基于小波的廣義時頻分布及其與Cohen類的關系
The Generalized Time-Frequency Distribution Based on Wavelet and Its Relation with Cohens Class
-
摘要: STFT, WT, WVD和Cohen類是目前信號分析和處理的有力工具。本文用WT的二次型時頻形式分析了線性時頻特性，研究了尺度圖和變化窗譜圖與Cohen類之間的關系；將尺度圖納入到Cohen類的框架，從而使WT廣義化為時頻域、時延頻偏域的雙線性時頻分布以及譜相關域的二維頻率分布；定義了尺度圖、小波模糊函數(WAF)和小波譜相關函數(WSCF)；分析了它們的物理意義。推導并仿真了單頻、雙頻和高斯白噪聲的WSCF，分析了各自的特性。最后通過引入一種離散小波變換的加密算法，解決了小波時頻分布的計算問題。
-
關鍵詞:
- 小波;尺度圖;小波譜相關;二次時頻分布;Cohen類
Abstract: STFT, WT, WVD and Cohens class are the useful tools of signal processing. This paper analyzes the bilinear TF based on WT, and the relation between the scalogram, VWS and Cohens class, Furthermore, the scalogram is classified into Cohens class, and then WT is generalized to TF domain(scalogram)，ambiguity domain(wavelet AF) and frequency/frequency delay domain(WSCF). The WSCF characteristics of mono-frequency, dual-frequency, WGN, and fractal stochastic noise are analyzed. Finally, a dense algorithm of discrete WT is introduced to the computation of generalized TF distribution based on WT. -
王宏禹 著. 非平穩隨機信號分析與處理. 北京: 國防工業出版社, 1999. 1. 1: 206-219.[2]Jeong J.[J].Williams W J. Variable-windowed spectrograms: connecting Cohens class and the wavelet transform. IEEE signal processing, Fifth ASSP Workshop on Spectrum Estimation and Modeling.1990,:-[3]楊福生 著. 小波變換的工程分析與應用(第一版). 北京: 科技出版社, 1999, 2: 13-22[4]羅利春 著. 無線電偵察信號分析與處理. 北京: 國防工業出版社, 2003, 1. 1:70-80.[5]Kadambe S, Faye B B. A comparison of the existence of cross terms in the Wigner distribution and the squared magnitude of the wavelet transform and the short-time Fourier transform[J].IEEE Trans. on SP.1992, 40(10):2498-2516[6]張賢達 著. 現代信號處理(第二版). 北京: 清華大學出版社, 2002, 10: 464-470[7]Rioul O, et al.. Fast algorithm for discrete and continuous wavelet transform[J].IEEE Trans. on IT.1993, 38(2):569-586[8]Rioul O, Flandrin P. Time-scale energy distributions: A general class extending wavelet transforms[J].IEEE Trans. on SP.1992, 40(7):1746-1757[9]Li Y, Yi M, Yang Q, Xiao X C, Tai H-M, Low SNR BPSK signal chip rate estimation using a wavelet based spectral correlation algorithm. Proc. IEEE 45th IEEE International MWSCAS, Iulsa, Oklahma, USA: 2002: 247-249. -
