關于無截獲柵電子槍柵網形狀的研究
RESEARCH ON GRID-MESH SHAPES OF NON-INTERCEPTINGGRIDDED GUNS
-
摘要: 本文敘述了采用三種不同形狀柵網(方孔柵、六角孔柵、環形柵)的導流系數為1.4p的無截獲柵柵控電子槍,在電子注分析器上進行實驗的詳細情況。文中扼要地介紹了無截獲柵柵控槍使用三種不同柵網的設計方法,并給出了所用實驗系統的結構。三種柵網的熒光屏顯示和小孔掃描測試的結果表明,環形柵的電子光學性能最佳。從概念上定性地分析并討論了環形柵優于其它柵的原因。這為今后設計無截獲柵槍指出了方向。通過對多把無截獲柵槍的實驗研究和計算機計算,糾正了過去有關柵控槍和基礎無柵槍性能上的一些概念上的錯誤結論。
-
關鍵詞:
Abstract: A non-intercepting gridded gun with the perveance of 1.4p is described. Three different grid-mesh shapes (square, hexagonal and annular) are chosen, and the experimental results in an electron beam analyzer are given in detail. The design methods of the gun for each grid-mesh shape and the structures of the test system are briefly introduced. The results measured by using the fluorescent screen and pin-hole scanning technique are given. It turns out that the annular grid possessed the best electron optical performance. The reason that the performance of the annular grid is better than the others is qualitatively explained and discussed, so as to give the guide lines of how to design the non-intercepting gridded guns. Through the experiment and computer calculation for several non-intercepting gridded guns, the previous wrong conceptional conclusions about the performances of the guns with and without grid may be corrected. -
