考慮電子注與場自洽互作用的奧羅管的大信號分析
LARGE SIGNAL SELF-CONSISTENT SOLUTION FOR OROTRON
-
摘要: 本文僅對于簡化模型探討了關于奧羅管(orotron)的效率(起振問題),導出了影響效率的重要參量Zc,給出了關于這種器件的電子注與場互作用的大信號自洽解,并舉例對實際參量進行了數值計算。計算結果指出,為了保證奧羅管能在寬頻范圍內調諧的前提下研制實用的器件,在設計準光腔的時候,不僅應追求高的品質因數,還應使與電子注作用的光柵上的模斑盡還能伸長和展寬,對于所采用的緊貼光柵表面掠過的電子注,應盡可能提高其電流值。
-
關鍵詞:
- 毫米波器件; 奧羅管; 大信號分析; 電子效率
Abstract: A large signal self-consistent solution of orotron for a simplified model is given. In this model the electron beam is modulated by the field and the field is excited by the electron beam inversely. A parameter Zc, which is very important for the efficiency (as well as for getting oscillation), is deduced. By means of this simplified model calculation is carried out for some practical parameters of orotron. It is shown that for producing a practical orotroa in wide frequency range, it is necessary to design a quasi-optical resonator not only with a high QH but also with a wide and long enough mode spot on the grating. And for the electron beam, a very small thickness is needed and it ought to pass by the grating as closely as possible, and a high enough value of current is also very necessary. -
V. K. Korneenkov, A. A. Peturshin, et al., Radiophyt. Quantum Electron., 20(1977), 197.[2]K. Mizuno, S. Ono, Y. Shibata, IEEE Trans. on ED, ED-20(1973), 749.[3]D. E. Wortman, H. Drophin, et al., IEEE J. of QE, QE-17(1981), 1341.[4]宋文森,郭開周,電子科學學刊,9(1987), 213.[5]Ф.С.Русин,Г.Д.Богомолов,Электроника Больших Мощностей,Сборник 5, Издателбство Наука, Москва,1968, p38.[6]Ю.В.Гуляев,А.А.Кураев,et al., Радиотехника и Электронника, 28(1983), 1791. -
