JFET壓磁電效應的理論分析
THEORETICAL ANALYSIS OF THE PRESSURE-MAGNETOELECTRIC EFFECT OF JFET
-
摘要: 本文用標準的松弛方法研究了結型場效應晶體管的壓磁電效應。利用準平面拉普拉斯方程及有限差分法計算了不同柵電壓、漏電壓以及n溝道硅器件不同寬長比的壓力靈敏度和磁靈敏度。在P0,B=0,器件寬長比為W/L=1/2-1時,電流性壓力靈敏度約為:2.5％cm2/N。據此,提出了一種有良好工作穩定性及噪聲性能的力學量敏感器件結型場效應力敏管(Junction field effect-pressure sensor)。
-
關鍵詞:
- JFET壓阻效應; 壓磁電效應; 松弛方法; 有限差分法
Abstract: The pressure-magnetoelectric effect of JFET is discussed by using standard relaxation techniques. A theoretical evaluation of the pressure sensitivity and Hall sensitivity of the n-channel silicon JFET with various geometries (W/L), gate voltages (VGS) and drain voltages (VDS) is made. The results show that when P0,B0, the current-pressure sensitivity is about 2.5%cm2/N, supposing W/L = 1/2-1. A junction field effect-pressure sensor with high stability and low noise is designed. -
M. Esashi, et al., Sensors and Actrsators, 4(1983), 537-544.[2]K .Suzuki et al., IEEE Trans. on ED, ED-34 (1987) 6, 1360-1366.[3]G. R. Mohan Rao, W. N. Carr, Solid-State Elect., 16(1973), 483-485.[4]R. S. Hemert, Solid-State Elect., 17(1974), 1039-1042.[5]阮英超,半導體學報,1(1980)2,107-120.[6]中科院沈陽計算技術研究所編,電子計算機常用算法,科學出版社,1976.[7]G. E. Forsythe, W. R. Wasow, Finite-Difference Methods for Partial Differential Equations.New York, Wiley, 1960. [8] 溫殿忠,黃得星,黑龍江大學學報,1985年,第1期,第47-52頁.[8]溫殿忠,傳感器技術,1988年,第1期,第35-38頁.[9]溫殿忠等,力敏傳感器設計與研制學術論文集,1987, 78-84.[10]南京航空學院,北京航空學院合編,傳感器原理,國防工業出版社,1983年, 第241-247頁. -
