諧振式四臂螺旋天線的矩量法分析
THE MOMENT METHOD FOR ANALYSIS OF RESONANT QUADRIFILAR HELICAL ANTENNAS
-
摘要: 本文對Nakano簡化的曲線天線積分方程核做了更便于數值計算的處理;運用矩量法分析,計算了諧振式四臂螺旋天線的圓極化方向圖、增益、軸比、前后比及賦形特性等,并研究了饋電方法和導電板對天線性能的影響。
-
關鍵詞:
- 螺旋天線; 積分方程核; 矩量法
Abstract: An efficient measure is taken in simplification of Nakano s kernel of integral equations of arbitarily bent wires. By means of the moment method, great efforts are made in analysis and computation of the circularly polarized patterns, gain, axial ratio, front to back ratio and beamshaping of the resonant quadrifilar helical antennas as well as the feeding techniques and effect of a conducting plate on the antennas. -
C. C. Kilgus, Microwave Journal, 13(1970) 12, 49-54.[2]K. K. Mei, IEEE Trans. on AP, AP-13(1965)5, 347-378.[3]H. Nakano, Trans. IECE Japan, E65(1982)6, 303-309.[4]R. F. Harrington, Field Computation by Moment Methods, the Macmillan Company, 1968. -
