容差參數的陣列天線方向圖綜合法
TOLERANCE SYNTHESIS TECHNIQUE FOR ARRAYS RADIATION PATTERN
-
摘要: 本文研究了設計參數具有容差的陣列天線方向圖綜合法;給出了陣列天線容差優化的數學模型;提出了求解容差優化問題的數學方法;建立了直線陣列天線容差區內誤差任意分布的物理模型;并對激勵幅度具有容差的側射天線陣進行了計算。本文的方法可以最大限度地避免設計參數容差對天線性能的影響。Abstract: Tolerance synthesis techniques of array radiation pattern are investigated. The mathematical models for array radiation pattern optimization are given, and the methods for solving the problem of tolerance optimization are initiated. The physical model for arbitrary tolerance distribution of array elements is presented. Numerical examples are given for the broadside array in which the excitation amplitude coefficients have tolerances. The methods given in this paper immunize optimally the resulting arrays against the deviations of the design parameters from their nominal values.
-
D. M. Pozar, IEEE Trans. on AP, AP-38(1990)8, 1176-1185.[2]H. Schiaer-Jacobsen, IEEE Trans on AP, AP-28(1980)2, 247-250.[3]H. Schiaer-Jacobsen, K. Madsen, IEEE Trans. on CAS, CAS-26(1979)9, 775-783.[4]焦永昌, 約束優化研究及在天線優化設計中的應用,西安電子科技大學博士學位論文,1990年，第32- 34頁.[5]Qi Yihong, Jiao Yongchang, Worst Case Tolerance Optimization of Arrays Radiation Pattern. APMC, (1992). -
