基于光度立體法的中醫舌體三維表面重建

蔡軼珩,  張琳琳,  盛楠,  張新峰,  王立娜

蔡軼珩, 張琳琳, 盛楠, 張新峰, 王立娜. 基于光度立體法的中醫舌體三維表面重建[J]. 電子與信息學報, 2015, 37(11): 2564-2570. doi: 10.11999/JEIT150124
引用本文: 蔡軼珩, 張琳琳, 盛楠, 張新峰, 王立娜. 基于光度立體法的中醫舌體三維表面重建[J]. 電子與信息學報, 2015, 37(11): 2564-2570. doi: 10.11999/JEIT150124
Cai Yi-heng, Zhang Lin-lin, Sheng Nan, Zhang Xin-feng, Wang Li-na. 3D Reconstruction of Tongue Surface Based on Photometric Stereo Method[J]. Journal of Electronics & Information Technology, 2015, 37(11): 2564-2570. doi: 10.11999/JEIT150124
Citation: Cai Yi-heng, Zhang Lin-lin, Sheng Nan, Zhang Xin-feng, Wang Li-na. 3D Reconstruction of Tongue Surface Based on Photometric Stereo Method[J]. Journal of Electronics & Information Technology, 2015, 37(11): 2564-2570. doi: 10.11999/JEIT150124

基于光度立體法的中醫舌體三維表面重建

doi: 10.11999/JEIT150124 cstr: 32379.14.JEIT150124
基金項目:

國家自然科學基金(61201360)

3D Reconstruction of Tongue Surface Based on Photometric Stereo Method

Funds:

The National Natural Science Foundation of China(61201360)

  • 摘要: 在中醫舌診客觀化研究進程中，以2維舌圖像為基礎進行分析所獲得的舌體特征信息有限，制約了舌診的客觀化發展。在將光度立體法用于靜態舌模型表面3維重建的可行性研究基礎之上，為了對真實舌體表面進行3維重建，該文設計一種舌體3維動態信息采集系統，用于舌像采集；然后采用光度立體法依次求出舌體表面的法向量、紋理反射率和深度信息，并基于DirectX進行3維顯示；最后針對舌體表面高光區域?qū)χ亟ńY(jié)果的影響，采用高光剔除算法剔除高光。經高光剔除后的重建結果和原來相比，在重建精度和魯棒性等方面都有更好的表現。經實驗證實，該重建方法的平均相對誤差約為7.24%，重建結果可形象地表達舌體的表面形態和齒痕等細節信息，可輔助中醫進行診斷。
    Abstract: In the process of the objective research in traditional Chinese medicine tongue diagnosis, the tongue information obtained from the analysis of 2D tongue image is limited. It restricts the development of tongue diagnosis. Based on the feasibility of photometric stereo method to reconstruct the static tongue mode, for reconstructing the 3D surface of the real tongue, a dynamic information collection system is designed for image information acquisition. Then the normal vectors, texture reflectance and depth values are obtained with photometric stereo method, and the 3D surface of tongue is displayed based on DirectX. Finally, a highlight excluding algorithm is used to reduce the effects of the highlight areas on the reconstruction results. After the highlight excluding, it performs better in the reconstruction accuracy and robustness aspects. Experimental results indicate that the average relative error of this algorithm is of 7.24%. The results can express the tongue surface morphology and details such as tooth marks visually.
