考慮螺帶厚度的縱向?qū)w加載螺旋慢波特性分析

雷文強,  楊中海,  廖平

雷文強, 楊中海, 廖平. 考慮螺帶厚度的縱向?qū)w加載螺旋慢波特性分析[J]. 電子與信息學報, 2004, 26(9): 1487-1494.
引用本文: 雷文強, 楊中海, 廖平. 考慮螺帶厚度的縱向?qū)w加載螺旋慢波特性分析[J]. 電子與信息學報, 2004, 26(9): 1487-1494.
Lei Wen-qiang, Yang Zhong-hai, Liao Ping. Vane-Loaded Helical Slow-Wave Characteristic Analysis Considering Helical Tape Thickness[J]. Journal of Electronics & Information Technology, 2004, 26(9): 1487-1494.
Citation: Lei Wen-qiang, Yang Zhong-hai, Liao Ping. Vane-Loaded Helical Slow-Wave Characteristic Analysis Considering Helical Tape Thickness[J]. Journal of Electronics & Information Technology, 2004, 26(9): 1487-1494.

考慮螺帶厚度的縱向?qū)w加載螺旋慢波特性分析

Vane-Loaded Helical Slow-Wave Characteristic Analysis Considering Helical Tape Thickness

  • 摘要: 考慮非翼片區角向高次模式以及螺帶厚度，運用場匹配方法參考脊加載環板慢波結構的邊界條件推導得到翼片加載螺旋慢波結構的色散特性方程；并運用MAFIA軟件對該結構進行模擬計算，將理論結果與模擬計算進行比較，其誤差范圍基本滿足設計精度的要求，并討論了不同翼片結構參數對色散特性的影響，為各種類型的翼片加載螺旋慢波特性的計算提供了一種參考方法。
    Abstract: Considering azimuthal higher order modes in non-vane area and helical tape thickness, using field matching method and boundary condition of the ridge-loaded ring-piano slow wave structure, the dispersion equation of vane-load helical slow-wave structure is obtained. The numerical simulation for the vane-loaded helical slow-wave structure using MAFIA software is done. The theory calculation results are compared with the simulation results. Their errors reach the request of design precision. The effect of the dispersion is discussed in the different parameters of the vane structure. The instruction method also is provided for other types vane-load helical slow-wave structure.
    • HTML全文
  • 趙士錄.連續波寬帶大功率行波管中的色散成型及諧波抑制技術研究.電子學報.1999,27(3):113-115. ［2］Paik S F. Design formulas for helix dispersion shaping. IEEE Trans. on Electron. Devices, 1969,16(12): 1010-1014. ［3］Kumar L, Raju R S, et al.. Modeling of a vane-loaded helical slow-wave structure for broad-band traveling-wave tubes. IEEE Trans. on Electron. Devices, 1989, 36(9): 1991-1999. ［4］AK Sinha R Verma, et al.. An improved model for the analysis of segment loaded helical slow-wave used in traveling wave tubes, 4th International Symposium on Recent Advances in Microwave Technology, India, 1993 C2.1: 144-147. ［5］范植開,劉慶想.諧振腔鏈色散關系及場分布的解析研究.物理學報,2000,49(7):1249-1255. ［6］Gong Y B, Wang W X, et al.. Theoretical analysis of ridge-loaded ring-plane slow wave structure by variational methods. IEE Proc.-Microw. Antennas Propag., 1998, 145(5): 397-405. ［7］張勇,莫元龍.有限厚度翼片加載螺旋線模型.電子科技大學學報,2002,31(5):479-484. ［8］The Mafia Collaboration.2000 Mafia User Manual,version4.0.25(Germany:CST.Inc),2000:221. ［9］劉盛綱,李宏福等.微波電子學導論.北京:國防工業出版社,1984:162-164. ［10］張克潛,李德杰.微波與光電子學中的電磁理論.北京:電子工業出版社,2001:255-259. ［11］Jain P K,Basu B N.The inhomogeneous loading effects of practical dielectric supports fbr the helical slow-wave structure of a TWT.IEEE Trans.on Electron.Devices,1987,34(12):2643-2648. ［12］宮玉彬.新型大功率行波管的研究.[博士論文],成都:電子科技大學.1998:22-25. ［13］Kory C L,Dayton J A.Accurate cold-test model of helical TWT slow-wave circuits.IEEE Trans.on Electron.Devices,1998,45(4):966-971. ［14］樊孝年,賈會文等.用MAFIA軟件計算改進的梳形慢波線的色散特性.真空電子技術,1999,4:10-13. ［15］雷文強,楊中海等.螺旋慢波電路高頻特性的三維計算模擬.強激光與粒子束,2002,14(6):892-896.
