星載Clos網絡的全分布式容錯調度算法

劉凱; 晏堅; 高曉琳; 陸建華

doi:10.11999/JEIT150944

星載Clos網絡的全分布式容錯調度算法

doi: 10.11999/JEIT150944 cstr: 32379.14.JEIT150944

2.
(清華大學電子工程系北京 100084) ②(清華大學宇航中心北京 100084) ③(清華大學深圳研究生院深圳 518055) ④(北京航天飛行控制中心北京 100094)

基金項目:

國家自然科學基金(91338108, 91438206)，中國電子科技集團校企合作基金(空間互聯網關鍵技術)

計量
- 文章訪問數: 1631
- HTML全文瀏覽量: 148
- PDF下載量: 418
- 被引次數: 0
出版歷程
- 收稿日期: 2015-08-19
- 修回日期: 2016-01-20
- 刊出日期: 2016-06-19

Fully Distributed Fault Tolerant Scheduling for Onboard Clos-network Switching

2.
(Department of Electronic Engineering, Tsinghua University, Beijing 100084, China)

Funds:

The National Natural Science Foundation of China (91338108, 91438206), China Electronics Technology Group School-Enterprise Cooperation Foundation (Key Technology of Space Internet)

摘要

摘要: 針對星載交換結構受空間輻射影響造成的可靠性嚴重下降問題，該文提出了一種支持全分布式調度的三級Clos網絡及其全分布式容錯(Fully Distributed Fault Tolerant, FDFT)調度算法，以提高星載交換結構在交叉點故障下的容錯能力。該Clos網絡的中間級和輸出級采用聯合輸入交叉點隊列，以支持Clos網絡和交換單元內部的全分布式調度。FDFT采用一種分布式故障檢測算法獲得交叉點故障信息?；趯?duì)交叉點故障影響范圍的分析，F(xiàn)DFT在輸入級采用一種容錯信元分發算法，實現無故障路徑的負載均衡。理論分析證明，當任一輸入/輸出級交換單元故障個數不超過(m-n)或所有中間級交換單元故障個數不超過(m-n)時，其中m, n分別為輸入級交換單元輸入、輸出端口數，F(xiàn)DFT能夠達到100%吞吐率。仿真結果進一步驗證，故障隨機發生情況下，F(xiàn)DFT能夠抵抗比故障任意發生情況下更多的故障，且在不同的業務場景下具有良好的吞吐率和時延性能。
- 星載交換 /
- Clos網絡 /
- 全分布式 /
- 容錯調度 /
- 負載均衡
Abstract: For an onboard switching, serious decline in the reliability is induced by the harsh space radiation environment. In this paper, a 3-stage Clos-network supporting fully distributed scheduling and a Fully Distributed Fault Tolerant (FDFT) scheduling algorithm are proposed to improve fault-tolerant ability of an onboard switching. Combined input and output queued architecture is employed in the central and output stages of the proposed Clos-network to support fully distributed scheduling in both the network and switching elements. In FDFT, a distributed fault detection algorithm is employed to obtain the crosspoint fault information. Based on the analysis of the influence of the faults, a fault-tolerant cell dispatching algorithm is proposed in the input stage which achieves load-balancing to fault-free paths. Theoretical analysis demonstrates that 100% throughput is achieved when no more than(m-n) crosspoint faults occur in any input/output module or in all central modules, where m and n are the number of inputs and outputs of input module, respectively. Furthermore, simulation results indicate that, in the case of faults occurring randomly, FDFT tolerates much more faults, and exhibits a good performance in terms of throughput and average cell delay under different traffic scenarios.
- Onboard switching /
- Clos-network /
- Fully distributed /
- Fault-tolerant scheduling /
- Load balancing

HTML全文

參考文獻(19)

BOTTA A and PESCAPE A. On the performance of new generation satellite broadband internet services[J]. IEEE Communications Magazine, 2014, 52(6): 202-209. doi: 10.1109/MCOM.2014.6829965.

JAFF E, PILLAI P, and HU Y. IP multicast receiver mobility support using PMIPv6 in a global satellite network[J]. IEEE Communications Magazine, 2015, 53(3): 30-37. doi: 10.1109/ MCOM.2015.7060479.

COURVILLE N, BISCHI H, and ZENG J. Critical issues of onboard switching in DVB-S/RCS broadband satellite networks[J]. IEEE Wireless Communications, 2005, 12(5): 28-36. doi: 10.1109/MWC.2005.1522101.

SIEGLE F, VLADIMIROVA T, ILSTAD J, et al. Mitigation of radiation effects in SRAM-based FPGAs for space applications[J]. ACM Computing Surveys, 2015, 47(2): 37:1-37:34. doi: 10.1145/2671181.

張茂森, 邱智亮, 高雅, 等. 星上Clos 交換網絡的分治調度算法[J]. 電子與信息學報, 2012, 34(11): 2734-2740. doi: 10.3724/SP.J.1146.2012.00553.

ZHANG M, QIU Z, GAO Y, et al. Divide-and-conquer dispatching scheme for satellite clos-network switches[J]. Journal of Electronics Information Technology, 2012, 34(11): 2734-2740. doi: 10.3724/SP.J.1146.2012.00553.

KAO Y H and CHAO H J. Design of a bufferless photonic clos network-on-chip architecture[J]. IEEE Transactions on Computers, 2014, 63(3): 764-776. doi: 10.1109/TC.2012.250.

YANG Y and WANG J. A fault-tolerant rearrangeable permutation network[J]. IEEE Transactions on Computer, 2004, 53(4): 414-426. doi: 10.1109/TC.2004.1268399.

GAO Y, QIU Z, ZHANG M, et al. Distributed weight matching dispatching scheme in MSM clos-network packet switches[J]. IEEE Communications Letters, 2013, 17(3): 580-583. doi: 10.1109/LCOMM.2013.012213.122552.

高雅, 邱智亮, 張茂森, 等. 基于幀填補的MMM Clos 網絡按序分組交換算法[J]. 電子與信息學報, 2012, 34(11): 2715-2720. doi: 10.3724/SP.J.1146.2012.00617.

GAO Y, QIU Z, ZHANG M, et al. Padded-frame based in-sequence dispatching scheme for memory-memory-memory (MMM) clos-network[J]. Journal of Electronics Information Technology, 2012, 34(11): 2715-2720. doi: 10. 3724/SP.J.1146.2012.00617.

楊君剛, 劉增基, 雒曉卓. 一種新型的三級Clos網絡分布式容錯調度機制[J]. 解放軍理工大學學報: 自然科學版, 2011, 12(3): 217-222.

YANG J, LIU Z, and LUO X. New distributed fault tolerance scheduling algorithm in three-stage clos network[J]. Journal of PLA University of Science and Technology (Natural Science Edition), 2011, 12(3): 217-222.

LI X, ZHOU Z, and HAMDI M. Space-memory-memory architecture for clos-network packet switches[C]. Proceedings of IEEE International Conference on Communications, Seoul, 2005, (2): 1031-1035. doi: 10.1109/ICC.2005.1494505.

YU H, RUEPP S, and BERGER M S. Out-of-sequence prevention for multicast input-queuing space-memory- memory clos-network[J]. IEEE Communications Letters, 2011, 15(7): 761-763. doi: 10.1109/LCOMM.2011.051011. 102535.

KLEBAN J and SUSZYNSKA U. Static dispatching with internal backpressure scheme for SMM clos-network switches [C]. Proceedings of IEEE Symposium on Computers and Communications, Madeira, 2013: 654-658. doi: 10.1109/ ISCC.2013.6755022.

ZHANG M, QIU Z, and GAO Y. Space-memory-memory clos-network switches with in-sequence service[J]. IET Communications, 2014, 8(16): 2825-2833. doi: 10.1049/iet- com.2013.0844.

ROJAS-CESSA R, OKI E, JING Z, et al. CIXB-1: combined input-one-cell-crosspoint buffered switch[C]. Proceedings of IEEE Workshop on High Performance Switching and Routing, Dallas, 2001: 324-329. doi: 10.1109/HPSR.2001.923655.

MCKEOWN N. The iSLIP scheduling algorithm for input- queued switches[J]. IEEE/ACM Transactions on Networking, 1999, 7(2): 188-201. doi: 10.1109/90.769767.
