SOI結構M-Z型調制器的有限元法分析
FINITE ELEMENT ANALYSIS OF THE SOI STRUCTURE M-Z INTERFEROMETRIC MODULATOR
-
摘要: 本文提出了采用有限元法分析SOI(Silicon on Insulator)結構M-Z(Mach-Zehnder)干涉型調制器的新方法。該方法在大截面單模SOI脊形波導理論的基礎上,根據等離子體色散效應分析了這種調制器的電光調制機理;根據有限元法分析了p+n結大注入時該調制器的電學性質,從而為實際研制成這種干涉型調制器打下了理論基礎。
-
關鍵詞:
- 集成光學; 調制器; 有限元法; SOI
Abstract: A new method for analysing SOI (Silicon on Insulator) Sructure Mach-Zehnder interferometric modulator by using finite element method is put forward. On the basis of the theory of the single-mode SOI rib optical waveguides with large cross-section, the electro-optic modulating mechanism of the modulator is investigated by using the plasma dispersion effect, and the electrical characteristics of the device is analysed by using the finie element method at p+n junction large injected. So the method provides a basis of the theory for the device to be fabricated. -
Mayer R A, Jung K H, Lee W D, et al. Optics Lett., 1992, 17(24): 1812-1814.[2]Fischer U, Zinke T, Schuppert B, et al. Electron[J].Lett.1994, 30(5):406-408[3]周樂柱.電子學報,1994, 22(3): 77-85.[4]Adams M J, Ritchie S, Rbertson M J. Appl. Phys. Lett., 1988, 48(13): 820-822.[5]劉育梁,劉思科.光學學報,1991, 11(8):727-732.[6]Soref R A, Schmidtchen J, Petermann K. IEEE J. of QE, 1991,QE-27(8):1971-1973.[7]Pirnat T,Fiedman L, Soref R A. J. Appl. Phys., 1991, 70(8): 3355-3359.[8]Vablonovitch E, Swanson R M, et al. Appl. Phys. Lett., 1986, 48(3): 245-247.[9]趙策洲,劉恩科,李國正.光學學報,1994, 14(7): 783-784. -
