采用光波導調制器進行的光學雙穩態和多穩態的研究
STUDY OF OPTICAL BIST ABILITY AND MULTISTABILITY WITH OPTICAL WAVEGUIDE MODULATOR
-
摘要: 采用平面光波導電光調制器及簡單的雙光束干涉裝置成功地進行了光學雙穩態和多穩態的實驗研究。光波導調制器是在自制的鈦擴散鈮酸埋平面光波導上蒸鍍鋁電極制成的。采取激光由調制器端面直接輸入,由鍺酸鉍棱鏡耦合輸出的方式。實驗中消除了鍺酸鉍晶體旋光性的影響。本文除了對光學雙穩性進行了分析討論外,還著重對不同形態的多穩實驗回線進行了探討。
-
關鍵詞:
Abstract: Using a planar optical waveguide electro-optic modulator and simple double beam interfering device, the experimental study of optical bistability and multistability is succesfully performed. The waveguide modulator is made by depositing Aluminium as electrodes on the Ti-diffused LiNbO3 planar optical waveguide which is fabricated by ourselves. Laser beam is coupled directly into the end of optical waveguide modulator and out of the Bi12GeO20 prism. Optical rotation arising from Bi12GeO21 crystal is overcome in experiment. In addition to analyzing and discussing optical bistability the multistabilitical hysteresis curves of different shapes obtained in experiments are particularly investigated. -
P.W .Smith, E. H. Turner et al., IEEE J. Quant.Elec. QE-14 (1978), 207.[2]P.W. Smith, Appl. Phys. Lett., 34(1979), 62.[3]P.S. Cross, IEEE J. Quant. Elec., QE-14(1978),577.[4]A.Schnappor, Opt. Comm., 29(1979), 304.[5]李淳飛、鄒立勛、萬立德,哈爾濱工業大學學報,1982年,第1期,第1-12頁.[6]I. P. Kaminov, Appl. Phys. Lett., 22(1973), 540.[7]葉培大、吳彝尊,光波導技術基本理論,人民郵電出版社,1981年,第502頁.[8]土井康弘,偏光と結晶光學,共立出版株式會社,1975年,第110頁.[9]李淳飛、季家镕,光學學報,4(1981), 336. -
