一種新穎的樹狀分形超寬帶天線
doi: 10.11999/JEIT140816 cstr: 32379.14.JEIT140816
基金項目:
電子信息系統復雜電磁環境效應國家重點實驗室開放課題基金(CEMEE2014Z0102B)和國家自然科學基金(61001002)資助課題
A Novel Ultra-wideband Fractal Tree-shape Antenna
-
摘要: 該文設計一種新穎的樹狀分形超寬帶天線，該天線采用梯形結構的有限接地面。增加樹狀分形結構的迭代次數和優化有限接地面的形狀可以使天線獲得良好的阻抗匹配，進而實現天線的超寬帶性能。該天線的工作頻帶為4.2~17.5 GHz(相對帶寬為122.6%)，天線的電尺寸為0.350.35，可應用于C波段、X波段、Ku波段和超寬帶(UWB)波段通信，具有廣泛的應用前景。實測結果和仿真結果吻合，證明了該天線的有效性。Abstract: An ultra-wideband fractal antenna is proposed, which has an isosceles trapezoid ground-plane. Increasing fractal iterations and optimizing ground-plane shape can achieve a better impedance matching so as to realize Ultra-WideBand (UWB) antenna performance. The presented fractal antenna offers a -10 dB return loss bandwidth in the range of 4.2 to 17.5 GHz (relative band is 122.6%) with electrical dimension of 0.350.35. Thus, this type of antenna is suitable for C, X, Ku and UWB band communications, which may have a wide application prospect. The measured results fit well with the simulation results, and the effectiveness is validated using the measured results.
-
Key words:
- Fractal antenna /
- Ultra WideBand (UWB) /
- Impedance matching /
- Tree-shape antenna
-
