一種基于多參數融合的無袖帶式連續血壓測量方法的研究

徐志紅; 方震; 陳賢祥; 覃力; 杜利東; 趙湛; 劉杰昕

doi:10.11999/JEIT170238

一種基于多參數融合的無袖帶式連續血壓測量方法的研究

doi: 10.11999/JEIT170238 cstr: 32379.14.JEIT170238

2.
(中國科學院電子學研究所北京 100190)
3.
(北京天壇醫院北京 100050)

基金項目:

國家自然科學基金(61302033)，北京市自然科學基金(Z16003)，國家重點研發計劃(2016YFC1304302)

計量
- 文章訪問數: 1684
- HTML全文瀏覽量: 177
- PDF下載量: 218
- 被引次數: 0
出版歷程
- 收稿日期: 2017-03-24
- 修回日期: 2017-11-27
- 刊出日期: 2018-02-19

Research About Cuff-less Continuous Blood Pressure Estimation by Multi-parameter Fusion Method

2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
3.
(TianTan Hospital, Beijing 100050, China)

Funds:

The National Natural Science Foundation of China (61302033), The Key Project of Beijing Municipal Natural Science Foundation (Z16003), The National Key Research and Development Project (2016YFC1304302)

摘要

摘要: 針對現有基于脈搏波傳輸時間的無創連續性血壓測量算法精度不高的問題，該文綜合考慮心電信號和血氧容積波與血壓變化的相關性，提出一種基于BP神經網絡的無創連續性血壓測量方法。該文首先利用改進的心電信號算法提取出心電信號的R點，利用差分、閾值的方法提取出血氧容積波的特征參數，再經過特征解析，提取出與血壓相關的15維特征向量，構建基于BP神經網絡的血壓計算模型，計算出逐拍的血壓值。該方法在天壇醫院等單位進行了醫學臨床比對測試，并通過因子分析法分析了15個特征參數的權重比。實驗證明：在預測血壓上，脈搏波傳輸時間的權重，大于相鄰特征點之間的時間信息權重，大于脈搏波面積信息權重，大于脈搏波幅值信息權重；該方法精度優于其它相近方法，單次測量的舒張壓和收縮壓誤差的平均值標準差分別是-1.576.12 mmHg和-0.624.82 mmHg，重復測量誤差的平均值標準差分別是-2.125.10 mmHg和-2.524.41 mmHg。收縮壓和舒張壓的測量精度均達到了BHS血壓標準的Grade A類和AAMI標準。
- 可穿戴式技術 /
- 連續血壓 /
- 多參數融合 /
- 神經網絡
Abstract: For the problem of noninvasive continuous blood pressure algorithm with un-accuracy, a novel multi- parameter fusion algorithm based on BP neural network is proposed, according to the formation from electrocardiogram and photoplethysmograph of arterial blood pressure. The improved Pan Tompkins algorithm is used to extract the R peak of electrocardiogram, and difference-threshold algorithm is used to extract the features points of photo-plethysmograph, and the fifteen feature parameters relative to blood pressure are extracted and used to establish the model of blood pressure to estimate the beat-to-beat systolic blood pressure and diastolic blood pressure. The factor analysis method is used to analyze the weight of each parameter. The results show that the weight order is pulse transit time, time information, photoplethysmography area information, amplitude information and area ratio. The algorithm is tested in the TianTan Hospital, and the meansstandard difference of single measurement errors are respectively -1.576.12 mmHg and -0.624.82 mmHg, the means standard difference, D. of repeated measurement errors are respectively -2.125.10 mmHg and -2.524.41 mmHg, for systolic blood pressure and diastolic blood pressure. And the measurement accuracy for systolic blood pressure and diastolic blood pressure reaches Grade A of BHS standard and AAMI standard.
- Wearable technology /
- Continuous blood pressure /
- Multi-parameter fusion /
- Neural network
