連續波穿透雷達柱面成像的干涉條紋抑制研究

許圣志; 黃春琳; 劉濤; 覃堯; 陸珉

doi:10.11999/JEIT150274

連續波穿透雷達柱面成像的干涉條紋抑制研究

doi: 10.11999/JEIT150274 cstr: 32379.14.JEIT150274

基金項目:

國家自然基金(61372160)

計量
- 文章訪問數: 1625
- HTML全文瀏覽量: 99
- PDF下載量: 627
- 被引次數: 0
出版歷程
- 收稿日期: 2015-03-04
- 修回日期: 2015-07-07
- 刊出日期: 2015-11-19

A Study of Removing Interference Fringes on Cylindrical Subsurface Imaging with Continuous Wave Penetrating Radar

Funds:

The National Natural Science Foundation of China (61372160)

摘要

摘要: 在進行單頻連續波表層穿透雷達的柱面2維無損檢測成像掃描時，發現明暗相間的條紋現象，這是雷達成像掃描的一種主要干擾，會嚴重降低目標的成像效果。該文簡單分析了曲面干涉條紋的產生機理，并且基于柱面與目標的譜域分布特性差異，提出譜域干涉條紋濾波方法。針對小目標具有較規律的譜域角度分布特性，沿角度進行譜域插值的補償，以消除譜域?yàn)V波丟失目標譜信息的影響。此外，結合波前成像算法，給出了實現簡單、處理高效的譜域?yàn)V波成像處理流程。通過仿真分析和實測數據實驗，結果表明該文方法能夠有效去除柱面的干涉條紋，形成清晰的目標圖像。與傳統的減平均方法的對比證實該文方法更有效。
- 連續波表層穿透雷達 /
- 干涉條紋 /
- 無損檢測 /
- 柱面探測
Abstract: The interference fringe phenomenon appears when continuous wave subsurface penetrating radar is used to image on the uneven surfaces for nondestructive detection. As one of the main disturbances, the fringes will deteriorate the imaging results. The principle of this phenomenon is briefly studied and a filtering method to remove the fringes based on the distribution difference in frequency domain between cylindrical surfaces and target is proposed. Besides, according to the regular angle distribution of small target in frequency domain, a compensatory method by interpolation in a certain angle is studied to optimize the imaging results. Moreover, an effective imaging process for cylindrical subsurface detection based on the wavefront imaging algorithm is illustrated. The numerical and experimental data validate the applicability of proposed method and the results outperform the traditional approach of average subtraction.
- Continuous wave subsurface penetrating radar /
- Interference fringes /
- Nondestructive detection /
- Cylindrical subsurface detection

HTML全文

參考文獻(22)

粟毅, 黃春琳, 雷文太. 探地雷達理論與應用[M]. 北京: 科學出版社, 2006: 210-265.

Su Yi, Huang Chun-lin, and Lei Wen-tai. Theory and Application of Ground Penetrating Radar[M]. Beijing: Science Press, 2006: 210-265.

周琳. 探地雷達成像技術研究[D]. [博士論文], 國防科學技術大學, 2012.

Zhou Lin. Research on ground penetrating radar imaging techniques[D]. [Ph.D. dissertation], National University of Defense Technology, 2012.

金添. 超寬帶SAR淺埋目標成像與檢測的理論和技術研究[D]. [博士論文], 國防科學技術大學, 2007.

Jin Tian. Research on theory and technique of ultra- wideband SAR shallow buried targets imaging and detection[D]. [Ph.D. dissertation], National University of Defense Technology, 2007.

雷文太, 粟毅, 黃仕家. 探地雷達近場三維距離偏移成像算法[J]. 電子與信息學報, 2003, 25(12): 1641-1646.

Lei Wen-tai, Su Yi, and Huang Shi-jia. Ground penetrating radar near field 3-D range migration imaging technique[J]. Journal of Electronics Information Technology, 2003, 25(12): 1641-1646.

Capineri L, Fiesoli F, and Windsor C. Holographic radar: a strategy for uneven surfaces[C]. 14th International Conference on Ground Penetrating Radar (GPR2012), Shanghai, 2012: 143-145.

Huang Chun-lin and Liu Tao. The Impact of an uneven medium surface in holographic penetrating imaging and a method to eliminate the interference[C]. International Technical Conference of IEEE Region 10 (IEEE TENCON2013), Xian, 2013: 1-4.

Sukhanov D and Zavyalova K. Three-dimensional non- contact subsurface radiotomography through a non-planar interface between media[C]. 15th International Conference on Ground Penetrating Radar (GPR2014), Brussels, 2014: 691-695.

Yasemin Altuncu, Ibrahim Akduman, and Ali Yapar. Detecting and locating dielectric objects buried under a rough interface[J]. IEEE Geoscience and Remote Sensing Letters, 2007, 4(2): 251-255.

Selda Yldz, Yasemin Altuncu, Ali Yapar, et al.. On the scattering of electromagnetic waves by periodic rough dielectric surfaces: a BOA solution[J]. IEEE Transactions on Geoscience and Remote Sensing, 2008, 46(9): 2599-2606.

Tolga Ulas Gurbuz, Birol Aslanyurek, Pinar Karabulut E, et al.. An efficient nonlinear imaging approach for dielectric objects buried under a rough surface[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(5): 3013-3022.

Xie Yao, Guo Bin, Xu Lu-zhou, et al.. Multistatic adaptive microwave imaging for early breast cancer detection[J]. IEEE Transactions on Biomedical Engineering, 2006, 53(8): 1647-1657.

Sheen M, McMakin L, and Hall E. Three-dimensional millimeter-wace imaging for concealed weapon detection[J]. IEEE Transactions of Microwave Theory and Techniques, 2001, 49(9): 1581-1592.

Diao Qi-long and Huang Chun-lin. A study of the interference stripe phenomenon caused by electromagnetic wave propagating in multi-layered medium[C]. 14th International Conference on Ground Penetrating Radar (GPR2012), Shanghai, 2012: 780-784.

刁其龍, 黃春琳. 抑制穿過具有傾斜角度的介質探測成像時產生的寄生干涉條紋現象[J]. 物理學報, 2012, 61(21): 1-10.

Diao Qi-long and Huang Chun-lin. Restraining parasitic interference fringe phenomenon in detection imaging through the medium with inclined angle[J]. Acta Physica Sinica, 2012, 61(21): 1-10.

Fu Lei, Liu Si-xin, and Liu Lan-bo. Internal structure characterization of living tree trunk cross-section using gpr: numerical examples and field data analysis[C]. 15th International Conference on Ground Penetrating Radar (GPR2014), Brussels, 2014: 155-160.

Santos-Asssuncao S, perez-Gracia V, Caselles O, et al.. Geophysical exploration of columns in historical heritage buildings[C]. 15th International Conference on Ground Penetrating Radar (GPR2014), Brussels, 2014: 97-102.

Redman J D, Hans G, and Diamanti N. Effect of wood log shape on moisture content measurement using GPR[C]. 15th International Conference on Ground Penetrating Radar (GPR2014), Brussels, 2014: 181-185.
