數字圖象幾何變換的B樣條算法和硬件實現
B SPLINE ALGORITHM FOR GEOMETRIC TRANSFORMATION OF DIGITAL IMAGE AND HARDWIRED IMPLEMENTATION
-
摘要: 本文提出了一種利用B樣條函數進行數字圖象幾何變換的算法。在給定一組特殊的規則控制柵格點的條件下,構成B樣條變換式。此變換算法保證給出的控制柵格點的準確對應,可得較高的精度。在小型圖象處理系統中可用一種專用的變換解算裝置來實現。 本文還提出開窗幾何變換的自動實現。
-
關鍵詞:
Abstract: In this paper, the algorithm of using B spline function for geometric transformation of digital image is presented. Given a group of special regular controlling points, B spline function for transformation is formed. The algorithm guarantees precise correspondence between controlling points, higher precision can be obtained. It can be implemented in a minicomputer digital image processing system with a special hard-wired device.This paper also points out that the geometric window transformation can be implemented automatically. -
楊世仁,計算機學報,3(1980), 54.[2]H. S. Hou and H. C. Andrews, IEEE Trans. on ASSP, ASSP-26(1978), 508.[3]M. T. Munteanu and L. L. Schumaker, J. Approximation Theory, 10(1974), 23.[4]R. T. Gregorg and D. L. Karney, A Collection of Matrices for Testing Computational Algerithms, New York: Wiley, 1969, p. 48.[5]劉其真等,自動化學報,8(1982),279. -
