對接波導的縫隙耦合特性
COUPLING PROPERTIES OF THE SLOT IN THE WAVEGUIDE JUNCTIONS
-
摘要: 本文介紹由長縫隙耦合的端頭對接的波導接頭的電特性。利用伽略金法求解縫隙口面上等效磁流,獲得散射場及其等效參量的通用表達式。波導尺寸,縫隙尺寸和位置是任意的。給出了數值計算實例和實驗數據,二者相吻合。
-
關鍵詞:
- 波導接頭; 耦合; 縫隙; 矩量法
Abstract: The coupling properties of a transverse slot in the common wall between butting two rectangular waveguides are discussed. By means of Galerkin s method which takes into account the wall thickness, equivalent magnetic currents on the aperture surface of the slot are obtained, and then general formulas of scattering fields and of .equivalent parameters arc derived. The dimensions as well as seats of those two waveguides and the slot, and the thickness of the wall are arbitrary. For example, the transforming coefficients and the VSWRs of numerical calculation and experiments are given. The theoretical and experimental results are in good agreement. -
呂善偉,任濟時,方愔,電子學報，1985年，第5期，第92-101頁.[2]張式淇,傅氏變換法求解磁流源激勵場,中國電子學會1987年天線年會論文集,南京,第6-(Ⅰ)-1-6-(Ⅰ)-3頁. -
