X波段矩形波導相控陣天線
X-BAND RECTANGULAR WAVEGUIDE PHASED ARRAY ANTENNA
-
摘要: 本文給出X波段矩形波導相控陣天線的研制結果。將該天線作為電磁場邊界值問題求解,建立了以孔徑切向電場為未知函數的積分方程。經矩法處理后,在DJS-6型電子計算機上得到了數值解。制作了115元的無源小陣列。測量了陣單元方向圖,加工了兩個H面波導模擬器:HIC14和HIC29,進行了測試。寬角匹配介質板和孔徑上匹配膜片的參數是通過理論計算和試驗調整確定的。理論計算結果與測量結果相近。在86009600MHz頻段和60掃描圓錐體內,天線的輸入電壓駐波比VSWR2。
-
關鍵詞:
Abstract: The results of an actual X-band rectangular waveguide phase controlled antenna array are given. Using the antenna array as boundary values of electro-magnetic field, a solution of the field equations is made, and an integral equation of the tangential electric feild function of an unknown aperture is established. Through conversion to matrix methods, numerical results are obtained by using the DJS-6 computer. A sourceless small array containing 115 elements was made. The directional diagram of the array element wasmeasured. Also two magnetic H face waveguide simulators: HIC 14 and HIC 29 were made, and experimental tests were performed. The parameters of the wide angled matching dielectric plate and the mateching foil over the aperture were determined by theoretical calculations and experimental results are quite close to each other. On the 8600--9600 MHz band and 60 scanning spherical cone; the VSWR of input voltage on the antenna is less than 2. -
N.Amitay, V. Galindo and C.P. Wu著,陸雷譯,相控陣天線理論與分析,國防工業出版社 1978.[2]C.Cchen, IEEE Trans. on AP, AP-21(1973), 298.[3]S.W.Lee and W. R. Jones, IEEE Trans. on AP, AP-19(1971), 41.[4]S.W.Lee, W. R. Jone and J. J. Complull, IEEE Trans. on MTT,MTT-19(1971),528. -
