直接體繪制中增強深度感知的網格投影算法
doi: 10.11999/JEIT150303 cstr: 32379.14.JEIT150303
-
1.
(裝備學院研究生管理大隊 北京 101416) ②(裝備學院復雜電子系統仿真實驗室 北京 101416)
基金項目:
國家自然科學基金(61202129)
Enhanced Depth Perception Grid-projection Algorithm for Direct Volume Rendering
-
1.
(Department of Graduate Management, Equipment Academy, Beijing 101416, China)
-
2.
(Science and Technology on Complex Electronic System Simulation Laboratory, Equipment Academy, Beijing 101416, China)
Funds:
The National Natural Science Foundation of China (61202129)
-
摘要: 體繪制技術生成的圖像中丟失了深度信息，已有的增強深度感知方法通常只針對某些結構區域，犧牲其它結構信息的同時又直接修改體繪制算法。面向光線投射體繪制算法，該文提出一種增強深度感知的方法，不直接修改光線投射算法。投影均勻網格到體數據表面，網格跟隨表面變形后經光線投射繪制在結果圖像中，用戶根據變形網格能夠感知圖像中的深度信息。同時，為突顯變形網格所反映的深度信息，對投影后的網格線進行深度相關的著色，并添加投影輔助線以連接不同深度表面上的投影網格。算法在統一計算設備架構下并行執行后，不僅能夠?qū)崟r(shí)生成圖像支持用戶的交互控制，且圖像中增強深度感知的效果明顯，特別是當體數據包含多個分離或者交叉物體時。
-
關鍵詞:
- 體繪制 /
- 深度感知 /
- 網格投影 /
- 并行執行 /
- 統一計算設備架構
Abstract: The depth information in volume data is lost in the image rendered by volume rendering technique. The existing methods of depth perception enhancement only enhance some structures in the volume data at the cost of other structures details, and they directly edit the volume rendering algorithm. For ray-casting algorithm, a method of depth perception enhancement is presented, and it does not directly edit the algorithm. Specifically, an inerratic grid is projected to the surface of volume data, and then the grid changing along surface is rendered in the final image. Users can apperceive the depth information of surface from the changed grid. Meanwhil, two methods are used to enhance the depth information of the grid projection lines, one is coloring the grid lines based on the depth, and the other one is adding accessorial lines to join the grid lines on two surfaces with different depths. When implemented using compute unified device architecture, the image is rendered in real-time under user interaction. The effect of depth perception enhancement in the final image is obvious especially when the volume data contains some disjunct or intersectant objects. -
Zhang Q, Eagleson R, and Peters T M. Volume visualization: A technical overview with a focus on medical applications[J]. Journal of Digital Imaging, 2011, 24(4): 640-664. Kersten-Oertel M, Chen S J, and Collins D L. An evaluation of depth enhancing perceptual cues for vascular volume visualization in neurosurgery[J]. IEEE Transactions on Visualization and Computer Graphics, 2014, 20(3): 391-403. Bruckner S and M. Enhancing depth-perception with flexible volumetric halos[J]. IEEE Transactions on Visualization and Computer Graphics, 2007, 13(6): 1344-1351. Everts M H, Bekker H, Roerdink J B, et al.. Depth-dependent halos: illustrative rendering of dense line data[J]. IEEE Transactions on Visualization and Computer Graphics, 2009, 15(6): 1299-1306. Soltszv V, Patel D, and Viola I. Chromatic shadows for improved perception[C]. Proceedings of the ACM SIGGRAPH/Eurographics Symposium on Non- Photorealistic Animation and Rendering, Vancouver, Canada, 2011: 105-116. Ament M, Sadlo F, Dachsbacher C, et al.. Low-pass filtered volumetric shadows[J]. IEEE Transactions on Visualization and Computer Graphics, 2014, 20(12): 2437-2446. Zheng Lin, Wu Ying-cai, and Ma Kwan-liu. Perceptually- based depth-ordering enhancement for direct volume rendering[J]. IEEE Transactions on Visualization and Computer Graphics, 2013, 19(3): 446-459. Schott M, Grosset A V P, Martin T, et al.. Depth of field effects for interactive direct volume rendering[C]. Proceedings of the Eurographics/IEEE Symposium on Visualization 2011, Bergen, Norway, 2011: 941-950. Berge C S Z, Baust M, Kapoor A, et al.. Predicate-based focus-and-context visualization for 3D ultrasound[J]. IEEE Transactions on Visualization and Computer Graphics, 2014, 20(12): 2379-2387. Bair A S, House D H, and Ware C. Texturing of layered surfaces for optimal viewing[J]. IEEE Transactions on Visualization and Computer Graphics, 2006, 12(5): 1125-1132. Bair A and House D. A grid with a view: optimal texturing for perception of layered surface shape[J]. IEEE Transactions on Visualization and Computer Graphics, 2007, 13(6): 1656-1663. 蔣剛毅, 朱亞培, 郁梅, 等. 基于感知的視頻編碼方法綜述[J]. 電子與信息學報, 2013, 35(2): 474-483. Jiang Gang-yi, Zhu Ya-pei, Yu Mei, et al.. Perceptual video coding: a survey[J]. Journal of Electronics Information Technology, 2013, 35(2): 474-483. Interrante V, Fuchs H, and Pizer S M. Conveying the 3D shape of smoothly curving transparent surfaces via texture[J]. IEEE Transactions on Visualization and Computer Graphics, 1997, 3(2): 98-117. Xie Jin-rong, Yu Hong-feng, and Ma Kwan-liu. Interactive ray casting of geodesic grids[C]. Proceedings of the Eurographics Conference on Visualization 2013, Leipzig, Germany, 2013: 481-490. 馬千里, 李思昆, 白曉征, 等. CFD非結構化網格格心格式數據高質量體繪制方法[J]. 計算機學報, 2011, 34(3): 508-516. Ma Qian-li, Li Si-kun, Bai Xiao-zheng, et al.. High-quality volume rendering of unstructured-grid cell-centered data in CFD[J]. Chinese Journal of Computers, 2011, 34(3): 508-516. NVIDIA. About CUDA[OL]. https://developer.nvidia.com/ about-cuda, 2015. Rosen P. A visual approach to investigating shared and global memory behavior of CUDA kernels[C]. Proceedings of the Eurographics Conference on Visualization 2013, Leipzig, Germany, 2013: 161-170. Zhang Yu-bo, Dong Zhao, and Ma Kwan-liu. Real-time volume rendering in dynamic lighting environments using precomputed photon mapping[J]. IEEE Transactions on Visualization and Computer Graphics, 2013, 19(8): 1317-1330. 曾理, 倪風岳, 劉寶東, 等. 計算機統一設備架構加速外部計算機斷層圖像重建[J]. 電子與信息學報, 2011, 33(11): 2665-2671. Zeng Li, Ni Feng-yue, Liu Bao-dong, et al.. Image reconstruction of exterior computed tomography accelerated by computer unified device architecture[J]. Journal of Electronics Information Technology, 2011, 33(11): 2665-2671. -
