GaAlAs/GaAs雙異質結發光管中的深能級
STUDY OF DEEP LEVELS IN Ga_(1-x)AlxAs/GaAs DH LEDs
-
摘要: 本文用DLTS譜儀和單脈沖瞬態電容技術測量了光通信用GaAlAs/GaAs雙異質結發光管中的深能級,對有源區摻Si和摻Ge的相同結構器件,均測得有多子陷阱存在,其能級位置分別為EC-ED0.29eV和ET-EV0.42eV。比較了外延系統中氧含量變化對有源區摻Si器件深能級的影響,以及有源區EL圖象中的DSD與深能級關系,結果表明外延系統中氧含量對深能級有明顯影響,而EL圖象中DSD的出現率與深能級無明顯關系。
-
關鍵詞:
- 發光管; GaAlAs/GaAs雙異質結; 深能級
Abstract: Deep levels in Ga1-xAlxAs/GaAs double-heterojunction LEDs have been studied by DLTS. The Ga1-xAlxAs DH material was grown by LPE technique. The dark deitcts are ob-jerved with an infrared line scanner. The effect of the oxygen contamination on the deep levels in Si-doped active layer is found. The activation energy EC-ED0.29 eV. The DSD are sometimes generated in the emitting area. It did not related to the deep levels obviously. -
D. V. Lang, J. Appl. Phys., 47(1976), 4986-4992.[2]K. Kondo, et al., Recombination-induced deep-level formation in GaAlAs DH 2EDS, 1981 GaAs and Related Compounds, Oiso, Japan, pp. 227-232.[3]高季林等,半導體學報,6(1985)3,245-249.[4]胡愷生等,發光與顯示,1984年,第3期,第25-32頁.[5]胡愷生等,發光與顯示,1981年,第2期,第34-44頁.[6]史一京,全國半導體化合物材料光電器件學術會議論文集,昆明,1982,283-286.[7]Zou Yuan-Xi, et al., Proc of 1985 Material Research Society Symposiu m46 Microscopic Identification of Electronic Detects in Semiconductors, San Francisco, USA.[8]Masamichi Sakounoto, J. Appl. Phys., 58(1985), 337-340, 385--388.[9]Toshro Uji, Jpn. J. Appl. Phys., 17(1978), 727-728.[10]Masami Tackikawa, et al., Jpn. J. Appl. Phys.,23(1984)12, 1594-1597.[11]E. E. Wagner, et al., J. Appl. Phys., 51(1980), 5434-5437.[12]P. K. Bhattacharya, et al., Appl. Phys. Lett., 36(1976), 664-666.[13]P. K. Bhattacharya, et al., Appl. Phys. Lett., 45(1985), 1322-1323. -
