TEM分析用的半導體橫截面樣品的制備和分析的結果
PREPARATION OF CROSS-SECTIONAL SPECIMEN OF SEMICONDUCTOR FOR TEM AND ANALYTICRESULTS
-
摘要: 本文介紹了透射式電子顯微鏡(TEM)用的橫截面樣品的制作技術。利用這一技術制出的樣品,用TEM觀察到了GaAs/AlGaAs超晶格結構中周期性的精細成分調制的新現象。在金屬有機化合物汽相沉積(MOCVD)生長的GaAs/si材料中還觀察到一些新形狀的位錯、微孿晶等。這一種制樣技術也適用于其他半導體材料系統的研究。Abstract: The technique for preparing cross-sectional specimen of semiconductor for TEM is shown. In such specimens prepared with the technique, an unexpected periodic compositional modulation in the fine low-dimensional structure named Fine Low Dimensional Modulated Fringes of GaAs/AlGaAs multilayers grown by MBE are observed. Some new patterns of dislocations, defects and microtwins etc. in GaAs/Si grown by both MBE and MOCVD are remarked. The technology can be adapted to the study of other systems of semiconductor materials also.
-
范榮團,電子科學學刊,12(1990)1,93-99.[2]褚一鳴,姜彤弼,范榮團,電子顯微學報,7(1988)3,178.[3]范榮團,MBE,MOCVD外延生長的GaAs/Si中微孿晶,第三屆全國材料科學中電子顯微學會議論文集,1989年,11月,四川樂山,第56-58頁.[4]D. J. Eagesham, et al., Defects in MBE and MOCVD Grown GaAs on Si Inst. Phys. Conf. Ser. No.87,1987, 105-110. -
