S波段2.5MW寬頻帶大功率速調管的研制
A S-BAND 2.5 MW HIGH-POWER BROADBAND KLYSTRON
-
摘要: 本文討論了大功率、高增益、寬頻帶大功率速調管的設計和制造,還采用小信號增益和大信號效率計算程序,對寬頻帶速調管的群聚段進行了設計。當小信號增益大于50dB時,7腔速調管的群聚頻寬寬于10％,8腔速調管的群聚頻寬可達1015％ 給出了兩類寬頻帶輸出電路,即濾波器型輸出電路和重疊模雙間隙腔輸出電路的設計方法和測試結果,結果表明:前一種輸出電路的頻寬可達7.510％,后一種輸出電路的頻寬可達1015％。 研制了兩種類型速調管,采用濾波器型輸出段的速調管的性能達到:1dB等激勵頻寬為7.5％,效率為38％,飽和增益大于43dB,輸出功率大于2.5MW。采用雙間隙腔輸出段的速調管的1dB等激勵頻寬遲10％,工作穩定。
-
關鍵詞:
Abstract: In ths paper, the design considerations of the high- efficiency high- gain broadband klystron are described. Its buncher has been studied by using small signal gain and large sigual efficiency programs. The buncher bandwidth of 10% with small signal gain greater than 50 dB can be obtained for 7-cavity klystron. The bandwidth of 10-15% can be obtained for a 8-cavity klystron. The design methods and measured results of two types of output cireuits are introduced. The bandwidth of the filter type output circuit is about 7.5-10% and that of the overlapping mode two gap cavity output circuit is about 10-12%. Two types of S-band broadband klystron have been constructed and tested. Teh experimental results are given as follow. The klystron with a filter type output circuit has 1 dB equi-drive bandwidth of 7.5% with efficiency of 38% and gain of 43 dB. The klystron with an overlapping mode two gap cavity output circuit has 1 dB equi-drive bandwidth of 10%. Their output power is greater than 2.5 MW. -
G. Faillon, Revue Technique Thomson-CSF, 8(1976), 289.[2]M. J. Smith, D. Perring and G. Phillips, A One Megawatt S-Band Grided Klystron for a Wide Band Pulse Comptession Radar, 1977, Radar-77, International Conference, 1977 (London, England) pp. 354-357.[3]J. Mann, Wide-Bandwidth High-Efficiency High-Gain Klystron Amplifier, 1982 Microwave Power Tube Conference (U. S. A).[4]丁耀根,電子科學學刊,5(1983), 238.[5]丁耀恨,朱允淑,電子學通訊,4(1982),354.[6]丁耀根,陸孝厚,電子學通訊,4(1982), 168.[7]E. Lien., Technical Report ECOM-02157-F Nov. 1967.[8]Zhao Yongxing, IEEE Trans. on ED, ED-29(1982), 316.[9]陸孝厚,電子科學學刊,5(1983),290. -
