波導頻率雙工器的多模分析計算
Multi-Mode Analysis and Calculation in Waveguide Duplexer
-
摘要: 該文用多模微波網絡的方法來分析波導頻率雙工器。先將波導頻率雙工器在結構上分割(分解)為相對簡單的單元部件(單元網絡)群，進而逐個分析每一個單元部件的電磁場邊值問題以獲得該單元網絡的多模網絡散射參數，最后通過多模網絡參數矩陣的級聯，得到整個器件，即由所有單元網絡構成的合成網絡的整體散射參數。
-
關鍵詞:
- 多模微波網絡; 有限元法; 積分方程法
Abstract: A H-plane waveguide duplexer is analysized with a multi-mode microwave network method in this paper. This method is carried out through three steps: dividing the microwave device to be analyzed into a group of unit components at first, then numerically solving, the electromagnetic boundary-value problems of components one by one to yield their multi-mode network scattering parameters, finally re-combining all the unit components to obtain the total scattering parameters of the original devices to be analyzed. -
鄧次平.現代微波網絡導論.北京:國防工業出版社,1994年6月第1版,第1章第4節.[2]Sorrentino R. Numerical Methods for Passive Microwave and Millimeter-Wave Structures, New York: IEEE Press, 1989, Ch. 8.[3]Pong Fan, Desen Fan. Computer-aided design of E-plane waveguide passive components[J].IEEE Trans. on MTT.1989, 37(2):335-339[4]Silvester P P, Ferrari R L. Finite Elements for Electrical Engineer, New York: Cambridge University, 1983, Ch.2.[5]Uwe Rosenberg, Jaroslaw Uher, Jens Bornemann. Waveguide Components for Antenna Feed Systems: Theory and Cad, USA: Artech House, 1993, Ch.3.[6]Weile D S, Michielssen E. Genetic algorithm optimization applied to electromagnetics: a review.IEEE Trans. on AP, 1997, 45(3): 343-353. -
