基于角度參數特定邊界值的旋轉交叉眼干擾容限研究

劉松楊; 董春曦; 朱穎童; 趙國慶; 許錦

doi:10.11999/JEIT150903

基于角度參數特定邊界值的旋轉交叉眼干擾容限研究

doi: 10.11999/JEIT150903 cstr: 32379.14.JEIT150903

基金項目:

中央高?；究蒲袠I(yè)務費專項資金(K5051202026, JB140203)，國家973計劃項目(613181)

計量
- 文章訪問數: 1784
- HTML全文瀏覽量: 190
- PDF下載量: 343
- 被引次數: 0
出版歷程
- 收稿日期: 2015-07-30
- 修回日期: 2015-12-11
- 刊出日期: 2016-04-19

Tolerance Analysis of Rotating Cross-eye Jamming Based on Angle Factor Specific Boundary Value

Funds:

Fundamental Research Funds for Central Universities (K5051202026, JB140203), The National 973 Program of China (613181)

摘要

摘要: 在干擾平臺旋轉或者被不同方向的雷達探測情況下，該文對傳統反向交叉眼和正交四點源反向交叉眼進行了容限分析。在分析過程中引入了角度參數的概念，同時提出角度參數特定邊界值(AFSBV)作為評估兩種方案性能的指標。進一步推導得出角度參數特定邊界值關于相位偏移和幅度增益的閉合解，在干擾平臺旋轉角取值不斷變化時，得出角度參數特定邊界值的最大值。這一結論能指導交叉眼干擾工程實踐中相位和幅度的取值范圍，使系統能滿足所有干擾平臺旋轉或者被不同方向的雷達探測情況。
- 電子戰 /
- 角度欺騙 /
- 交叉眼干擾 /
- 反向陣 /
- 容限分析
Abstract: In the case that the jammer platform rotates or is pointed in all different directions for radar detcting, the tolerance analysis is made between the conventional retrodirective cross-eye and the orthogonal four jamming elements. In the analysis procedure, angle factor is introduced. A new criterion called Angle Factor Specific Boundary Value (AFSBV) is proposed to evaluate the performance of the two scenarios. The closed-form solutions for the phase shift and amplitude gain are derived in the following sections. In the case of rotating jammer platform, the maximum value of angle factor specific boundary value is obtained. The results for the amplitude and phase can satisfy the case that the jammer platform rotates or is pointed in all directions for radar detecting.
- Electronic warfare /
- Angular deception /
- Cross-eye jamming /
- Retrodirective arrays /
- Tolerance analysis

HTML全文

參考文獻(23)

趙國慶. 雷達對抗原理[M]. 西安: 西安電子科技大學出版社, 1999: 169-183.

ZHAO Guoqing. Fundamentals of Radar Countermeasure[M]. Xian: Xidian University Press, 1999: 169-183.

唐琳, 焦淑紅, 齊歡, 等. 一種單脈沖雷達多通道L1正則化波束銳化方法[J]. 電子與信息學報, 2014, 36(9): 2201-2206. doi: 10.3724/SP.J.1146.2013.01742.

TANG Lin, JIAO Shuhong, Qi Huan, et al. A new mono-pulse radar beam sharpening method with multichannel L1 regularization[J]. Journal of Electronics Information Technology, 2014, 36(9): 2201-2206. doi: 10. 3724/SP.J.1146. 2013.01742.

李永禎, 胡萬秋, 陳思偉, 等. 有源轉發式干擾的全極化單脈沖雷達抑制方法研究[J]. 電子與信息學報, 2015, 37(2): 276-282. doi: 10.11999/JEIT140146.

LI Yongzhen, HU Wanqiu, CHEN Siwei, et al. Active repeater jamming suppression using polarimetric monopulse radar[J]. Journal of Electronics Information Technology, 2015, 37(2): 276-282. doi: 10.11999/JEIT140146.

殷紅成, 王超, 黃培康. 雷達目標角閃爍三種表示的內在聯系[J]. 雷達學報, 2014, 3(2): 119-128.

YIN Hongcheng, WANG Chao, and HUANG Peikang. Inherent relations among the three representations of radar target angular glint[J]. Journal of Radars, 2014, 3(2): 119-128.

蘇劍, 宋志勇, 付強, 等. 單脈沖雷達不可分辨目標與誘餌聯合跟蹤方法[J]. 雷達學報, 2015, 4(2): 160-171.

SU Jian, SONG Zhiyong, FU Qiang, et al. Joint tracking method for the unresolved decoy and target with monopulse radar[J]. Journal of Radars, 2015, 4(2): 160-171.

SHERMAN S M. Complex indicated angles applied to unresolved radar targets and multipath[J]. IEEE Transactions on Aerospace and Electronic Systems, 1971, 7(1): 160-170.

HOWARD D D. Radar target angular scintillation in tracking and guidance systems based on echo signal phase front distortion[C]. Proceedings of NEC, 1959, 15: 840-849.

DUNN H J and HOWARD D D. Radar target amplitude, angle, and doppler scintillation from analysis of the echo signal propagating in space[J]. IEEE Transactions on Microwave Theory and Techniques, 1968, 9(9): 715-728.

LARS F. Cross-eye jamming of monopulse radar[C]. International Waveform Diversity and Design Conference, Pisa, Italy, 2007: 209-213.

HARWOOD N M, Dawber N W, King J D, et al. Multiple-element crosseye[J]. IET Radar, Sonar Navigation, 2007, 1(1): 67-73.

SHARP E D and DIAB M. Van atta reflector array[J]. IRE Transactions on Antennas and Propagation, 1960, 8(4): 436-438.

DUPLESSIS W P, ODENDAAL J W, and JOUBERT J. Extended analysis of retrodirective cross-eye jamming[J]. IEEE Transactions on Antennas and Propagation, 2009, 57(9): 2803-2806.

DUPLESSIS W P. A comprehensive investigation of retrodirective cross-eye jamming[D]. [Ph.D. dissertation]. University of Pretoria, 2010.

DUPLESSIS W P, ODENDAAL J W, and JOUBERT J. Tolerance analysis of cross-eye jamming systems[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(1): 740-745.

DUPLESSIS W P, ODENDAAL J W, and JOUBERT J. Platform skin return and retrodirective cross-eye jamming[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(1): 490-501.

DUPLESSIS W P. Limiting apparent target position in skin-return influenced cross-eye jamming[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(3): 2097-2101.

LIU Tianpeng, WEI Xizhang, and LI Lei. Multiple-element retrodirective cross-eye jamming against amplitude- comparison monopulse radar[C]. 2014 12th International Conference on Signal Processing (ICSP), Hangzhou, 2014: 2135-2140.

LIU Songyang, DONG Chunxi, XU Jin, et al. Analysis of rotating cross-eye jamming[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14: 939-942.
