用邊界元素法計算階梯開口波導的反射系數
CALCULATION OF REFLECTION COEFFICIENT FOR STEP OPEN WAVEGUIDE WITH BOUNDARY ELEMENT METHOD
-
摘要: 本文報道的是用邊界元素法計算階梯開口波導的反射系數。文中給出了用邊界元素法求解波動方程問題的主要步驟和公式,并對本問題的一些計算細節作了說明。把在特殊狀態下得到的結果與有關文獻中的結果作了比較,從而看出這種方法的有效性。
-
關鍵詞:
Abstract: In this paper, the boundary element method (BEM) and the finite element method (FEM) are compared. Then the formulation of Helmholtz equation by BEM and the ealeulation of the reflection coefficient for step-open parallel plate waveguide by BEM are presented. Finally the flow-chart of the program and the computed results are given. Comparison of the computed results for the standing wave state with those given by the related literature shows that the computed results are reasonable. -
C. A. Brebbia, The Boundary Element Method for Engineers, Pentech Press, (1978).[2]李忠元,電磁問題中的邊界元素法,電子技術,1982年,第2期,第23頁.[3]鶩巢慎等，境界要素法による開放領域問題の解析,電気學會雷磁界理論研究會資料,EMT-81-15,1981年.[4]F. Sporleder, Waveguide Tapers Transitions and Couplers, (IEE Electromagnetic Waves Series 6), IEE, 1979. -
