一種寬帶大斜視STOLT插值及距離變標補償方法

王金波; 唐勁松; 張森; 鐘和平

doi:10.11999/JEIT171068

一種寬帶大斜視STOLT插值及距離變標補償方法

doi: 10.11999/JEIT171068 cstr: 32379.14.JEIT171068

^①(海軍工程大學電子工程學院武漢 430033) ^②(海軍工程大學海軍水聲技術研究所武漢 430033)

基金項目:

國家自然科學基金(61671461, 41304015)

詳細信息

作者簡介:
王金波：男，1979年生，講師，博士，研究方向?yàn)楹铣煽讖铰晠刃盘?hào)處理. 唐勁松：男，1964年生，教授，博士生導師，研究方向?yàn)楦缮婧铣煽讖铰晠?、水聲通信技術. 張森：男，1982年生，副研究員，碩士生導師，研究方向?yàn)楦缮婧铣煽讖铰晠群退暥ㄎ? 鐘和平：男，1983年生，助理研究員，研究方向?yàn)楦缮婧铣煽讖铰晠刃盘?hào)處理和并行計算.

中圖分類號: U666.7; TN911.7
計量
- 文章訪問數: 1605
- HTML全文瀏覽量: 240
- PDF下載量: 132
- 被引次數: 0
出版歷程
- 收稿日期: 2017-11-16
- 修回日期: 2018-04-09
- 刊出日期: 2018-07-19

Range Scaling Compensation Method Based on STOLT Interpolation in Broadband Squint SAS Imaging

WANG Jinbo^① TANG Jinsong^② ZHANG Sen^② ZHONG Heping^②

Funds:

The National Natural Science Foundation of China (61671461, 41304015)

摘要

摘要: 針對大斜視合成孔徑聲吶成像問題，該文推導了寬帶大斜視條件下合成孔徑聲吶回波在徑向和方位向2維波數域中的波數譜的解析表達式，指出了Stolt插值需要解決的距離波數譜卷繞以及成像后距離向上目標的相對距離縮小等問題，給出了距離波數譜卷繞時的Stolt插值方法，提出了距離波數變標因子的概念，并通過在距離空域中補償距離波數變標因子引起的距離變標的方法，解決了大斜視角條件下Stolt插值引起的距離變標問題。點目標仿真數據和模擬回波數據處理驗證了該文方法的正確性和有效性。
- 合成孔徑聲吶成像 /
- 寬帶 /
- 斜視 /
- 算法 /
- 距離波數變標因子
Abstract: Considering the problem of large squint synthetic aperture sonar imaging, the analytical expression of the wavenumber spectrum is analyzed in detail in the radial and azimuth wavenumber fields under the wide-band high-squint conditions. The spectrum winding and shrink in the distance wavenumber fields after the Stolt interpolation are pointed out, and the reduced relative distance between the target in the imaging result is also indicated, then the Stolt interpolation method for distance wavenumber spectrum winding is given. The concept of range wavenumber scaling factor is proposed, the method of compensating the scaling factor and the spectrum winding in the distance space are given. Finally, the problem of range scaling caused by Stolt interpolation under large oblique angle is solved by compensating the distance variable in distance space. Point object simulation data and simulated echo data processing verify the correctness and validity of the proposed method.
- Synthetic Aperture Sonar (SAS) imaging、Broadband、Squint、algorithm、Range wavenumber scaling factor /
