單臺相機機載InSAR基線動態測量方法研究
The Dynamic Measurement Scheme Based on Single Camera for the Airborne InSAR Baseline
-
摘要: 該文提出一種對機載干涉合成孔徑雷達(InSAR)基線的動態測量方法。通過在機載InSAR天線上布設一定數量的控制點，采用單臺內方位元素精確標定的數碼相機對天線進行實時監測?；趯?shí)時控制點圖像所建立的共線方程和后方交會算法，解算出相機測量坐標系與控制點輔助坐標系之間的轉換參數。將轉換參數代入待測點坐標方程后，計算得到天線中心在測量坐標系下的實時三維坐標。在實驗室進行的靜態和動態模擬實驗取得較好結果，驗證了該文提出的InSAR基線動態測量方案的可行性。Abstract: The dynamic measurement scheme based on single camera for the airborne InSAR baseline is described in this paper. In the above measurement scheme, the calibrated camera is mainly responsible for taking pictures on the pre-designed legends on the antennas of the InSAR system at a reasonable frequency. The 3D coordinates of the antenna phase centers are calculated by the collinear equations and backward intersection algorithm. The scheme is verified feasible by the static and dynamic tests.
-
Graham L C. Synthetic interferometric radar for topographic mapping[J].Proc. IEEE.1974, 62(6):763-[2]Peng Hailiang, Shao Yi-ming, Song Fu-ming, Wu Yi-rong, Wang Lei, Li Lan. DEM generation using L-band airborne SAR data,IGARSS 2000, Honolulu Hawaii, USA, 2000:764 - 766.[3]王磊,彭海良.重復飛行機載干涉SAR的實驗研究[J].電子與信息學報.2002,24(12):1939-1946瀏覽[4]Wang Yan-ping, Peng Hai-liang. Locating calibrators in airborne InSAR calibration. IGARSS 2003, Toulouse, France. 2003:4515 - 4517.[5]彭海良,王彥平.機載合成孔徑雷達干涉靈敏度分析.高技術通訊,2004,14(1):17-20.[6]馮文灝.近景攝影測量的基本技術提要.測繪科學,2000,25(4):26-30.[7]王保豐.計算機視覺工業測量系統的建立與標定.[碩士論文],鄭州:解放軍信息工程大學,2004.[8]李德仁,王新華.CCD陣列相機的幾何標定.武漢測繪科技大學學報,1997,22(4):308-313.[9]李廣云,倪涵,徐忠陽.工業測量系統.北京:解放軍出版社,1994:89-151.[10]黃桂平.多臺電子經緯儀/全站儀構成混合測量系統的研究與開發.[碩士論文],鄭州:解放軍信息工程大學,1999. -
