降低光子晶體諧振腔Q值的方法分析
doi: 10.11999/JEIT140486 cstr: 32379.14.JEIT140486
基金項目:
國家自然科學基金(61372050, 61250008)資助課題
Analysis of the Method to Decrease the Q Value in Photonic Band Gap Cavity
-
摘要: 該文在分析計算金屬光子晶體的正三角形晶格TE模式的色散特性、全局帶隙分布圖的基礎上，針對金屬光子晶體結構諧振腔Q值較高的問題，對降低光子晶體諧振腔Q值的方法進行了分析和設計。采用加載介質柱的混合結構和介質微擾兩種方法分別對諧振腔的Q值進行有效的控制，并分析了兩種方法對諧振腔模式選擇性的影響。結果表明，兩種方法都能在不改變諧振腔模式選擇性和場分布的基礎上有效降低Q值，而介質微擾的方法還同時清除了與TE04競爭的兩種雜模，提高了模式選擇性。
-
關鍵詞:
- 光子帶隙 /
- Q值 /
- 諧振腔 /
- 模式競爭
Abstract: Based on analyzing the dispersion characteristics and global band gaps for general two-dimensional Photonic Band Gap (PBG) structures formed by triangular arrays of metal posts for TE modes, two methods are proposed to solve the problem of the high Q value in PBG cavity. The result shows that the Q value can be effectively controlled by loading media structures or inserting dielectric perturbation in PBG cavity. In consideration of mode competition in PBG cavity, the mode selection is calculated respectively for the two methods. It is shown that the two methods both can control the Q value without reducing the mode selection or changing the electric field distribution of TE04 mode. In addition, two competing modes are cleared in the method of dielectric perturbation, which improves the mode selection at the operation frequency of TE04 mode.-
Key words:
- Photonic Band Gap (PBG) /
- Q value /
- Resonator /
- Mode competition
-
