FDTD結合變分法計算線天線間耦合度
Calculation of Mutual Coupling between Wire Antennas by Applying Variational Principles in FDTD
-
摘要: 線天線的自阻抗、互阻抗及耦合度是工程應用中迫切需要但又很難計算準確的。該文將時域有限差分法和變分原理相結合，求解了線天線之間的互阻抗，從而得到了耦合系數。其結果與FEKO，NEC仿真均吻合良好，表明該文方法可以獲得比傳統FDTD計算方法更加準確的計算結果。
-
關鍵詞:
- FDTD;變分原理;互耦
Abstract: Self impedance,mutual impedance and coupling of antennas are crying out for engineering application，but they can not be easily accurately calculated. The scheme that combines variational principles and the FDTD is presented in this paper to calculate the mutual impedance of wire antennas and the coupling coefficients. Numerical results obtained here have a good agreement with that from FEKO and NEC, which validate the accuracy and efficiency of this method. -
R. F. 哈林登 著，王爾杰等譯. 計算電磁場的矩量法. 北京：國防工業出版社，1981: 7475. .[2]葛德彪，閆玉波. 電磁波時域有限差分方法. 西安：西安電子科技大學出版社，2002.4: 824. .[3]Pekonen O P M, Nikoskinen K I, Goodwin S. Applying variational principles in FDTD antenna input impedance simulations[J].Microwave and Optical Technology Letters.1998, 19(6):422-3.0.CO;2-Z' target='_blank'>[4]楊娟，張玉，梁昌洪. 線天線輸入阻抗的變分原理結合FDTD求解. 電波科學學報，2003，18(1): 4852. .[5]Harrington R F. Time-Hamonic Electromagnetic Fields. New York: McGraw-Hill, 1961: 348355.[6]Burke G J. Numerical Electromagnetics Code-NEC-4 Method of Moments Part II: Program Description--Theory, UCRL- MA- 109338. California: Lawrence Livermore National Laboratory, 1992. -
