微帶型回音壁模介質諧振器帶阻方向濾波器
MILLIMETER-WAVE BANDSTOP AND DIRECTIONAL FILTERS USING PLANAR WHISPERING-GALLERY MODES DIELECTRIC RESONATORS AND MICROSTRIP LINE
-
摘要: 本文報道了使用新型平面回音壁模介質諧振器的微帶型毫米波帶阻、方向濾波器。全文用行波環諧振器的方法進行分析,并給出了Ka波段帶阻、方向濾波器的實驗研究,其結果表明,該諧振器特別適用于毫米波微帶集成電路。
-
關鍵詞:
- 毫米波; 介質諧振器; 回音壁模; 濾波器; 微帶線
Abstract: This paper reports the utilization of a new type of planar whispering-gallery modes dielectric resonators and microstrip line for the design of Ka-band bandstop and directional filters. The analysis is based on the traveling wave ring resonator. Finally, experimental results of bandstop and directrional filters in Ka-band are given, which show such resonators are very suitable for use in millimeter-wave microstrip integrated circuits. -
Vedrenne C, et al. IEE Proc.-H, 1982, 129(4): 183-187.[2]Auraguchi M, et al. IEEE Trans on MTT, 1982, MTT-30(11): 1867-1873.[3]Hoefer W J R, et al. IEEE Trans, on MTT, 1982, MTT-30(12): 2190-2194.[4]Guillon P.[J]. Microwave RF.1987,26(9):75-[5]Jiao X H, et al. IEEE Trans on MTT, 1987, MTT-35(12): 1169-1175.[6]Jiao X H, et al. IEEE Trans on MTT, 1989, MTT-37(2): 432-437.[7]Rayleigh Lord. Phil. Mag., 1914, 27(11): 100-104.[8]劉革,劉盛綱.電子科技大學學報,1994, 23(4): 387-391.[9]Guillon P, et al. Electronic Lett, 1985, 21(3): 88-89.[10]薛泉.毫米波微帶混合集成技術:[博士論文].電子科技大學應用物理所,1993. -
