電離層閃爍對星載P波段SAR的影響分析
doi: 10.11999/JEIT140948 cstr: 32379.14.JEIT140948
-
2.
(中國電波傳播研究所 青島 266107)
-
3.
(西安電子科技大學物理與光電工程學院 西安 710071)
基金項目:
國家國際科技合作專項(2011DFA22270)資助課題
Effects of Ionospheric Scintillation on P Band Spaceborne SAR
-
1.
(School of Physics and Optoel Ectronic Engineering, Xidian University, Xi&rsquo
-
2.
(China Research Institute of Radiowave Propagation, Qingdao 266107, China)
-
3.
(School of Physics and Optoel Ectronic Engineering, Xidian University, Xi&rsquo
-
摘要: 電離層閃爍會破壞星載合成孔徑雷達(SAR)回波信號之間的相關性，使其成像性能下降。已有的工作都是假設已知電離層電子密度的擾動開展的，但是目前的測量手段無法直接獲取該參量。該文利用海口觀測站超高頻(UHF)頻段太陽活動高年和中等年份的實測數據，分析電離層閃爍的變化特征，并基于相位屏理論，給出一種利用閃爍指數評估電離層閃爍對星載P波段SAR系統影響效應的方法。結果表明：電離層閃爍在低緯地區主要發生在夜間，且在兩分季高發；太陽活動高年，全年約有3.8%的時間會發生電離層閃爍現象；對于P波段SAR系統來說，弱閃爍使得方位向沖激響應函數(IRF)的主瓣寬度和副瓣增益增大，分辨率下降；中等強度閃爍使得方位向沖激響應函數發生嚴重的擾動，副瓣增益增大到主瓣的水平，主瓣中心也發生平移，可能使得系統無法直接成像。
-
關鍵詞:
- 合成孔徑雷達 /
- 電離層閃爍 /
- P波段 /
- 相位屏 /
- 分辨率
Abstract: The ionospheric scintillation can destroy the coherence of SAR echos, and correspondingly degrade SAR imaging performance. The previous studies are conducted under the hypothesis of the given ionospheric electron density irregularities, which are unavailable with the current measurement technologies. In this paper, the characteristics of ionospheric scintillations at low latitudes are analysed by using the observational data of Ultra High Frequency (UHF) band scintillations in the years of high and moderate solar activity at Haikou station. Based on the phase screen theory, a method is proposed to quantify the effects of ionospheric scintillation on P-band spaceborne SAR by using the scintillation index. The results show that the scintillations occur mostly at the night time at low latitudes, especially in equinoxes. The scintillations occur approximately 3.8% during a typical year of high solar activity. For P band SAR, the weak scintillation widens the mainlobe of azimuthal Impulse Response Function (IRF), increases the intensity of sidelobe, and reduces the azimuthal resolution. The moderate scintillation disturbs the IRF seriously, increases the intensity of sidelobe to the degree of mainlobe, and makes the peak of mainlobe shift in azimuthal direction, which can result in the disability of SAR imaging.-
Key words:
- SAR /
- Ionospheric scintillation /
- P band /
- Phase screen /
- Resolution
-
鄧云凱, 趙鳳軍, 王宇. 星載SAR技術的發展趨勢及應用淺析[J].雷達學報, 2012, 1(1): 1-10. Deng Yun-kai, Zhao Feng-jun, and Wang Yu. Brief analysis on the development and application of spaceborne SAR[J]. Journal of Radars, 2012, 1(1): 1-10. Rignot E, Zimmermann J R, and Vanzyl J J. Spaceborne applications of P-band imaging radars for measuring forest biomass[J]. IEEE Transactions on Geoscience and Remote Sensing, 1995, 33(5): 1162-1169. Ishimaru A, Kuga, Y, Liu J, et al.. Ionospheric effects on synthetic aperture radar at 100 MHz to 2 GHz[J]. Radio Science, 1999, 34(1): 257-268. 劉傳保. 電離層對雷達測量精度的影響及校正方法研究[J]. 航天電子對抗, 2013, 29(2): 47-53. Liu Chuan-bao. The effects of ionosphere to radar measurement precision and the correction methods[J]. Aerospace Electronic Warfare, 2013, 29(2): 47-53. Emardson R, Jarlemark P, Johansson J, et al.. Spatial variability in the ionosphere measured with GNSS networks[J]. Radio Science, 2013, 48(5): 646-652. McNamara L F, Caton R G, Parris R T, et al.. Sinnatures of equatorial plasma bubbles in VHF satellite scitillations and equatorial ionograms[J]. Radio Science, 2013, 48(2): 89-101. Franke S J, Liu C H, and Fang D J. Mulrifrequency study of ionospheric scintillation at Ascension island[J]. Radio Science, 1984, 19(3): 695-706. Quegan S and Lamont J. Ionospheric and tropospheric effects on synthetic aperture radar performance[J]. International Journal of Remote Sensing, 1986, 7(4): 525-539. Rogers N C and Quegan S. Simulation of ionospheric effects and their mitigation for the ESA BIOMASS P-band space-based radar[C]. Proceedings of the Ionospheric Effects Symposium, Alexandria, VA, USA, 2011: 13A3-1-13A3-8. Tsynkov S V. On SAR imaging through the earths ionosphere[J]. SIAM Journal on Imaging Sciences, 2009, 2(1): 140-182. Gilman M, Smith E, and Tsynkov S V. Reduction of ionospheric distortions for spaceborne synthetic aperture radar with the help of image registration[J]. Inverse Problems, 2013, 29(5): 054005(1-35). Xu Z W, Wu J, and Wu Z S. Potential effects of the ionosphere on space-based SAR imaging[J]. IEEE Transactions on Antennas and Propagation, 2008, 56(7): 1968-1975. 鄭虎, 李廉林, 李芳. 電離層對星載合成孔徑雷達方位向分辨率影響的分析[J]. 電子與信息學報, 2008, 30(9): 2085-2088. Zheng Hu, Li Lian-lin, and Li Fang. Study about ionospheric effects on spaceborne SAR azimuth imaging[J]. Journal of Electronics Information Technology, 2008, 30(9): 2085-2088. 李力, 楊淋, 張永勝, 等. 電離層不規則體對P波段星載SAR成像的影響[J]. 國防科技大學學報, 2013, 35(5): 158-162. Li Li, Yang Lin, Zhang Yong-sheng, et al.. Effects of ionospheric irregularities on spaceborne P band SAR imaging [J]. Journal of National University of Defense Technology, 2013, 35(5): 158-162. 李亮, 洪峻, 明峰, 等. 電離層時空變化對中高軌SAR成像質量的影響分析[J]. 電子與信息學報, 2014, 36(4): 915-922. Li Liang, Hong Jun, Ming Feng, et al.. Study of ionospheric effects induced by spatio-temporal variability on medium-earth-orbit SAR imaging quality[J]. Journal of Electronics Information Technology, 2014, 36(4): 915-922. Ngwira C M, Klenzing J, Olwendo J, et al.. A study of intense ionospheric scintillation observed during a quiet day in the East African low-latitude region[J]. Radio Science, 2013, 48(4): 396-405. Rino C L. A power law phase screen model for ionospheric scintillation: 1. Weak scatter[J]. Radio Science, 1979, 14(6): 1135-1145. Aarons J. Global morphology of ionospheric scintillations[J]. Proceedings of the IEEE, 1982, 70(4):360－378. 甄衛民, 馮健, 陳麗, 等. 多站多路徑GPS信號研究低緯電離層不均勻體[J]. 電波科學學報, 2007, 22(1): 138-142. Zhen Wei-min, Feng Jian, Chen Li, et al.. Investigation of low-latitude ionospheric irregularities by using multi-station GPS multi-link signals[J]. Chinese Journal of Radio Science, 2007, 22(1): 138-142. -
