多晶硅發射極晶體管的低溫頻率特性研究
INVESTIGATION OF LOW TEMPERATURE FREQUENCY CHARACTERISTICS OF POLYSILICON EMITTER BIPOLAR TRANSISTORS
-
摘要: 本文考慮低溫下半導體中載流子凍析效應和淺能級雜質的陷阱效應等因素,分析了多晶硅發射極晶體管的低溫頻率特性。研究表明,受載流子凍析效應的影響,基區電阻在低溫下隨溫度下降接近于指數上升,使晶體管的頻率性能變環;而由于淺能級雜質的陷阱效應,低溫下基區和發射區渡越時間變長,截止頻率下降。這些因素在低溫器件設計中應予重視。
-
關鍵詞:
- 雙極晶體管; 多晶硅發射極; 截止頻率; 低溫頻率特性
Abstract: The low temperature frequency characteristics of polysilicon emitter bipolar transistors are investigated, considered the carrier freezingout effect and trapping effect of shallow energy impurities in semiconductors. It shows that the base sheet resistance Rdb increases quasi-exponentially at low temperature due to carrier freezingout, which results in the degradation of frequency characteristics of the transistors at low temperature. The base and emitter transit time increase and the cutoff frequency decreases at low temperature due to the trapping effect of shallow energy level impurities. Those should be considered carefully in the design of devices for low temperature operation. -
Kapoor A K, et al. Polysilicon Emitter Bipolar Transistors. New York: IEEE Press. 1989. 3-16.[2]黃流興,等.電子科學學刊,1994,16(2):207-211.[3]Yu Z, et al. IEEE Trans. on ED, 1984. ED-31(6): 773-784.[4]Selberherr S. In: Raider S I, et al. ed, Proc. Symp. Low Temperature Electronics and High[5]Temperature Superconductors, 1988, 70-86.[6]Van den Biesen I J. Solid State Electronics, 1986, 29(5): 529-534.[7]Suzuki K. IEEE Trans. on ED, 1991, ED-38(11): 2512-2518.[8]Dumke W P. IEEE Trans. on ED, 1970, ED-17(4): 388-389.[9]鄭茳,等.固體電子學研究與進展,1991,11(1): 33-37. -
