基于波束域分塊RDLMS的機載外輻射源雷達雜波對消算法

楊鵬程; 呂曉德; 劉宇; 柴致海; 張丹

doi:10.11999/JEIT160595

基于波束域分塊RDLMS的機載外輻射源雷達雜波對消算法

doi: 10.11999/JEIT160595 cstr: 32379.14.JEIT160595

計量
- 文章訪問數: 5255
- HTML全文瀏覽量: 89
- PDF下載量: 356
- 被引次數: 0
出版歷程
- 收稿日期: 2016-06-03
- 修回日期: 2016-10-26
- 刊出日期: 2017-04-19

Clutter Cancellation Algorithm for Airborne Passive Radar Based on Block RDLMS in Beam Domain

摘要

摘要: 針對機載外輻射源雷達多普勒展寬的雜波對消問題，該文首先從降低計算量的角度出發，提出了波束域分塊RDLMS算法。通過波束形成降低了多普勒維對消階數，通過分塊減小了迭代次數并可以利用FFT快速實現。分析表明，所提算法能夠大幅降低雜波對消的計算量，為實時處理提供了支撐。其次，在處理性能方面，由于算法對所有濾波器系數采用相同的步長，當雜噪比較高時會有較大的對消殘余；根據系數比例自適應算法的思想，該文提出了改進算法，對不同的濾波器系數采用不同的步長，步長的大小與濾波器系數的對數成正比。仿真表明，改進算法使雜波對消殘余降低了1.3 dB，對消性能接近理想。
- 機載外輻射源雷達 /
- 雜波對消 /
- 分塊RDLMS /
- 波束域 /
- 步長矩陣
Abstract: For the cancellation of Doppler-spreading clutters of airborne passive radar, firstly, Block RDLMS in beam domain is proposed in order to reduce computational load. In the proposed algorithm, the order of cancellation in Doppler dimension is reduced by beamforming, and the iteration of adaptive processing is reduced by data segmenting, while FFT can be employed. It is verified that the proposed algorithm can reduce computational load substantially, which is valuable for real-time cancellation. Secondly, the improved algorithm is developed based on the idea of proportionate adaptation. Because the same step is assigned to all weights in the proposed algorithm, there will be relatively more residual clutter when the Clutter to Noise Ratio (CNR) is higher. The improved algorithm will assign different steps proportional to the logarithm of corresponding weights. Simulations show that by using the improved algorithm the residual is reduced 1.3dB and the performance of clutter cancellation approaches the ideal case.
- Airborne passive radar /
- Clutter cancellation /
- Block RDLMS /
- Beam domain /
- Step matrix

HTML全文

參考文獻(19)

GRIFFITHS H and BAKER C. Passive coherent location radar systems. Part 1: performance prediction[J]. IEE Proceedings-Radar, Sonar and Navigation, 2005, 152(3): 153-159. doi: 10.1049/ip-rsn:20045082.

DAWIDOWICZ B, KULPA K S, and MALANOWSKI M. Suppression of the ground clutter in airborne PCL radar using DPCA technique[C]. European Radar Conference, Rome, Italy, 2009: 306-309.

BROWN J, WOODBRIDGE K, STOVE A, et al. Air target detection using airborne passive bistatic radar[J]. Electronics Letters, 2010, 46(20): 1396-1397. doi: 10.1049/el.2010.1732.

TAN D K P, LESTURGIE M, SUN H, et al. Target detection performance analysis for airborne passive bistatic radar[C]. IEEE International Geoscience and Remote Sensing Symposium (IGARSS), Honolulu, USA, 2010: 3553-3556. doi: 10.1109/IGARSS.2010.5652159.

KULPA K, MALANOWSKI M, SAMCZYNSKI P, et al. The concept of airborne passive radar[C]. IEEE Microwaves, Radar and Remote Sensing Symposium (MRRS), Kiev, Ukraine, 2011: 267-270. doi: 10.1109/MRRS.2011.6053651.

KULPA K, MALANOWSKI M, SAMCZYNSKI P, et al. On-board PCL systems for airborne platform protection[C]. Tyrrhenian International Workshop on Digital Communications-Enhanced Surveillance of Aircraft and Vehicles (TIWDC/ESAV), Capri, Italy, 2011: 119-122.

BROWN J, WOODBRIDGE K, GRIFFITHS H, et al. Passive bistatic radar experiments from an airborne platform [J]. IEEE Aerospace and Electronic Systems Magazine, 2012, 27(11): 50-55. doi: 10.1109/MAES.2012.6380826.

DAWIDOWICZ B, KULPA K S, MALANOWSKI M, et al. DPCA detection of moving targets in airborne passive radar [J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(2): 1347-1357. doi: 10.1109/TAES.2012.6178066.

DAWIDOWICZ B, SAMCZYNSKI P, MALANOWSKI M, et al. Detection of moving targets with multichannel airborne passive radar[J]. IEEE Aerospace and Electronic Systems Magazine, 2012, 27(11): 42-49. doi: 10.1109/MAES.2012.　6380825.

WU Q, ZHANG Y D, AMIN M G, et al. Space-time adaptive processing in bistatic passive radar exploiting group sparsity[C]. IEEE Radar Conference, Arlington, USA, 2015: 886-890. doi: 10.1109/RADAR.2015.7131120.

RABASTE O and POULLIN D. Rejection of Doppler shifted multipaths in airborne passive radar[C]. IEEE Radar Conference, Arlington, USA, 2015: 1660-1665. doi: 10.1109/ RADAR.2015.7131265.

PALMER J, CRISTALLINI D, and KUSCHEL H. Opportunities and current drivers for passive radar research [C]. IEEE Radar Conference, Johannesburg, Africa, 2015: 145-150. doi: 10.1109/RadarConf.2015.7411870.

BERTHILLOT C, SANTORI A, RABASTE O, et al. Improving BEM channel estimation for airborne passive radar reference signal reconstruction[C]. International Radar Symposium (IRS), Dresden, Germany, 2015: 77-82. doi: 10.1109/IRS.2015.7226351.

AHMADI M J, AMIRI R, and BEHNIA F. Mitigation of range and velocity walk in airborne passive radar with long integration time[C]. Iranian Conference on Electrical Engineering (ICEE), Tehran, Iran, 2015: 514-517. doi: 10.1109/IranianCEE.2015.7146270.

TAN D K P, LESTURGIE M, SUN H, et al. Spacetime interference analysis and suppression for airborne passive radar using transmissions of opportunity[J]. IET Radar, Sonar Navigation, 2014, 8(2): 142-152. doi: 10.1049/iet-rsn. 2013.0190.

萬顯榮, 梁龍, 但陽鵬, 等. 移動平臺外輻射源雷達實驗研究 [J]. 電波科學學報, 2015, 30(2): 383-390. doi: 10.13443/j.cjors. 2014042301.

WAN Xianrong, LIANG Long, DAN Yangpeng, et al. Experimental research of passive radar on moving platform[J]. Chinese Journal of Radio Science, 2015, 30(2): 383-390. doi: 10.13443/j.cjors.2014042301.

劉立剛, FUKUMOTO M, 張世永. 一種變步長Proportionate NLMS自適應濾波算法及其在網絡回聲消除中的應用[J]. 電子學報, 2010, 38(4): 973-978.

LIU Ligang, FUKUMOTO M, and ZHANG Shiyong. A variable step-size Proportionate NLMS adaptive filtering algorithm and its application in network echo cancellation[J]. Acta Electronica Sinica, 2010, 38(4): 973-978.
