輻射式仿真中脈沖雷達ISAR成像等效模擬方法

劉曉斌; 劉進; 劉光軍; 趙鋒; 王國玉

doi:10.11999/JEIT170931

輻射式仿真中脈沖雷達ISAR成像等效模擬方法

doi: 10.11999/JEIT170931 cstr: 32379.14.JEIT170931

^①(國防科技大學電子信息系統復雜電磁環境效應國家重點實驗室長沙 410073) ^②(軍委裝備發展部裝備信息管理中心北京 100034)

基金項目:

國家自然科學基金(61101180, 61401491, 61490692)

詳細信息

作者簡介:
劉曉斌：男，1990年生，博士生，研究方向?yàn)槔走_(dá)信號處理、雷達系統仿真技術. 劉進：男，1981年生，講師，研究方向?yàn)槔走_(dá)極化信息處理、微動目標特征提取與識別、電子信息系統建模與仿真.

中圖分類號: TN959.1
計量
- 文章訪問數: 1157
- HTML全文瀏覽量: 143
- PDF下載量: 58
- 被引次數: 0
出版歷程
- 收稿日期: 2017-10-09
- 修回日期: 2018-03-21
- 刊出日期: 2018-07-19

Equivalent Simulation Method for Pulse Radar ISAR Imaging in Radio Frequency Simulation

LIU Xiaobin^① LIU Jin^① LIU Guangjun^② ZHAO Feng^① WANG Guoyu^①

Funds:

The National Natural Science Foundation of China (61101180, 61401491, 61490692)

摘要

摘要: 脈沖雷達信號廣泛用于逆合成孔徑雷達(ISAR)成像。在輻射式仿真中采用脈沖雷達信號進行ISAR成像時，由于脈寬對應的傳播距離遠大于微波暗室的空間長度，脈沖回波會在發射信號未被完全輻射之前返回接收機，使得收發信號相互耦合，難以得到ISAR圖像。該文提出基于間歇收發的脈沖雷達ISAR成像等效模擬方法，通過將脈沖信號分段發射、分段接收，得到分段稀疏的目標回波。然后，結合壓縮感知與間歇收發回波，重構得到ISAR圖像。根據等效模擬的實現流程，對仿真與實測數據進行分析，結果表明，該等效模擬方法所得ISAR圖像與完整脈沖回波所得圖像基本一致，從而驗證了等效模擬方法的有效性。
- 脈沖雷達 /
- ISAR成像 /
- 壓縮感知 /
- 間歇收發
Abstract: Pulse radar signal is widely used in Inverse Synthetic Aperture Radar (ISAR) imaging. However, because the propagation distance obtained by the pulse width is larger than the size of anechoic chamber, target echo returns before the pulse signal is fully transmitted. As a result, the transmitted and reflected signals are coupled and difficult to be separated for ISAR imaging in Radio Frequency Simulation (RFS). To solve this problem, the equivalent simulation method is proposed for pulse radar ISAR imaging based on Interrupted Transmitting and Receiving (ITR). As the ITR echo is piecewise sparse in time domain, the ISAR image can be reconstructed based on Compressive Sensing (CS). Simulation and real data demonstrate that the ISAR image obtained by the proposed method is consistent with that obtained by the complete pulse radar signal. Therefore, the proposed method is effective for ISAR imaging in RFS.
- Pulse radar、Inverse Synthetic Aperture Radar (ISAR) imaging、Compressive Sensing (CS)、Interrupted Transmitting and Receiving (ITR) /
