重?fù)诫s發射區中禁帶寬度和少子復合壽命的確定方法
A NEW METHOD FOR DETERMINATION OF ENERGY GAP AND MINORITY-CARRIER RECOMBINATION LIFETIME IN HIGHLY DOPED EMITTER
-
摘要: 禁帶寬度和少子復合壽命是硅晶體管發射區中重要的物理參數。本文利用p-n結反向擴散電流的溫度特性和借助于線性外推法,提出了一種確定絕對零度時禁帶寬度的新方法。由于發射區重?fù)诫s,本文考慮了載流子的費米-狄拉克統計分布。提出了確定發射區中少子復合壽命的方法。該方法簡便實用。
-
關鍵詞:
- 重?fù)诫s發射區; 禁帶寬度; 少子復合壽命
Abstract: Energy gap and minority-carrier recombination lifetime are important physical parameters in the emitter of silicon transistor. Using temperature characteristics obtained from the reverse diffusion current of p-n junction and by means of linear extrapolation, a new method for determination of the energy gap at 0K is presented. Based on the carrier Fermi-Dirac statistic distribution, a method for determination of minority-carrier recombination lifetime in highly doped emitter is presented. This test method is simple and can be used in practice. -
J. W. Slotboosn, et al., Solid-State Electron., 19(1976), 857-862.[2]G. E. Possin, et al., IEEE Trans. on ED, ED-27(1980), 983-990.[3]N. D. Arora, et al., Appl. Phys. Lett., 37(1980), 325-327.[4]D. J. Roulston, et al., IEEE Trans. on ED, ED-29(1982), 284-291.[5]C. H. Henry, et al., Phys. Rev., B15(1977), 989-1016.[6]N. D. Arora, et al., IEEE Trans. on ED, ED-29(1982), 292-295.[7]J. Dziemior, et al., Appl. Phys. Lett., 31(1977), 346-350. -
