大規模MIMO系統中聯合用戶分組和聯盟博弈的動態導頻分配方案

智慧; 王飛躍; 黃子菊

doi:10.11999/5EIT190445

大規模MIMO系統中聯合用戶分組和聯盟博弈的動態導頻分配方案

doi: 10.11999/5EIT190445 cstr: 32379.14.5EIT190445

安徽大學計算智能與信號處理教育部重點實驗室合肥 230601

基金項目: 安徽省高校自然科學研究項目(KJ2016A042)

詳細信息

作者簡介:
智慧：女，1984年生，講師，研究方向為大規模MIMO、協作通信和無線傳感器網絡等

王飛躍：男，1989年生，碩士生，研究方向為無線中繼網絡、協作通信、大規模MIMO

黃子菊：女，1993年生，碩士生，研究方向為大規模MIMO、第五代(5G)移動通信系統

通訊作者:
智慧　zhihui_0902@163.com

中圖分類號: TN911.23
計量
- 文章訪問數: 2166
- HTML全文瀏覽量: 1141
- PDF下載量: 64
- 被引次數: 0
出版歷程
- 收稿日期: 2019-06-18
- 修回日期: 2019-09-28
- 網絡出版日期: 2020-01-20
- 刊出日期: 2020-07-23

Dynamic Pilot Allocation Scheme for Joint User Grouping and Alliance Game in Massive MIMO Systems

Ministry of Education Key Laboratory of Computing Intelligent and Signal Processing, Anhui University, Hefei 230601, China

Funds: The College Natural Science Research Project of Anhui Province (KJ2016A042)

摘要

摘要:
大量研究表明，大規模MIMO系統中的小區邊緣用戶比中心用戶更易遭受導頻污染的影響。因此，該文提出一種聯合用戶分組和聯盟博弈(JUG-AG)的動態導頻分配方案來減輕系統導頻污染。根據用戶信號強度將所有用戶分為A，B兩組，把接收基站信號強度弱的小區邊緣用戶記為A組，剩余用戶則為B組。A組用戶使用相互正交的導頻，B組用戶則借助聯盟博弈來重復使用剩余的正交導頻。在B組用戶的聯盟博弈中，用戶被分成若干個互不相交的用戶子聯盟，屬于不同子聯盟的用戶分配不同的相互正交導頻序列，而屬于同一子聯盟中的用戶使用相同的導頻序列。與已有的導頻分配方案相比，該文提出的JUG-AG方案更靈活，可以用于所有用戶隨機分布的場景。而且，該算法通過循環搜索可以獲得整體最優解。仿真結果表明JUG-AG方案能夠有效降低上行鏈路中用戶信號檢測的平均均方根誤差(RMSE)，而且可以提高用戶的平均服務速率。
- 大規模多輸入多輸出 /
- 導頻污染 /
- 均方根誤差 /
- 服務速率 /
- 聯合用戶分組和聯盟博弈
Abstract:
Many researches demonstrate that cell-edge users are more susceptible to pilot contamination than the cell-center users in massive MIMO systems. Therefore, this paper proposes a dynamic pilot allocation scheme called Joint User Grouping and Alliance Game (JUG-AG) to mitigate pilot contamination. According to the user signal strength, the users are divided into two groups, namely A and B. Users with weak strength of received Base Stations (BSs) signals are recorded as group A, and the remaining users are group B. The users of group A use mutually orthogonal pilots, and the users of group B reuse the remaining orthogonal pilots by means of alliance game. In the alliance game for the users of group B, users are divided into several disjoint user sub-alliances, users belonging to different sub-alliances are allocated different orthogonal pilot sequences, and users in the same sub-alliance reuse the same pilot sequence. Compared with the existing pilot allocation schemes, the proposed JUG-AG scheme is more flexible and can be used for scenarios that all users are randomly distributed. Moreover, the algorithm can obtain the overall optimal solution through cyclic searching. The simulation results demonstrate that the JUG-AG scheme can effectively reduce the average Root Mean Square Error (RMSE) of user signal detection in the uplink and improve the average service rate of users.
- Massive MIMO /
- Pilot contamination /
- Root Mean Square Error (RMSE) /
- Service rate /
- Joint User Grouping and Alliance Game (JUG-AG)

HTML全文

圖 1 系統模型與用戶導頻分配方案

下載: 全尺寸圖片幻燈片

圖 2 平均RMSE與$p$, ${M}$, ${\sigma ^2}$間的關系

下載: 全尺寸圖片幻燈片

圖 3 平均RMSE與$q$, $q$與$N$以及平均RMSE與$N$間的關系

下載: 全尺寸圖片幻燈片

圖 4 服務速率與$p$, $M$間的關系

下載: 全尺寸圖片幻燈片

算法1　導頻分配算法

　步驟 1　(用戶分組)：計算所有用戶的${\eta _{iik}}$值，從小到大排序。
根據排序，優選前$q$個值較小的用戶為A組，剩余($N - q$)個用戶為B組。

　步驟 2　(聯盟博弈)：

　初始化：對于B組用戶，給定初始聯盟結構$\lambda = \{ {\lambda _1},{\lambda _2}, ···, {\lambda _{h - q}}\} $，并設當前搜索次數$\zeta = 0$。

　循環：

　(1) 對于所有用戶$(i,k) \in \varPhi \,\,$(即B用戶)，進行循環搜索；

　(2) 對于所有${\lambda _j} \in \{ \{ {\lambda _1},{\lambda _2}, ···, {\lambda _{h - q}}{{\rm \} \backslash }}\Gamma (i,k)\} ,(j = 1,2,···,$　　 $h - q)$，進行查找：

　效用函數為RMSE時，若聯盟調整規則1中兩個條件都滿足，則
　有$\lambda {{\rm = }}\lambda ^0$。同理，效用函數為服務速率時，若聯盟調整規則2中兩
　個條件都滿足，則有$\lambda {{\rm = }}\lambda ^0$。

　否則，聯盟結構保持不變($\lambda {{\rm = }}\lambda $)。

　結束(對應循環2)

　搜索次數增加，即$\zeta = \zeta + 1$，

　結束(對應循環1)

　直到$\lambda \xrightarrow{{(i,k)}}\, \,{\lambda ^0}$的所有條件不成立或$\zeta > \varpi $，循環結束。

　步驟 3　(導頻分配)：A組用戶分配$q$個正交導頻，B組中($N - q$)個用戶根據第2步用戶子聯盟分配的結果將剩余$h - q$個正交導頻依次分配給這$h - q$個用戶子聯盟。

下載: 導出CSV

表 1 仿真參數設置

參數	數值	參數	數值
基站坐標	(4.0,4.0), (5.7,4.0), (2.3,4.0), (4.9,5.5), (3.1,5.5), (4.9,2.5), (3.1,2.5)	最大搜索次數$\varpi $	800
小區數L	7	路徑衰落因子$\upsilon $	3
用戶數N	20	導頻數h	8

下載: 導出CSV

參考文獻(16)

ZHANG Ruoyu, ZHAO Honglin, ZHANG Jiayan, et al. Hybrid orthogonal and non-orthogonal pilot distribution based channel estimation in massive MIMO system[J]. Journal of Systems Engineering and Electronics, 2018, 29(5): 881–898. doi: 10.21629/JSEE.2018.05.01

KIM K, LEE J, and CHOI J. Deep learning based pilot allocation scheme (DL-PAS) for 5G massive MIMO system[J]. IEEE Communications Letters, 2018, 22(4): 828–831. doi: 10.1109/LCOMM.2018.2803054

ZHI Hui and HU Yanjun. Novel multi-cell precoding schemes for TDD massive MIMO systems[J]. Wireless Personal Communications, 2017, 97(4): 6111–6129. doi: 10.1007/s11277-017-4829-4

ZHU Xudong, WANG Zhaocheng, QIAN Chen, et al. Soft pilot reuse and multicell block diagonalization precoding for massive MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2016, 65(5): 3285–3298. doi: 10.1109/TVT.2015.2445795

張進彥, 金鳳, 尹禮欣. 大規模MIMO系統中基于用戶分類的動態導頻分配[J]. 電信科學, 2017, 33(9): 76–84. doi: 10.11959/j.issn.1000-0801.2017212

ZHANG Jinyan, JIN Feng, and YIN Lixin. Dynamic pilot assignment in massive MIMO system based on user classification[J]. Telecommunications Science, 2017, 33(9): 76–84. doi: 10.11959/j.issn.1000-0801.2017212

ZHU Xudong, WANG Zhaocheng, DAI Linglong, et al. Smart pilot assignment for massive MIMO[J]. IEEE Communications Letters, 2015, 19(9): 1644–1647. doi: 10.1109/LCOMM.2015.2409176

KU Li, FAN Jiancun, and DENG Jianguo. Low complexity pilot allocation in massive MIMO systems[C]. The 8th IEEE International Conference on Communication Software and Networks, Beijing, China, 2016: 402–406.

AKBAR N, YANG Nan, SADEGHI P, et al. Multi-cell multiuser massive MIMO networks: User capacity analysis and pilot design[J]. IEEE Transactions on Communications, 2016, 64(12): 5064–5077. doi: 10.1109/TCOMM.2016.2614674

JING Xiaorong, LI Mengwan, LIU Hongqing, et al. Superimposed pilot optimization design and channel estimation for multiuser massive MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2018, 67(12): 11818–11832. doi: 10.1109/TVT.2018.2875480

CASTA?EDA GARCIA M H and LUO Jian. Time-shifted pilots multiplexed with uplink data and unequal power allocation[C]. 2018 IEEE Wireless Communications and Networking Conference, Barcelona, Spain, 2018: 1–6.

GAO Hongyuan, SU Yumeng, ZHANG Shibo, et al. Antenna selection and power allocation design for 5G massive MIMO uplink networks[J]. China Communications, 2019, 16(4): 1–15.

GUO Kaifeng, GUO Yan, and ASCHEID G. Energy-efficient uplink power allocation in multi-cell mu-massive-MIMO systems[C]. The 21th European Wireless Conference, Budapest, Hungary, 2015: 1–5.

AHMADI H, FARHANG A, MARCHETTI N, et al. A game theoretic approach for pilot contamination avoidance in massive MIMO[J]. IEEE Wireless Communications Letters, 2016, 5(1): 12–15. doi: 10.1109/LWC.2015.2487261

MOCHAOURAB R, BJ?RNSON E, and BENGTSSON M. Adaptive pilot clustering in heterogeneous massive MIMO networks[J]. IEEE Transactions on Wireless Communications, 2016, 15(8): 5555–5568. doi: 10.1109/TWC.2016.2561289

BOGOMOLNAIA A and JACKSON M O. The stability of hedonic coalition structures[J]. Games and Economic Behavior, 2002, 38(2): 201–230. doi: 10.1006/game.2001.0877

OSBORNE M J and RUBINSTEIN A. A Course in Game Theory[M]. Cambridge, USA: MIT Press, 1994: 255–298.
