微波四相調制的分析與動態觀察法
AN ANALYSIS AND A DYNAMIC TESTING METHOD OF MICROWAVE QPSK MODULATION
-
摘要: 本文采用步進轉動(順時針或逆時針)的信碼作信源,分析了廣義四相調制的特性,給出調制信號的頻譜和兩調相電路間的導納關系表達式,計算了幾種典型四相調制頻譜的實例,據此可判定調制的效果和相位誤差,并用于動態測試中對四相調制器進行調整,實驗表明測得的結果與理論計算是相符的。本文還報道了X波段四相調制器的實驗情況,測得其最大相位誤差小于4,相讓精度可達0.1,插入損耗小于4dB,傳送數據率可達 34Mb/s。
-
關鍵詞:
Abstract: Using the clockwise or anticlockwise stepping pulse code signal, the characterities of general QPSK modulation are analysed. The spectrums in several operational conditions and the admittance formulas of related two modulation circu ts are given. Several typical examples of QPSK modulation are calculated. The results are used to decide the modulation effect and phase error, and also to adjust the QPSK modulator under the dynamic testing. The experimental results are in agreement with the theortical calculations. An X band QPSK modulator is also presented. the maximum phase error is less than 4, insertion loss less than 4 dB, phase accuracy near 0.1 and transmission data rate up to 34 Mb/s. -
W. O. Schlosser and K. Kurokanwa, IEEE Trans. on MTT,MTT-20(1972), 614. -
