用于近貼聚焦微通道板象增強器的新穎控制電路
A NOVEL CONTROL CIRCUIT FOR PROXIMITY FOCUSED MICROCHANNEL PLATE IMAGE INTENSIFIERS
-
摘要: 近貼聚焦微通道板(MCP)象增強器由于具有高的時間和空間分辨率、寬廣的光譜和輸入強度動態范圍、高的增益以及能記錄單次瞬變現象,經常被用作超高速的光快門(光閘)。 微通道板象增強器與控制其快門作用的選通脈沖發生器相結合,便構成具有高的光增益和快速響應的超高速相機。本文比較了對一個典型第二代象增強器(18mm,ITT-F4111型象增強器)進行脈沖控制的三種方式。在此基礎上,提出了在象增強器的光陰極進行選通的、能產生大幅度毫微秒脈沖的新穎控制電路。實驗表明,用這種控制發生器,相機的曝光時間可達到約2 ns。文中還討論了控制發生器與象增強器之間的匹配,并提出一個簡單而有效的方法,借此可以消除在單次攝影中必須絕對避免的多次曝光現象。
-
關鍵詞:
Abstract: The proximity focused microchannel plate (MCP) image intensifier can be used as a fast optical shutter, due to its high temporal and spatial resolution, large spectral and input intensity range, high gain, and possibility of transient recording of single-shot events.A microchannel plate image intensifier combining with a gating pulse generator constitutes the simplest image converter camera with high gain and fast response. Three different gating manners for a typical second generation converter tube (18 mm,ITT-F4111 type) are compared. A new control circuit for gating the photocathode of the image intensifier is developed, and it generates high amplitude nanosecond pulses. The experimental result shows that a camera exposure time of about 2 ns has been obtained with this gating generator. The matching of the gating generator with the image intensifier is also discussed. a simple and efficient method is presented to eliminate the multi-exposure effect which must be avoided in single-shot photography. -
F. S. Hallock, SMPTE Journal, 89(1980), 709.[2]Generation. II Proximity Focused Channel Intensifier Tubes, ITT-Druckschrift F-4111.[3]J. L. Moll et al., Proc. IRE, 50(1962), 43.[4]張執中,周旋,物理學報, 30(1981), 84. -
