: 10.11999/JEIT180077

基于小波的穩健光流計算方法

doi: 10.11999/JEIT180077 cstr: 32379.14.JEIT180077
  • 1.

    大連大學遼寧省北斗高精度位置服務技術工程實驗室 ??大連 ??116622

  • 2.

    大連大學大連市環境感知與智能控制重點實驗室 ??大連 ??116622

基金項目: 國家自然科學基金(61301258, 61271379)，中國博士后科學基金(2016M590218)
詳細信息
    作者簡介:

    王洪雁：男，1979年生，副教授，博士，主要研究方向為MIMO雷達信號處理、毫米波通信、無人機控制

    鄭佳：男，1990年生，碩士生，研究方向為機器視覺、無人機容錯控制

    裴炳南：男，1956年生，教授，博士，博士生導師，主要研究方向為雷達信號處理、毫米波通信

    通訊作者:

    王洪雁　 gglongs@163.com

  • 中圖分類號: TN919.8

A Robust Optical Flow Calculation Method Based on Wavelet

  • 1.

    Liaoning Engineering Laboratory of BeiDou High-precision Location Service, Dalian University, Dalian 116622, China

  • 2.

    Dalian Key Laboratory of Environmental Perception and Intelligent Control, Dalian University, Dalian 116622, China

Funds: The National Natural Science Foundation of China (61301258, 61271379), China Postdoctoral Science Foundation (2016M590218)
  • 摘要: 針對系統誤差導致光流計算穩健性較差及精度較低的問題，該文提出一種基于小波多分辨理論的穩健光流計算方法。所提算法基于小波多尺度分辨率特性，將光照條件變化及傳感器噪聲引起的系統誤差包含進光流計算中以改善光流計算的穩健性及估計精度，并通過總體最小二乘法求解超定小波光流方程組以獲得光流矢量。仿真結果表明，與傳統的Lucas-Kanade算法、Horn-Schunck算法及基于小波的全向圖像光流估計方法相比，所提算法可顯著改善光流估計精度及穩健性。
    Abstract: Focusing on the issue that the systematic errors lead to poor robustness and low accuracy of optical flow calculation, a robust optical flow calculation method is proposed in this paper, which is based on the wavelet multi-resolution theory. With the multi-resolution characteristics of wavelet, the system error caused by variation of illumination conditions and sensor noise is incorporated into the calculation of optical flow to improve the robustness and estimation accuracy. In what follows, the total least square method is used to solve the over-determined wavelet optical flow equations to obtain the optical flow vector. As compared to the traditional Lucas-Kanade approach, Horn-Schunck method and optical flow estimation in omnidirectional images using wavelet approach, simulation results show that the proposed algorithm can significantly improve the accuracy of optical flow estimation and the robustness of the optical flow field.
    • HTML全文

  • 圖  2  慢速運動場景下所得光流

    圖  1  慢速運動場景下采集的連續4幀圖像

    圖  4  快速運動場景下所得光流

    圖  3  快速運動場景下所采集的連續4幀圖片

    圖  5  不同運動場景下相鄰2幀圖像所得光流平均角度誤差、平均角度標準差及絕對平均誤差隨迭代次數變化

    表  2  快速運動下光流性能參數

    算法類型 E F H
    3幀、4幀 4幀、5幀 5幀、6幀 3幀、4幀 4幀、5幀 5幀、6幀 3幀、4幀 4幀、5幀 5幀、6幀
    HS 12.23 12.20 12.27 12.59 12.54 12.57 0.91 0.93 0.90
    LK 8.76 8.75 8.78 9.12 9.08 9.10 0.78 0.76 0.77
    DC 4.89 4.78 4.82 4.35 4.33 4.36 0.34 0.36 0.35
    本文算法 2.08 2.11 2.13 2.47 2.46 2.41 0.26 0.23 0.25
    下載: 導出CSV

    表  1  慢速運動下光流性能參數

    算法類型 E F H
    6幀、7幀 7幀、8幀 8幀、9幀 6幀、7幀 7幀、8幀 8幀、9幀 6幀、7幀 7幀、8幀 8幀、9幀
    HS 11.56 11.48 11.51 12.07 11.98 12.05 0.79 0.76 0.80
    LK 7.64 7.57 7.60 8.39 8.36 8.38 0.68 0.64 0.67
    DC 3.21 3.19 3.34 3.45 3.42 3.47 0.34 0.36 0.32
    本文算法 1.95 1.89 1.94 2.26 2.23 2.25 0.18 0.16 0.17
    下載: 導出CSV

    表  3  求解光流所需時間

    算法類型 慢速運動耗時 快速運動耗時
    6幀、7幀 7幀、8幀 8幀、9幀 3幀、4幀 4幀、5幀 5幀、6幀
    HS光流法 4.42 4.38 4.45 5.58 5.39 5.45
    LK光流法 4.14 4.03 4.18 4.67 4.31 4.46
    DC光流法 3.23 3.19 3.42 3.53 3.42 3.47
    本文算法 2.26 2.24 2.31 2.50 2.46 2.41
    下載: 導出CSV
  • BLESER G and HENDEBY G. Using optical flow as lightweight SLAM alternative[C]. International Symposium on Mixed and Augmented Reality, Orlando, USA, 2009, 175–176. doi: 10.1109/ISMAR.2009.5336475.
    ZHANG Congxuan, Ge Liyue, CHEN Zhen, et al. Guided filtering: Toward edge-preserving for optical flow[J]. IEEE Access, 2018, 6: 26958–26970 doi: 10.1109/ACCESS.2018.2831920
    GOPPERT J, YANTEK S, and HWANG I. Invariant Kalman filter application to optical flow based visual odometry for UAVs[C]. IEEE Ninth International Conference on Ubiquitous and Future Networks, Milan, Italy, 2017: 99–104. doi: 10.1109/ICUFN.2017.7993755.
    PASTOR-MORENO D, SHIN H S, and WALDOCK A. Optical flow localisation and appearance mapping (OFLAAM) for long-term navigation[C]. IEEE International Conference on Unmanned Aircraft Systems, Colorado, USA, 2015: 980–988. doi: 10.1109/ICUAS.2015.7152387.
    CHAMORRO-MARTINEZ J and FERNANDEZ-VALDIVIA J. A new approach to motion pattern recognition and its application to optical flow estimation[J]. IEEE Transactions on Systems Man&Cybernetics Part C, 2006, 37(1): 39–51 doi: 10.1109/TSMCC.2006.876044
    HORN B K P and SCHUNCK B G. Determining optical flow[J]. Artificial Intelligence, 1981, 17(1/3): 185–203 doi: 10.1016/0004-3702(81)90024-2
    LUCAS B D and KANADE T. An iterative image registration technique with an application to stereo vision[C]. International Joint Conference on Artificial Intelligence, Vancouver, Canada, 1981: 674–679.
    DRULEA M and NEDEVSCHI S. Total variation regularization of local-global optical flow[C]. IEEE International Conference on Intelligent Transportation Systems, Washington, DC, USA, 2011: 318–323. doi: 10.1109/ITSC.2011.6082986.
    NIU Yan, XU Zhiwen, CHE Xiangjiu, et al. Dynamically removing false features in pyramidal lucas-kanade registration[J]. IEEE Transactions on Image Processing, 2014, 23(8): 3535–3544 doi: 10.1109/TIP.2014.2331140
    田天, 周兵, 李波, 等. 基于解析小波的光流計算方法[J]. 北京航空航天大學學報, 2003, 29(6): 548–551 doi: 10.13700/j.bh.1001-5965.2003.06.019

    TIAN Tian, ZHOU Bing, LI Bo, et al. Optical flow computation based on analytic wavelet[J]. Journal of Beijing University of Aeronautics and Astronautics, 2003, 29(6): 548–551 doi: 10.13700/j.bh.1001-5965.2003.06.019
    MAGAREY J and KINGSBURY N. Motion estimation using a complex-valued wavelet transform[J]. IEEE Transactions on Signal Processing, 2002, 46(4): 1069–1084 doi: 10.1109/78.668557
    WU Yute, KANADE T, COHN J, et al. Optical flow estimation using wavelet motion model[C]. IEEE International Conference on Computer Vision, Bombay, India, 1998: 992–998. doi: 10.1109/ICCV.1998.710837.
    項學智, 趙春暉. 形態梯度恒常的復值小波光流求解[J]. 哈爾濱工程大學學報, 2008, 29(8): 872–876 doi: 10.3969/j.issn.1006-7043.2008.08.020

    XIANG Xuezhi and ZHAO Chunhui. An estimation of complex wavelet optical flow with invariant morphological gradient[J]. Journal of Harbin Engineering University, 2008, 29(8): 872–876 doi: 10.3969/j.issn.1006-7043.2008.08.020
    DEMONCEAUX C and KACHI-AKKOUCHE D. Optical flow estimation in omnidirectional images using wavelet approach[C]. IEEE International Conference on Computer Vision and Pattern Recognition, Madison, USA, 2003: 71–76. doi: 10.1109/CVPRW.2003.10080.
    SCHAFFRIN B and FELUS Y A. On the multivariate total least-squares approach to empirical coordinate transformations. Three algorithms[J]. Journal of Geodesy, 2008, 82(6): 373–383 doi: 10.1007/s00190-007-0186-5
    NIAZ M T, IMDAD F, KIM S, et al. Total least-square-based receiver for asymmetrically clipped optical-orthogonal frequency divisional multiplexing visible light communication system[J]. IET Optoelectronics, 2017, 11(4): 129–133 doi: 10.1049/iet-opt.2015.0133
    ARTYUSHENKO V M and VOLOVACH V I. The effect of multiplicative noise on probability density function of signal and additive noise[C]. IEEE Workshop on Electronic and Networking Technologies, Moscow, Russia, 2018: 1–5. doi: 10.1109/MWENT.2018.8337270.
    DATESMAN A. Shot noise in radiobiological systems[J]. Journal of Environmental Radioactivity, 2016, 164: 365–368 doi: 10.1016/j.jenvrad.2016.06.017
    CELLA G. Thermal noise correlations and subtraction[J]. Physics Letters A, 2017, 382: 2269–2274 doi: 10.1016/j.physleta.2017.06.026
    SHOU Guofa, XIA Ling, JIANG Mingfeng, et al. Truncated total least squares: A new regularization method for the solution of ECG inverse problems[J]. IEEE Transactions on Bio-medical Engineering, 2008, 55(4): 1327–1335 doi: 10.1109/TBME.2007.912404
    曲付勇, 孟祥偉. 基于約束總體最小二乘方法的到達時差到達頻差無源定位算法[J]. 電子與信息學報, 2014, 36(5): 1075–1081 doi: 10.3724/SP.J.1146.2013.01019

    QU Fuyong and MENG Xiangwei. Source localization using TDOA and FDOA measurements based on constrained total least squares algorithm[J]. Journal of Electronics&Information Technology, 2014, 36(5): 1075–1081 doi: 10.3724/SP.J.1146.2013.01019
    BARRON J L, FLEET D J, and CHEMIN S. Performance of optical flow techniques[C]. IEEE International Conference on Computer Vision and Pattern Recognition, Champaign, USA, 2002: 236–242. doi: 10.1109/CVPR.1992.223269.
