基于方程相容性檢測有源網絡多重故障的可測性
TESTABILITY OF EQUATION CONSISTENCY BASED ALGORITHM FOR MULTIPLE-FAULT LOCATION OF ACTIVE NETWORKS
-
摘要: 該文引入零泛器電路討論有源網絡的k故障定位的問題,使含有四種受控電源的有源網絡k故障定位方法與無源網絡統一起來。此外,對有源網絡k故障定位的局部可測條件和全局可測條件從拓撲上進行了分析。
-
關鍵詞:
- 有源網絡; 故障診斷; 可測性
Abstract: This paper deals with k-fault location of active networks with four controlled sources. It is verified by means of nullors, that the algorithm for active networks is identical to that for passive networks. Furthermore, the local testability and global testability are topologically discussed for active networks. -
R.M.Biernacki,J.W.Bandler,Multiple-fault location of analog circuits,IEEE Trans.on Circuits and Systms,1981,CAS-28(5),361-366.[2]T.X.Trick,Y.Li.A sensitivity based algorithin for fanlt isolation in analog circuits,In Selected Papers on Analog Fault Diagnosis by R.W.Lou.New York,IEEE Press,1987,67-70.[3]C.S.Lin,A.F.Huang,R.W.Liu.Topological conditions for single-branch-fault,IEEE Trans on Circuits and Systms,1983,CAS-30(6),376-381.[4]Z.F.Huang,C,S.Lin,R.W.Liu,Node-fault diagnosis and a design of testability,IEEE Trans on Circuits and Systms 1983,CAS-30(5),257-265.[5]李于凡,王定中.K故障診斷可測性的公樹條件,電路與系統學報,1996,1(1),89-97.[6]王定中,零泛器電路分析,北京,高等教育出版社,1987,第四節. -
