機載編隊飛行InSAR的運動誤差分析與補償
Motion Error Analysis and Compensation for Airborne Formation Flying InSAR
-
摘要: 該文分析了機載編隊飛行InSAR中的運動誤差問題。將飛機間距變化(垂直航跡的基線變化)情況分為間距逐漸增大、間距逐漸減小、間距呈正弦曲線規律變化3種情況討論。推導了相位變化與基線變化的定量關系, 給出了飛機間距變化和速度差異的仿真結果。采用方位向去斜坡處理,提出在測繪區域內放置兩個控制點,補償基線變化導致的相位誤差,可以大幅度地提高整片區域數字高度模型的精度。仿真結果說明該分析正確。
-
關鍵詞:
- InSAR; 編隊飛行; 運動誤差
Abstract: Motion error problem for airborne formation flying InSAR is analyzed. The plane interval changes (across track baseline changes) are discussed in three situations: interval increasing, interval decreasing, interval changing according to sine curve. Phase changes with baseline changes are derived quantificationally. The simulation result of plane interval changes and velocity difference are given out. Azimuth slope eliminating is adopted. Two control points are set in topographic area to compensate the phase error of baseline changes. This algorithm can improve the digital elevation model precision for whole area. The simulation results prove that the analysis is right. -
Graham L C. Synthetic interferometer for topographic mapping [J].Proc. IEEE.1974, 62(6):763-[2]Madsen S N, Zebker H A, et al.. Topographic mapping using radar interferometry: Processing techniques [J].IEEE Trans. on Geoscience and Remote Sensing.1993, 31 (1):246-[3]Zebker H A, Werner C L. Accuracy of topographic maps derived from ERS-1 interferometric radar [J].IEEE Trans. on Geoscience and Remote Sensing.1994, 32(4):823-[4]Lee H, Liu Jian Guo. Analysis of topographic decorrelation in SAR interferometry using ratio coherence imagery [J].IEEE Trans. on Geoscience and Remote Sensing.2001, 39(2):223-[5]唐智,李景文.編隊飛行InSAR的平地效應與地形高度效應分析[J].電子學報,2003,31(12A):2183-2186.[6]Zebker H A, Villasenor J. Decorrelation in interferometric radar echoes [J].IEEE Trans. on Geoscience and Remote Sensing.1992,30(5):950-[7]Rodriguez E, Martin J M. Theory and design of interferometric synthetic aperture radars [J]. IEE Proc.-F, 1992, 139(2): 147 -159.[8]肖業倫,張曉敏.編隊飛行衛星群的軌道動力學特性與構形設計[J].宇航學報,2001,22(4):7-12.[9]韓潮,譚田,楊宇.編隊飛行衛星群構型保持及初始化[J].中國空間科學技術,2003,(4):51-57. -
