基于FDTD的波導介質層PBG結構的研究
Research on Dielectric Layer PBG Structures in Waveguide Based on FDTD
-
摘要: 該文提出了波導中介質層式的PBG結構，并對其阻帶特性進行了數值分析，其中包括PBG 結構的設計，周期長度、周期個數、單元尺寸等幾個方面對阻帶特性的影響等，并給出了結論。利用介質層PBG結構來制作波導濾波器具有設計簡單、易于實現的顯著優點。Abstract: In this paper, a new dielectric layer PBG structures in waveguide is introduced, and numerical analysis to its stop-band characteristic is finished. The design of PBG structures and the effect of the size of period, the number of periods, the size of unit etc. are presented. And the conclusion is presented too. It is easy to design and manufacture waveguide filter using dielectric layer PBG structures.
-
Yablonovitch E. Inhibited spontaneous emission in solid-state physics and electronics[J].Phys. Rev.Lett.1987, 58(20):2059-2062[2]Vesna Radisic, Yongxi Qian, Roberto Coccioli, et al.. Novel 2-D photonic bandgap structure for microstrip lines[J].IEEE Microwave Guided Wave Lett.1998, 8(2):69-071[3]Yasushi Horii, Makoto Tsutsumi. Harmonic control by photonic bandgap on microstrip patch antenna[J].IEEE Microwave Guided Wave Lett.1999, 9(1):13-15[4]Joseph S. Colburn, Yahya Rahmat-Samii. Patch antennas on externally perforated high dielectric constant substrates. IEEE Trans. on Antennas Propagat., 1999, AP-47(12): 1785-1794.[5]Smith D R, Schultz S. A New type of waveguide structures with photonic band structures. IEEE MTT-S Digest, 1996: 911-914. -
