頻譜擁擠環境中峰均功率比約束的認知雷達發射波形設計

鄒鯤; 駱艷卜; 李偉; 李海林

doi:10.11999/JEIT170834

頻譜擁擠環境中峰均功率比約束的認知雷達發射波形設計

doi: 10.11999/JEIT170834 cstr: 32379.14.JEIT170834

(空軍工程大學信息與導航學院西安 710077)

基金項目:

國家自然科學基金(61571456)，陜西省自然科學基金(2016JM0644)

詳細信息

作者簡介:
鄒鯤：鄒鯤：男，1976年生，副教授，研究方向為統計信號處理、信號檢測與估計、認知雷達信號處理. 駱艷卜：男，1980年生，講師，研究方向為無線電導航信號處理、雷達信號處理. 李偉：男，1978年生，副教授，研究方向為新體制雷達技術. 李海林：男，1982年生，講師，研究方向為超高速飛行器導航信息處理.

中圖分類號: TN957.51
計量
- 文章訪問數: 1248
- HTML全文瀏覽量: 156
- PDF下載量: 309
- 被引次數: 0
出版歷程
- 收稿日期: 2017-08-30
- 修回日期: 2018-03-02
- 刊出日期: 2018-07-19

Cognitive Radar Waveform Design with A Peak to Average Power Ration Constraint for Spectrally Dense Environments

ZOU Kun LUO Yanbo LI Wei LI Hailin

Funds:

The National Natural Science Foundation of China (61571456), The Natural Science Foundation of Shaanxi Province (2016JM0644)

摘要

摘要: 復雜電磁環境的一個重要特征是頻譜資源受限，合理使用有限的頻譜資源是認知雷達發射波形設計必須考慮的問題。以峰值與平均功率比(PAR)為約束條件，設計認知雷達發射波形，最大化接收數據信噪比(SNR)，最小化波形頻譜在受干擾頻段內功率。該問題是二次約束的多目標優化問題，采用Pareto優化方法，將兩個目標函數通過加權構成一個目標函數，從而構成一個二次約束二次規劃非凸優化問題。進一步采用半定規劃松弛和隨機化方法，可以獲得最優發射波形，其性能與Pareto加權系數和PAR約束條件等有關。計算機仿真分析表明，發射波形設計在SNR和干擾抑制能力方面存在制約關系，并可以通過增大發射機動態范圍進一步改善性能。
- 認知雷達 /
- 波形設計 /
- 頻譜擁擠環境 /
- Pareto優化 /
- 峰均功率比約束
Abstract: The most important characteristic of the complex electromagnetic environment is the limitation of the radio frequency resource. As a result, the smart use of the limiting spectral resource is necessary to the waveform design for the cognitive radar. This paper designs the transmit waveform under the Peak to Average power Ratio (PAR), to maximize the Signal to Noise power Ratio (SNR) at the receiver, and simultaneously, minimize the power of the waveform in the interference frequency bands. The waveform design problem is a quadratically constrained multi-objective optimization problem. Exploiting the Pareto optimization method, the one objective function is obtained by weighted sum of the two ones, and the resultant problem reduces into a Quadratically Constrained Quadratic Program (QCQP). In order to solve it, the SemiDefinite Program (SDP) relaxation and randomization are used to achieve the optimal waveform, whose performance is related to the Pareto weights and the PAR constraint. The computer simulation results show that, there is a restrictive relationship between the SNR and interference suppression ability for the waveform design, and the performance can be improved by increasing the dynamic range of the transmitter.
- Cognitive radar、Waveform design、Spectral dense environment、Pareto optimization、Peak to Average power Ratio (PAR) constraint /

HTML全文

參考文獻(16)

[2] TAYLOR J D. Ultra-wideband Radar Technology[M]. Florida: CRC Press LLC, 2001, Chapter 12.

GRIFFITHS H, WATTS S, and WICKS M. Radar spectrum engineering and management: Technical and regulatory issues[J]. Proceedings of the IEEE, 2015, 103(1): 85-102. doi: 10.1109/JPROC.2014.2365517.

[3] LINDENFELD M J. Sparse frequency transmit and receive waveform design[J]. IEEE Transactions on Aerospace and Electronic System, 2004, 40(3): 851-861. doi: 10.1109/TAES. 2004.1337459.

[4] STINCO P, GRECO M S, and GINI F. Spectrum sensing and sharing for cognitive radars[J]. IET Radar, Sonar and Navigation, 2016, 10(3): 595-602. doi: 10.1049/iet-rsn.2015. 0372.

[5] STINCO P, GRECO M, and GINI F. Cognitive radars in spectrally dense environments[J]. IEEE Aerospace and Electronic Systems Magazine, 2016, 31(10): 20-27. doi: 10.1109/MAES.2016.150193.

[6] BLUNT S D and MOKOLE E L. Overview of radar waveform diversity[J]. IEEE Aerospace and Electronic Systems Magazine, 2016, 31(11): 2-40. doi: 10.1109/MAES.2016. 160071.

[7] AUBRY A, DE MAIO A, PIEZZO M, et al. Radar waveform design in a spectrally crowded environment via nonconvex quadratic optimization[J]. IEEE Transactions on Aerospace and Electronic System, 2014, 50(2): 1138-1152. doi: 10.1109/ TAES.2014.120731.

[8] AI W, HUANG Y, and ZHANG S. New results on Hermitian matrix rank-one decomposition[J]. Mathematical Programming, Series A, 2011, 128(1/2): 253-283. doi: 10.1007 /s10107-009-0304-7.

[9] AUBRY A, DE MAIO A, HUANG Y, et al. A new radar waveform design algorithm with improved feasibility for spectral coexistence[J]. IEEE Transactions on Aerospace and Electronic System, 2015, 50(2): 1029-1038. doi: 10.1109/ TAES.2014.140093.

[10] AUBRY A, CAROTENUTO V, and DE MAIO A. Forcing multiple spectral compatibility constraints in radar waveforms[J]. IEEE Signal Processing, 2016, 23(4): 483-487. doi: 10.1109/LSP.2016.2532739.

[11] LUO Zhiquan, MA WingKin, SO A M, et al. Semidefinite relaxation of quadratic optimization problems, from its practical deployments and scope of applicability to key theoretical results[J]. IEEE Signal Processing Magazine, 2010, 27(3): 20-34. doi: 10.1109/MSP.2010.936019.

[12] GE Peng, CUI Guolong, KARBASI S M, et al. Cognitive radar sequence design under the spectral compatibility requirements[J]. IET Radar, Sonar and Navigation, 2017, 11(5): 759-767. doi: 10.1049/iet-rsn.2016.0239.

[13] AUBRY A, CAROTENUTO V, DE MAIO A, et al. Optimization theory-based radar waveform design for spectrally dense environments[J]. IEEE Aerospace and Electron System Magazine, 2016, 31(12): 14-25. doi: 10.1109 /MAES.2016.150216.

[14] DE MAIO A, PIEZZO M, FARINA A, et al. Pareto-optimal radar waveform design[J]. IET Radar, Sonar and Navigation, 2011, 5(4): 473-482. doi: 10.1049/iet-rsn.2010.0184.

[15] DE MAIO A, HUANG Y, PIEZZO M, et al. Design of optimized radar codes with a peak to average power ratio constraint[J]. IEEE Transactions on Signal Processing, 2011, 59(6): 2683-2697. doi: 10.1109/TSP.2011.2128313.

[16] YU Xianxiang, CUI Guolong, GE Peng, et al. Constrained radar waveform design algorithm for spectral coexistence[J]. Electronics Letters, 2017, 53(8): 558-560. doi: 10.1049/el. 2016.4524.
