寬頻帶寬波束磁電偶極子天線設計
doi: 10.11999/JEIT140579 cstr: 32379.14.JEIT140579
基金項目:
國家自然科學基金(61271100, 61471389)和陜西省自然科學基礎研究計劃項目(2012JM8003)資助課題
Broadband and Wide Beam Magneto-electric Dipole Antenna Design
-
摘要: 為了展寬天線的波束寬度，在磁電(ME)偶極子天線的基礎上，該文設計出一種低交叉極化寬頻帶寬波束的新型磁電偶極子天線。通過將振子傾斜彎折，展寬了天線的波束寬度；結合6個寄生振子的對稱加載，提高了輻射方向圖的一致性。在型饋電結構基礎上，優化天線的振子間距和振子長度，實現了天線58.5%的相對帶寬(S11-10 dB)，頻帶范圍為2.3~4.2 GHz；對振子傾斜角度以及寄生振子的參數進行優化，在2.4~4.0 GHz的頻帶內實現了輻射方向圖E面和H面同時達到120以上的半功率波束寬度(HPBW)。測試與仿真有較好的一致性，證明了所設計天線不僅具有寬頻帶寬波束特性，同時在整個頻帶范圍內方向圖的一致性得到了極大地提高。Abstract: In order to broaden the antenna beamwidth, a broadband and wide beam Magneto-Electric (ME) dipole antenna with low polarization is designed based on the conventional ME antenna. By tilting and bending the dipoles, the beam width of the antenna is broadened; the consistency of the radiation pattern is improved by placing 6 parasitic patches symmetrically around the ground center. Optimizing the space between the dipoles and the length of the dipole based on the-shaped feed structure, a relative bandwidth of 58.5% (S11-10 dB) from 2.3~4.2 GHz is achieved. By optimizing the tilting angle and the parameters of the parasitic dipole, the Half Power Beam Width (HPBW) of E-plane and H-plane is simultaneously broadened to 120 in the frequency range from 2.4~4.0 GHz. The measurement results are in good agreement with the corresponding simulation, which not only prove that the broadband and wide beam characteristics of the designed antenna, but also extremely improve the consistency of the radiation pattern through the whole frequency band.
-
Key words:
- Antenna /
- Magneto-Electric (ME) dipole /
- Parasitic monopole /
- Wide beam /
- Broadband /
- Consistency
-
