太赫茲合成孔徑雷達成像運動補償算法

張群英; 江兆鳳; 李超; 吳世有; 方廣有

doi:10.11999/JEIT160201

太赫茲合成孔徑雷達成像運動補償算法

doi: 10.11999/JEIT160201 cstr: 32379.14.JEIT160201

1.
(中國科學院電子學研究所電磁輻射與探測技術重點實驗室北京 100190) ②(中國科學院大學 北京 100049)

基金項目:

國家高技術研究發展計劃(2015AA8125021)

計量
- 文章訪問數: 1658
- HTML全文瀏覽量: 171
- PDF下載量: 665
- 被引次數: 0
出版歷程
- 收稿日期: 2016-03-03
- 修回日期: 2016-07-01
- 刊出日期: 2017-01-19

Motion Compensation Imaging Algorithm of TeraHertz Synthetic Aperture Radar

1.
(Key Laboratory of Electromagnetic Radiation and Detection Technology, Institute of Electronics,Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National High Technology Research and Development Program of China (2015AA8125021)

摘要

摘要: 合成孔徑雷達(SAR)成像理論分析和工程經驗表明當雷達平臺的運動誤差幅度達到亞波長量級時，會影響圖像的聚焦質量。相對傳統微波SAR，太赫茲合成孔徑雷達(THz-SAR)工作在波長更短的太赫茲頻段，對搭載雷達平臺的穩定性要求更苛刻，需要達到微米級的控制和測量精度，目前的平臺控制和測量技術還不能滿足要求。該文提出一種基于回波數據的THz-SAR成像運動補償算法，通過慣性測量單元輸出的姿態信息完成由運動誤差引起的距離徙動的校正，結合天線方向圖和粗聚焦圖像中特顯點的最大幅值估計最優位置并構建理想回波。利用實際回波和理想回波數據提取由平臺運動誤差引起回波的相位誤差并進行補償，有效地實現了THz-SAR高分辨率成像。采用中心頻率0.2 THz的SAR系統進行室外車載實驗，對目標進行2維高分辨成像，得到角反射器和金屬條的SAR圖像。實驗結果驗證了所提運動補償算法的正確性和有效性。
- 太赫茲合成孔徑雷達 /
- 太赫茲成像 /
- 運動補償算法 /
- 平動誤差
Abstract: Theoretical analysis and engineering experience of SAR imaging shows that radar platforms motion error will affect the quality of the image if its amplitude is greater than sub wavelength. Compared with traditional SAR working in microwave frequency band, TeraHertz SAR (THz-SAR) works in a shorter wavelength as the TeraHertz band, the control and measure accuracy of radar platforms motion should be micron dimension, but the current technology can not meet the requirements. A novel motion compensation algorithm for THz-SAR imaging based on echo data is proposed in this paper. The attitude information from the inertial measurement unit is used to calibrate the migration error caused by the motion. Firstly, an obvious point like object is found in the coarse focusing image and the optimal position of this point is estimated by combining the antenna pattern and the maximum echos amplitude. Then the ideal echo of this point object is generated using the above estimated position and the phase error caused by the motion error of the platform is extracted by comparing the actual echo and the ideal echo. The extracted phase error is used to compensate the motion error of platform. The SAR system with center frequency 0.2 THz is used to carry out the outdoor vehicle experiment. Two dimensional high resolutions of SAR images of the corner reflectors and the metal strips are achieved. The validity of the proposed motion compensation algorithm is proved by experimental results.
- TeraHertz Synthetic Aperture Radar (THz-SAR) /
- TeraHertz imaging /
- Motion compensation /
- Translational error

HTML全文

參考文獻(27)

張存林, 張巖, 等. 太赫茲感測與成像[M]. 北京: 國防工業出版社, 2008: 160-164.

ZHANG Cunlin, ZHANG Yan, et al. Terahertz Sensing and Imaging[M]. Beijing: National Defense Industry Press, 2008: 160-164.

徐政五. 基于太赫茲雷達的人體心跳和微動特征檢測方法研究[D]. [博士論文], 電子科技大學, 2014.

XU Zhengwu. The human heartbeat and micro-feature detection based on the THz radar[D]. [Ph.D. dissertation], University of Electronic Science and Technology of China, 2014.

WAHAIA F, KASALYNAS I, VENCKEVICIUS R, et al. Terahertz absorption and reflection imaging of carcinoma- affected colon tissues embedded in paraffin[J]. Journal of Molecular Structure, 2015, 1107: 214-219. doi: 10.1016/j. molstruc.2015.11.048.

BOWMAN T C, El-SHENAWEE M, and CAMPBELL L K. Terahertz imaging of excised breast tumor tissue on paraffin sections[J]. IEEE Transactions on Antennas Propagation, 2015, 63(5): 2088-2097. doi: 10.1109/TAP.2015.2406893.

ANDERSON J P, SHAPIRO M A, TEMKIN R J, et al. Studies of the 1.5-MW 110-GHz gyrotron experiment[J]. IEEE Transactions on Plasma Science, 2004, 32(3): 877-883. doi: 10.1109/TPS.2004.828813.

TOUSI Y and AFSHARI E. A high-power and scalable 2-D phased array for terahertz CMOS integrated systems[J]. IEEE Journal of Solid-State Circuits, 2015, 50(2): 597-609. doi: 10.1109/JSSC.2014.2375324.

PHILIPP M, GRAF U U, WAGNER-GENTNER A, et al. Compact 1.9 THz BWO local-oscillator for the GREAT heterodyne receiver[J]. Infrared Physics Technology, 2007, 51(1): 54-59. doi: 10.1016/j.infrared.2006.10.034.

VENDIK I B, VENDIK O G, ODIT M A, et al. Tunable metamaterials for controlling THz radiation[J]. IEEE Transactions on Terahertz Science Technology, 2012, 2(5): 538-549. doi: 10.1109/TTHZ.2012.2209878.

GOYETTE T M, DICKINSON J C, WALDMAN J, et al. A 1.56 THz compact radar range for W-Band imagery of scale-model tactical targets[J]. Proceedings of SPIE-The International Society for Optical Engineering, 2000, 4053: 615-622. doi: 10.1117/12.396372.

DENGLER R J, COOPER K B, CHATTOPADHYAY G, et al. 600 GHz imaging radar with 2 cm range resolution[C]. IEEE MTT-S International Microwave Symposium, Honolulu, Hawaii, USA, 2007: 1371-1374. doi: 10.1109/ MWSYM.2007.380468.

GILL J, LEE C, CHATTOPADHYAY G, et al. Array technology for terahertz imaging[C]. Passive and Active Millimeter-Wave Imaging XV, Baltimore, Maryland, USA, 2012: 836202. doi: 10.1117/12.920497.

成彬彬, 江舸, 陳鵬, 等. 0.67 THz高分辨力成像雷達[J]. 太赫茲科學與電子信息學報, 2013, 11(1): 7-11.

CHENG Binbin, JIANG Ge, CHEN Peng, et al. 0.67 THz high resolution imaging radar[J]. Journal of Terahertz Science and Electronic Information Technology, 2013, 11(1): 7-11. doi: 10.3788/HPLPB20132506.1577.

GU S, LI C, GAO X, et al. Three-dimensional image reconstruction of targets under the illumination of terahertz Gaussian beam-theory and experiment[J]. IEEE Transactions on Geoscience Remote Sensing, 2013, 51(4): 2241-2249. doi: 10.1109/TGRS.2012.2209892.

蔡英武, 楊陳, 曾耿華, 等. 太赫茲極高分辨力雷達成像試驗研究[J]. 強激光與粒子束, 2012, 24(1): 7-9. doi: 10.3788/ HPLPB20122401.0007.

CAI Yingwu, YANG Chen, ZENG Genghua, et al. Experimental research on high resolution terahertz radar imaging[J]. High Power Laser and Particle Beams, 2012, 24(1): 7-9. doi: 10.3788/HPLPB20122401.0007.

許景周, 張希成. 太赫茲科學技術和應用[M]. 北京: 北京大學出版社, 2007: 80-86.

XU Jingzhou and ZHANG Xicheng. Terahertz Science Technology and Applications[M]. Beijing: Peking University Press, 2007: 80-86.

ZHANG B, PI Y, and LI J. Terahertz imaging radar with inverse aperture synthesis techniques: System structure, signal processing and experiment results[J]. IEEE Sensors Journal, 2015, 15(1): 290-299. doi: 10.1109/JSEN.2014. 2342495.

林華. 無人機載太赫茲合成孔徑雷達成像分析與仿真[J]. 信息與電子工程, 2010, 8(4): 373-377.

LIN Hua. Analysis and simulation of UAV terahertz wave synthetic aperture radar imaging[J]. Information and Electronic Engineering, 2010, 8(4): 373-377.

趙雨露, 張群英, 李超, 等. 視頻合成孔徑雷達振動誤差分析及補償方案研究[J]. 雷達學報, 2015, 4(2): 230-239. doi: 10. 12000/JR14153.

ZHAO Yulu, ZHANG Qunying, LI Chao, et al. Vibration error analysis and motion compensation of video synthetic aperture radar[J]. Journal of Radars, 2015, 4(2): 230-239. doi: 10.12000 /JR14153.

安道祥. 高分辨SAR成像處理研究[D]. [博士論文], 國防科學技術大學研究生院, 2011.

AN Daoxiang. Study on the imaging techniques for high resolution SAR systems[D]. [Ph.D. dissertation], Graduate School of National University of Defense Technology, 2011.
